6ES7513-1AL01-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
As the central controller in a SIMATIC S7-1500 system, Siemens 6ES7513-1AL01-0AB0 executes the user program and coordinates PROFINET I/O through its integrated interface.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 6ES7513-1AL01-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7513-1AL01-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7513-1AL01-0AB0
  • Product Family:
    Siemens Simatic S7-1500
  • Product Type:
    SIMATIC S7-1500 CPU 1513-1 PN Central Processor
  • Stock:
    1
  • Program Work Memory:
    300 KB
  • Data Work Memory:
    1.5 MB
  • Load Memory:
    SIMATIC Memory Card, up to 32 GB
  • PROFINET Interface:
    IRT-capable interface with two-port switch
  • Bit Operation Time:
    40 ns
  • Integrated Display:
    Commissioning and diagnostic display
  • Supply Voltage:
    24 V DC; permissible range 19.2 to 28.8 V
  • Current Consumption:
    0.7 A rated
  • Power Loss:
    5.7 W typical
  • Protection Rating:
    IP20
  • Weight:
    1.1244 lbs (0.51 kg)
  • Estimated shipping dimensions:
    15.4x15x4.6cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Memory Structure PROFINET Cycle Display Diagnostics Commissioning Match

Features:

  • Separate program and data work memory support the CPU execution model.
  • The integrated PROFINET interface includes an IRT-capable two-port switch.
  • A front display presents operating and diagnostic information at the controller.
The CPU reads the process image, executes the user program and writes the resulting output image.

Network timing and device assignments come from the TIA Portal hardware configuration.

Load memory remains on the SIMATIC Memory Card while the active program executes in work memory.

The Siemens 6ES7513-1AL01-0AB0 SIMATIC S7-1500 CPU 1513-1 PN may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7513-1AL01-0AB0 CPU 1513-1 PN Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Relating load memory, work memory and runtime data

  • Program area: Executable blocks use the dedicated program work memory.
  • Data area: DB contents and runtime values use the separate data work memory.
  • Load path: The SIMATIC Memory Card stores the project data loaded by the CPU.
  • Replacement step: Card contents and firmware must agree with the replacement processor.

Connecting controller execution with distributed I/O updates

  • Two-port switch: Both RJ45 ports belong to the integrated PROFINET interface.
  • IRT scheduling: Configured send clocks coordinate time-sensitive network traffic.
  • Device assignment: PROFINET names bind configured stations to physical devices.
  • Diagnostic path: Interface and device faults enter the CPU diagnostic system.

Using the front display before opening the engineering project

  • Operating state: The display shows the current CPU mode and status.
  • Message access: Diagnostic events can be reviewed locally at the controller.
  • Interface data: Basic address and network information assists field identification.
  • Project confirmation: Online TIA Portal diagnostics provide the complete fault context.

Checking the dependencies that belong to this CPU execution

  • Order number: Read the complete 1AL01 suffix on the installed processor.
  • Firmware: Confirm compatibility between CPU firmware and the saved project.
  • Memory card: Use the project card prepared for the intended controller configuration.
  • Network identity: Restore the documented PROFINET name and IP parameters.
Description
At the center of a SIMATIC S7-1500 station, Siemens 6ES7513-1AL01-0AB0 is the CPU 1513-1 PN that executes control logic, maintains the process image and coordinates connected automation devices. Its separate program and data work-memory areas keep executable code distinct from runtime values.

The integrated PROFINET interface of 6ES7513-1AL01-0AB0 uses a two-port switch to connect the controller, engineering station and distributed I/O on the configured Ethernet network. IRT scheduling, device names and update times are defined in the hardware project rather than by the physical port alone.

A SIMATIC Memory Card supplies the load-memory path for 6ES7513-1AL01-0AB0, while the CPU copies the required program blocks into working memory for execution. The removable card therefore belongs to the commissioning and replacement workflow, together with the TIA Portal project and firmware package.

Operating and diagnostic information appears on the integrated display of 6ES7513-1AL01-0AB0, where technicians can read module states and basic interface information without opening the controller program. Detailed fault analysis still follows the diagnostic buffer and online project so that a network or module error is not mistaken for a processor failure.
Alternative Names
6ES75131AL010AB0 6ES7 513-1AL01-0AB0 6ES7513 1AL01 0AB0 Siemens 6ES7 513-1AL01-0AB0 6ES7-513-1AL01-0AB0 6ES7513-1AL01-0ABO 6ES75I3-1AL01-0AB0 6ES7513 1AL01 0ABO
Technical notes
The SIMATIC Memory Card, firmware and TIA Portal hardware configuration must correspond to Siemens 6ES7513-1AL01-0AB0 before its program and PROFINET device name are restored.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can the program be moved to a replacement 6ES7513-1AL01-0AB0?
For 6ES7513-1AL01-0AB0, use the verified TIA Portal project and SIMATIC Memory Card after confirming the target CPU firmware and complete order number.
Why does Siemens 6ES7513-1AL01-0AB0 remain inaccessible even when the link LEDs are on?
A live port only confirms the physical link; Siemens 6ES7513-1AL01-0AB0 also needs the configured PROFINET device name, IP settings and reachable engineering route.
What does the display help diagnose on 6ES7513-1AL01-0AB0?
The front display of 6ES7513-1AL01-0AB0 exposes CPU state, diagnostic messages and basic interface data before deeper checks are made in TIA Portal.
Can a memory card from another S7-1500 CPU be inserted into 6ES7513-1AL01-0AB0 without review?
No. The project on the card must be checked for 6ES7513-1AL01-0AB0 hardware, firmware and configured modules before startup.
Which memory limit matters when sizing an application for 6ES7513-1AL01-0AB0?
Separate the 300 KB program area from the 1.5 MB data area when estimating the application for 6ES7513-1AL01-0AB0; load-memory capacity alone does not remove either work-memory limit.
Is 6ES7513-1AL02-0AB0 automatically interchangeable with 6ES7513-1AL01-0AB0?
Although Siemens identifies 6ES7513-1AL02-0AB0 as a successor, migration from 6ES7513-1AL01-0AB0 still requires project, firmware and hardware-compatibility review.
