6SL3055-0AA00-5AA3

/ 4.9
1001 reviews | Need a Specific Revision?
The Siemens 6SL3055-0AA00-5AA3 SMC10 sensor module evaluates two-pole or multipole resolver feedback for a SINAMICS S120 drive through DRIVE-CLiQ.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6SL3055-0AA00-5AA3
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SL3055-0AA00-5AA3

  • Manufacturer:
    Siemens
  • Part Number:
    6SL3055-0AA00-5AA3
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    SINAMICS S120 SMC10 Sensor Module
  • Stock:
    1
  • Resolver Types:
    2-pole and multipole
  • Excitation Voltage:
    4.1 V
  • Excitation Frequency:
    5...16 kHz
  • Transmission Ratio:
    0.5
  • Encoder Frequency:
    2 kHz max
  • Signal Interpolation:
    16384×, 14 bit
  • Encoder Line Length:
    130 m max
  • Supply Voltage:
    24 V DC
  • Current Demand:
    0.20 A without encoder
  • Fuse Protection:
    20 A
  • Line-Side Conductor:
    2.5 mm² (AWG 14)
  • PE Connection:
    M4 screw
  • Degree of Protection:
    IP20 / UL open type
  • Power Loss:
    10 W max
  • Standard Compliance:
    cULus
  • Product Dimensions:
    30×150×111 mm
  • Weight:
    0.99 lbs (0.45 kg)
  • Estimated shipping dimensions:
    3.6×18.2×35.2cm
  • Tariff Code:
    85049090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Resolver Input Signal Scaling Cable Route Cabinet Fit

Features:

  • Evaluates feedback from two-pole and multipole resolver devices.
  • Transfers processed position feedback to the drive through DRIVE-CLiQ.
  • Supports resolver cable runs up to 130 m within the stated signal limits.
The SMC10 input stage in 6SL3055-0AA00-5AA3 excites and reads resolver windings rather than a digital DRIVE-CLiQ encoder.

Its conversion path combines a defined transmission ratio with high interpolation so the drive receives resolved position information.

Cabinet wiring must account for the open-type enclosure, protective earth, supply demand, and permitted resolver lead length.

The Siemens 6SL3055-0AA00-5AA3 SMC10 Sensor Module is listed as Active / Available from OEM.
Siemens 6SL3055-0AA00-5AA3 SMC10 Sensor Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Feedback device handling

  • Resolver coverage: The interface accepts both two-pole and multipole resolver feedback.
  • Excitation source: The module generates 4.1 V for the resolver winding.
  • Carrier range: Excitation operates from 5 to 16 kHz according to the controller timing.
  • Input purpose: Resolver signals are converted before they enter the DRIVE-CLiQ control path.

Resolver conversion limits

  • Transmission ratio: The SMC10 input is specified for a resolver ratio of 0.5.
  • Interpolation: Signal subdivision reaches 16384× with 14-bit resolution.
  • Frequency ceiling: Encoder frequency is limited to 2 kHz.
  • Timing dependency: The usable speed limit varies with resolver pole pairs and the current-controller clock cycle.

Feedback path boundaries

  • Encoder run: Resolver cabling may extend to 130 m within the specified interface conditions.
  • Control connection: DRIVE-CLiQ carries the evaluated feedback toward the SINAMICS controller.
  • Ordering scope: A DRIVE-CLiQ cable is not included with this SMC10 configuration.
  • Ground reference: The cabinet assembly provides an M4 protective-earth point.

Mechanical and supply integration

  • Enclosure class: IP20 / UL open type requires installation inside a suitable cabinet.
  • Module envelope: The hardware measures 30×150×111 mm.
  • Electronics supply: The 24 V DC input draws 0.20 A without the connected encoder.
  • Thermal load: Cabinet calculations must include up to 10 W of module power loss.
Description
The Siemens 6SL3055-0AA00-5AA3 is an SMC10 cabinet-mounted sensor module in the SINAMICS S120 encoder system. It evaluates resolver feedback from motors or external measuring points that do not provide a DRIVE-CLiQ interface.

Resolver processing in 6SL3055-0AA00-5AA3 supports both two-pole and multipole devices. The module supplies 4.1 V excitation at 5...16 kHz, works with a 0.5 transmission ratio, and converts the feedback with interpolation up to 16384× at 14-bit resolution.

Feedback entering 6SL3055-0AA00-5AA3 is carried to the drive control through DRIVE-CLiQ. The resolver cable may extend to 130 m, while the maximum encoder frequency is 2 kHz and depends on the resolver pole-pair count and the current-controller clock cycle.

For cabinet integration, 6SL3055-0AA00-5AA3 has IP20 / UL open-type protection and an M4 protective-earth connection. Its 24 V DC electronics draw 0.20 A without the encoder, and maximum module power loss is 10 W.
Alternative Names
6SL30550AA005AA3 6SL 3055-0AA00-5AA3 6SL3055 0AA00 5AA3 Siemens 6SL3055-0AA00-5AA3 SINAMICS S120 SMC10 SMC10 Sensor Module 6SL3055-OAAOO-5AA3 6SL3055-0AA00-5AA3 SMC10
Technical notes
Siemens 6SL3055-0AA00-5AA3 evaluates two-pole and multipole resolver signals and transfers feedback over DRIVE-CLiQ. The encoder cable limit is 130 m.
