        • Lifecycle status

          Discontinued / Obsolete by OEM
          Quotations, manuals, and SITOP PSU200M matching for 6EP1333-3BA00 can be coordinated by Apter Power.

        6EP1333-3BA00

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Siemens 6EP1333-3BA00 is a SITOP PSU200M 24 V DC, 5 A stabilized power supply for one- or two-phase AC input.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 6EP1333-3BA00
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6EP1333-3BA00

        • Manufacturer:
          Siemens
        • Part Number:
          6EP1333-3BA00
        • Product Family:
          Siemens SITOP
        • Product Type:
          SITOP PSU200M Stabilized Power Supply
        • Stock:
          1
        • Product Line:
          SITOP PSU200M
        • Input Phases:
          1-phase or 2-phase AC
        • Rated Input Ranges:
          120–230 V AC / 230–500 V AC
        • Permitted Input Windows:
          85–264 V AC / 176–550 V AC
        • Input Selection:
          De-energized 120/230 V selector switch
        • Rated Output:
          24 V DC, 5 A
        • Output Adjustment:
          24–28.8 V DC
        • Output Power:
          120 W
        • Operating Modes:
          Single or parallel characteristic
        • Overload Modes:
          Constant current or latching shutdown
        • Current Limitation:
          Approximately 5.5 A
        • Status LEDs:
          Green normal, yellow overload, red shutdown
        • DC Terminals:
          Two positive and two negative screw terminals
        • Mounting:
          EN 60715 35×7.5/15 DIN rail
        • Ambient Temperature:
          -25 to +70 °C with natural convection
        • Weight:
          2.646 lbs (1.2 kg)
        • Estimated shipping dimensions:
          14×15×9cm
        • Tariff Code:
          85044083
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Source Changeover Characteristic Switches Status Interpretation Output Coordination

        Features:

        • 6EP1333-3BA00 supplies a regulated 24 V DC rail at a 5 A rating.
        • A de-energized selector aligns the converter with the available AC source range.
        • Front switches choose single or parallel behavior and the overload response.
        The 6EP1333-3BA00 links a one- or two-phase feeder to an isolated DC load circuit.

        Its duplicated positive and negative terminals distribute one regulated output rather than independent channels.

        Selector position, characteristic switches and LED state provide three separate checks before load troubleshooting begins.

        The Siemens 6EP1333-3BA00 SITOP PSU200M Stabilized Power Supply may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Siemens 6EP1333-3BA00 SITOP PSU200M Stabilized Power Supply Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Matching the selector to the incoming AC feed

        • Low range: The first path accepts 85–264 V AC.
        • High range: The second path accepts 176–550 V AC.
        • Switch state: The factory position is 230 V and the selector is moved only while de-energized.
        • Two-phase feed: Line conductors use L1 and N/L2 with the protective conductor on PE.

        What switches A and B change

        • Switch A off: The hard characteristic holds voltage independently of output current in single operation.
        • Switch A on: The soft characteristic allows current sharing during parallel operation.
        • Switch B off: Constant-current mode reduces voltage as overload passes the current limit.
        • Switch B on: Latching mode shuts the supply down when overload pulls the output below 20 V.

        Separating normal, overload and shutdown states

        • Green indication: Output voltage is above 20 V ±0.5 V in normal operation.
        • Yellow indication: Overload has reduced the output below the 20 V threshold in constant-current mode.
        • Red indication: Latching shutdown or remote switch-off is present with the signaling module.
        • No green LED: The unit has no supply voltage at its input.

        Relating voltage adjustment to current and cooling

        • Factory setting: The output is supplied at 24 V DC.
        • Adjustment span: The potentiometer raises the setting as far as 28.8 V.
        • Current derating: Above 24 V, permitted output current falls by 4% for each additional volt.
        • Thermal alternative: The allowable ambient temperature may instead be reduced by 3 °C for each additional volt.
        Description
        Siemens 6EP1333-3BA00 is the 5 A member of the SITOP PSU200M modular power-supply family. It converts a one- or two-phase AC feed into a regulated, isolated 24 V DC output for the connected load, with two positive and two negative screw terminals distributing the DC rail.

        The input selector on 6EP1333-3BA00 separates the 120 V and 230–500 V source ranges and is moved only while the unit is de-energized. Depending on the selected range, the supply accepts 85–264 V AC or 176–550 V AC at 47–63 Hz before producing its rated output.

        Two front switches change how 6EP1333-3BA00 reacts to loading. Switch A chooses the hard single-unit characteristic or the soft characteristic for parallel operation, while switch B selects constant-current behavior or a latching shutdown when overload drives the output below 20 V.

        Normal, overload and shutdown conditions are separated on 6EP1333-3BA00 through green, yellow and red LEDs. The colors therefore distinguish available output from a current-limit event and from the latched state.

        The housing of 6EP1333-3BA00 snaps vertically onto an EN 60715 DIN rail. A 50 mm space above and below the unit maintains the cooling path for its -25 to +70 °C natural-convection range.
        Alternative Names
        Siemens 6EP1333-3BA00 6EP1333 3BA00 6EP13333BA00 SITOP PSU200M 6EP1333-3BA00 6EP1333-3BA00 24 V 5 A Siemens SITOP Modular 5 A PSU200M 1-2AC 24 VDC 5 A SITOP Modular 6EP1333 3BA00
        Technical notes
        Siemens 6EP1333-3BA00 uses a de-energized input-range selector and separate switches for parallel and overload characteristics. Verify their positions before energizing the connected 24 V load.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        When may the input-range selector on 6EP1333-3BA00 be moved?
        The selector on 6EP1333-3BA00 may be changed only while the power supply is de-energized; its factory position is 230 V.
        Which switch settings identify normal single-unit operation on 6EP1333-3BA00?
        The delivery state of 6EP1333-3BA00 has switch A off for the hard single-unit characteristic and switch B off for constant-current overload behavior.
        What changes when the output of 6EP1333-3BA00 is adjusted above 24 V?
        For 6EP1333-3BA00, output current must be reduced by 4% per additional volt, or allowable ambient temperature reduced by 3 °C per volt.
        How do the three LEDs on 6EP1333-3BA00 separate fault conditions?
        On 6EP1333-3BA00, green indicates normal output, yellow identifies overload in constant-current mode, and red identifies latching shutdown or remote switch-off.
        What must be provided on the line side of 6EP1333-3BA00?
        6EP1333-3BA00 requires the documented protective and disconnecting devices, with the protective conductor connected to its PE terminal.
        Can two 6EP1333-3BA00 supplies be connected for more output power?
        Yes. Two 6EP1333-3BA00 units may be connected in parallel when switch A selects the documented soft characteristic for current sharing.
