Features:
- Matches the 55 kW Active Line Module class in SINAMICS drive systems.
- Attenuates conducted emissions across the 150 kHz to 30 MHz band.
- Carries 105 A through a three-phase 380–480 V line path.
The Basic Line Filter is positioned ahead of the Active Line Module rather than between the inverter and motor.
Its electrical rating links suppression performance to the power level of the associated line-module installation.
Separate line, load, and protective-earth connections define the current path through the IP20 assembly.
The Siemens 6SL3000-0BE25-5DA0 SINAMICS 55 kW Basic Line Filter is listed as an active product and may be available for purchase and support from Apter Power.
Siemens 6SL3000-0BE25-5DA0 SINAMICS 55 kW Basic Line Filter Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Supply and Current Envelope
- Drive rating: The filter is assigned to a 55 kW Active Line Module.
- Input range: Three-phase operation covers 380 to 480 V.
- Frequency window: The permitted line frequency is 47 to 63 Hz.
- Current capacity: Rated line current is 105 A.
Conducted-Noise Attenuation
- Suppression band: Filtering covers conducted interference from 150 kHz to 30 MHz.
- Installation point: The assembly sits in the supply path ahead of the Active Line Module.
- Radio protection: High-frequency line emissions are reduced before they propagate into the mains.
- Thermal loss: Rated filter power loss is 41 W.
Power and Earth Connections
- Phase terminals: L1, L2, and L3 identify the three-phase line and load path.
- Conductor size: The power terminals accept 50 mm² conductors.
- Protective earth: PE is connected through an M6 screw.
- Tightening value: The specified PE torque is 3 Nm.
Module Pairing Boundary
- Assigned module: Selection is based on the 55 kW Active Line Module class.
- System families: The filter is listed for SINAMICS and SIMODRIVE 611 assemblies.
- Cabinet envelope: Overall dimensions are 46.6×10×22.6 cm.
- Enclosure form: The line filter has an IP20 protection rating.
