Features:
- Central Processing Unit Bridging Control Logic and Distributed I/O Networks
- Integrates Multi-Protocol Communication with High-Speed Data Processing
- Functions in Coordination with SIMATIC S7-300 Modules and PROFINET/PROFIBUS Devices
The SIEMENS 6ES7318-3EL01-0AB0 serves as the Central Processing Unit in a SIMATIC S7-300 rack, providing reliable execution of control programs for all modules within the system. It continuously processes complex automation tasks using its 2 MB work memory and distributes control commands through the rack backplane to support steady-state operation of all signal modules and function modules. Seamless protocol integration is standard with the 6ES7318-3EL01-0AB0, and its three independent communication interfaces enable simultaneous operation across MPI/DP, PROFIBUS DP, and PROFINET networks without interruption.
The 6ES7318-3EL01-0AB0 provides essential processing functions common to the entire rack, and is a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One 6ES7318-3EL01-0AB0 CPU is required per rack as the central controller. The 6ES7318-3EL01-0AB0 occupies a standard slot in the rack and is always located in the designated CPU position.
For expanded communication applications, the 6ES7318-3EL01-0AB0 leverages its 2nd interface as a DP master or slave and its 3rd interface as a PROFINET controller with integrated switch functionality. In addition to standard single-network operation, the multi-interface configuration also performs simultaneous protocol handling. The 6ES7318-3EL01-0AB0 dual-protocol configuration executes data exchange using the internal circuitry specified in the CPU communication options.
The 6ES7318-3EL01-0AB0 SIEMENS Central Processing Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6ES7318-3EL01-0AB0 Central Processing Unit Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6ES7318-3EL01-0AB0 Central Processing Unit Specs
General
- Manufacturer SIEMENS
- Model 6ES7318-3EL01-0AB0
- Condition New Original ready stock
- Product Family 6ES7390-1AE80-0AA0,6ES7307-1EA01-0AA0
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Demanding Automation Tasks: Used for large-scale, cross-industry automation in series machines, special machines, and complex plant construction.
- Distributed Network Control: Functions as a central controller in production lines, managing distributed I/O via PROFIBUS and PROFINET.
- Time-Critical Synchronization: Supports Isochronous Mode on PROFIBUS or PROFINET for highly synchronized, fast-cycle processes.
- Intelligent Subsystems: Operates as a PROFINET I-Device to connect seamlessly under other SIMATIC or non-Siemens master controllers.
- Plant-to-Office Communications: Leverages an integrated web server and Component-Based Automation (CBA) to bridge field devices with enterprise networks.
- Rated Voltage: Requires a 24 V DC power supply with a permissible input range between 19.2 V DC and 28.8 V DC.
- Current & Power: Draws a rated current consumption of 1,250 mA, with a typical power loss dissipation of 14 W.
- Memory Constraints: Relies on a plug-in SIMATIC Micro Memory Card (MMC) up to 8 MB for load memory and data retention.
- Protection Standards: Must be mounted inside a protective industrial enclosure/cabinet to safe-keep against dust, moisture, and conductive contaminants.
- Rail Mounting: Hooks directly onto a standard S7-300 DIN rail and secures mechanically via built-in locking screws.
- Bus Connectivity: Integrates with adjacent I/O modules using rear-facing S7 backplane bus connectors.
- Software Configuration: Programmed and configured using STEP 7 V5.5 (or higher) or via the TIA Portal framework.
