    Product manuals and system-matching guidance for 6DD1660-0BG0 are available through Apter Power.

6DD1660-0BG0

/ 4.9
1001 reviews | Need a Specific Revision?
For synchronous data exchange across SIMATIC TDC racks, the Siemens 6DD1660-0BG0 CP52IO communication module supplies four optical GlobalDataMemory interfaces.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6DD1660-0BG0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6DD1660-0BG0

  • Manufacturer:
    Siemens
  • Part Number:
    6DD1660-0BG0
  • Product Family:
    Siemens Simadyn
  • Product Type:
    Communication Module
  • Stock:
    1
  • Optical Interfaces:
    4 x Duplex SC
  • Transfer Rate:
    640 Mbit/s
  • Line Coding:
    8B/10B
  • Checksum:
    CRC
  • Status LEDs:
    8; transmit and receive indication for four interfaces
  • 5 V Current:
    3.0 A typical at 25 °C
  • 3.3 V Current:
    0.8 A typical at 25 °C
  • Power Loss:
    18 W typical
  • Fan Requirement:
    Required
  • Rack Space:
    1 slot
  • Weight:
    1.195 lbs (0.542 kg)
  • Estimated shipping dimensions:
    2x23.3x16cm
  • Tariff Code:
    85176200
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals GDM Role Fiber Channels LED States Rack Power

Features:

  • The CP52IO module connects SIMATIC TDC processor racks with the GlobalDataMemory system.
  • Four Duplex SC interfaces transfer GDM data at 640 Mbit/s with CRC checking.
  • Eight front LEDs separate transmit and receive activity for the four optical channels.
Siemens 6DD1660-0BG0 is the CP52IO member of the SIMATIC TDC GlobalDataMemory component group.

The module uses one rack slot and works as an optical interface board rather than the CP52M0 central memory board.

Its 20 mm front width fits the SIMATIC TDC rack format, while the specified power loss requires a rack fan.

The Siemens 6DD1660-0BG0 SIMATIC TDC CP52IO GDM Communication Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6DD1660-0BG0 SIMATIC TDC CP52IO GDM Communication Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Position in GlobalDataMemory

  • Central exchange: GDM permits CPU modules in networked racks to share data through central memory.
  • Interface position: CP52IO boards occupy rack slots beside the CP52M0 memory module.
  • Rack expansion: Each CP52IO provides the optical paths used to couple further racks.
  • Order identity: The 0BG0 suffix belongs to the CP52IO interface module, not the CP52M0 memory board.

Four Optical Data Paths

  • Connectors: X1 through X4 use Duplex SC fiber-optic connections.
  • Channel rate: Each documented optical interface operates at 640 Mbit/s.
  • Line coding: The data path uses 8B/10B coding.
  • Error check: CRC verifies the transferred telegrams.

Transmit and Receive Indication

  • LED pairs: Each of the four optical interfaces has one transmit and one receive indicator.
  • Green indication: H1, H3, H5, and H7 show data transmission.
  • Yellow indication: H2, H4, H6, and H8 show data reception.
  • Channel tracing: The front sequence keeps send and receive states aligned with interfaces 1 through 4.

Slot, Rails, and Cooling

  • Rack width: One slot accommodates the 20 mm wide module.
  • 5 V requirement: At 25 °C, the documented typical draw is 3.0 A.
  • Lower-voltage rail: The 3.3 V connection carries a documented typical draw of 0.8 A at 25 °C.
  • Thermal load: Typical power loss is 18 W and operation requires a fan.
Description
Siemens 6DD1660-0BG0 is the SIMATIC TDC CP52IO communication module that connects processor racks to GlobalDataMemory so CPU modules can exchange data through the central GDM structure.

Inside a GDM rack, 6DD1660-0BG0 occupies one slot beside the CP52M0 memory module, and each fitted CP52IO board extends the optical paths used to couple additional SIMATIC TDC racks.

Four Duplex SC channels on 6DD1660-0BG0 move data at 640 Mbit/s with 8B/10B coding and CRC checking; paired transmit and receive LEDs show activity for each optical interface.

The rack supplies 6DD1660-0BG0 from its 5 V and 3.3 V rails, while the module's 18 W typical power loss requires forced-air cooling in the installed frame.
Alternative Names
6DD16600BG0 6DD1660 0BG0 6DD 1660 0BG0 Siemens 6DD1660-0BG0 CP52IO CP52IO GDM interface module 6DD1660-0BG0 communication module 6DDI660-0BG0 6DD166O-OBG0
Technical notes
Siemens 6DD1660-0BG0 is the CP52IO board that adds four 640 Mbit/s optical interfaces to a SIMATIC TDC GlobalDataMemory rack.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can 6DD1660-0BG0 be separated from the CP52M0 memory board?
The 6DD1660-0BG0 is the CP52IO optical interface module; the CP52M0 is the separate central memory module in the GDM rack.
Which connection pattern belongs to 6DD1660-0BG0?
Four Duplex SC interfaces labeled X1 through X4 belong to 6DD1660-0BG0 and carry the GDM optical links.
Why does 6DD1660-0BG0 have eight front LEDs for four interfaces?
Each optical channel on 6DD1660-0BG0 has separate transmit and receive indication, producing four green and four yellow LEDs.
What rack resources must be reserved for 6DD1660-0BG0?
Reserve one SIMATIC TDC rack slot and forced-air cooling for 6DD1660-0BG0 because its typical power loss is 18 W.
Does 6DD1660-0BG0 use ordinary serial coding on its fiber links?
No. The optical links of 6DD1660-0BG0 operate at 640 Mbit/s with 8B/10B coding and CRC telegram checking.
