6ES7315-2EH13-0AB0 is a SIMATIC S7-300 CPU 315-2 PN/DP central processing unit with 256 KB working memory, featuring 1 MPI/DP interface (12 Mbit/s), 1 Ethernet PROFINET interface, and requiring a micro memory card.
Discover how Apter Power helps customers source hard-to-find automation parts,overcome delivery challenges and keep production moving.VIEW OUR SUCCESS STORIES >>
Technical specifications for 6ES7315-2EH13-0AB0
Manufacturer:
Siemens
Part Number:
6ES7315-2EH13-0AB0
Product Family:
Siemens Simatic S7-300
Firmware version:
V2.6
Engineering with:
Programming package STEP 7 V5.4 SP2
Supply voltage / Rated value (DC):
24 V
permissible range, lower limit (DC):
20.4 V
permissible range, upper limit (DC):
28.8 V
external protection for power supply lines (recommendation):
2 A min.
Input current / Current consumption (rated value):
650 mA
Current consumption (in no-load operation), typ.:
100 mA
Inrush current, typ.:
2.5 A
Weight:
0.5 kg
Estimated shipping dimensions:
8x12.3x12.4cm
Tariff Code:
8537101190
Country of origin:
Germany
Place of shipment:
Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
The 6ES7315-2EH13-0AB0 is a CPU 315-2 PN/DP central processing unit from the SIMATIC S7-300 series, specifically designed for industrial automation control, offering powerful processing capabilities and stable performance. This module provides 256 KByte of working memory, meeting the requirements of complex control tasks and data processing, ensuring efficient system operation.
The 6ES7315-2EH13-0AB0 is equipped with two key communication interfaces. First, the MPI/DP interface supports a transmission speed of up to 12 Mbit/s, enabling efficient data exchange with distributed I/O devices and other S7 series modules. Second, the module supports an Ethernet Profinet interface, allowing high-speed connection to industrial networks and remote data access.
We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
Trust Guaranteed
Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
Expertise
Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.
FAQS
The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What communication interfaces does the 6ES7315-2EH13-0AB0 have?
It has two key communication interfaces: 1.MPI/DP interface with a transmission speed of up to 12 Mbit/s, for efficient data exchange with distributed I/O devices and other S7 series modules. 2.Ethernet Profinet interface for high-speed connection to industrial networks and remote data access.
Is any additional component required to use the 6ES7315-2EH13-0AB0?
Yes, a Micro Memory Card is required to store programs, parameters, and system data, ensuring control system reliability and data integrity.
Where is the 6ES7315-2EH13-0AB0 commonly used?
This module is widely applied in various automation control scenarios and serves as a core processing unit of the S7-300 series.
