  • Lifecycle status

    Discontinued / Obsolete by OEM
    For 8440-1934, Apter Power offers quotations, product manuals, and configuration matching.

8440-1934

/ 4.9
1001 reviews | Need a Specific Revision?
Woodward 8440-1934 is an easYgen-3500-5/P1 front-panel genset controller with display and 5 A current-transformer inputs.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 8440-1934
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8440-1934

  • Manufacturer:
    Woodward
  • Part Number:
    8440-1934
  • Product Family:
    Woodward
  • Product Type:
    easYgen-3500-5/P1 Front-Panel Genset Controller
  • Stock:
    1
  • Current Inputs:
    5 A CT inputs
  • Supply Range:
    8–40 V DC for 12/24 V systems
  • Discrete Alarm Inputs:
    12 configurable inputs, 9 freely configurable
  • Discrete Outputs:
    Up to 12 configurable outputs
  • Analog Inputs:
    Three configurable FlexIn channels
  • Analog Outputs:
    Two configurable channels
  • CAN Interfaces:
    Three configurable CANopen or J1939 interfaces
  • Serial Interfaces:
    One RS-232 and one RS-485 Modbus RTU slave interface
  • Event Recorder:
    300 entries with real-time clock and battery backup
  • Display:
    5.7-inch 320 × 240 color graphic LCD with softkeys
  • Weight:
    4.784 lbs (2.17 kg)
  • Estimated shipping dimensions:
    28.2x21.7x9.9cm
  • Tariff Code:
    8537109090
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Controller I/O Breaker Control Communications Panel Setup

Features:

  • easYgen-3500-5/P1 front-panel genset controller
  • 5 A current-transformer inputs with configurable I/O
  • CANopen, J1939 and Modbus RTU communication
Woodward 8440-1934 combines the easYgen-3500-5/P1 controller, color display and 5 A current-input option in one front-panel unit.

The configurable inputs and outputs on 8440-1934 handle alarm states, analog measurements and programmed control actions.

Three CAN interfaces and the RS-232/RS-485 path separate CANopen or J1939 traffic from Modbus RTU communication on 8440-1934.

The Woodward 8440-1934 easYgen-3500-5/P1 Front-Panel Genset Controller may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Woodward 8440-1934 easYgen-3500-5/P1 Front-Panel Genset Controller Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Configurable Controller I/O

  • Alarm inputs: Twelve configurable inputs, nine freely configurable
  • Discrete outputs: Up to twelve configurable outputs
  • Analog channels: Three FlexIn inputs and two analog outputs

Generator and Breaker Functions

  • Controller package: easYgen-3500-5/P1
  • Current sensing: 5 A current-transformer inputs
  • DC supply: 8-40 V DC for 12 V and 24 V systems

Communication Interfaces

  • CAN channels: Three configurable CAN interfaces
  • CAN protocols: CANopen or J1939
  • Serial path: RS-232 and RS-485 for Modbus RTU slave communication

Front Panel and Event Review

  • Display: 5.7-inch 320 x 240 color graphic LCD with softkeys
  • Event storage: 300 timestamped entries
  • Clock support: Battery-backed real-time clock
Description
Woodward 8440-1934 is the easYgen-3500-5/P1 genset controller, combining a front-panel color display with 5 A current-transformer inputs for generator, mains and breaker-control functions.

Package P1 on 8440-1934 provides twelve configurable alarm inputs, up to twelve configurable outputs, three flexible analog inputs and two analog outputs. These channels let the controller receive engine and electrical conditions while driving the programmed operating sequence.

Communication on 8440-1934 is divided among three configurable CAN interfaces and one RS-232/RS-485 Modbus RTU path. The same control stores 300 timestamped events, so operating changes and protection responses can be reviewed against the real-time clock.

For installation, 8440-1934 uses the plastic front-panel housing measuring 282 × 217 × 99 mm. Its 8–40 V DC supply range serves 12 V and 24 V systems, while the documented maximum device weight is 2.17 kg.
Alternative Names
Woodward 8440-1934 Genset Controller easYgen-3500-5/P1 8440-1934 8440 1934 Generator Controller Woodward easYgen 3500 P1 easYgen-3500 5A P1 Controller 8440-1934 Front Panel Controller Woodward 3500-5 P1 Control easYgen 3000 Series 8440-1934
Technical notes
Woodward 8440-1934 is the 5 A CT, Package P1 version of the easYgen-3500 controller. Its front-panel housing includes the color display and softkeys.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which identity checks prevent Woodward 8440-1934 from being confused with another easYgen-3500 variant?
Woodward 8440-1934 is the easYgen-3500-5/P1 front-panel version with 5 A current-transformer inputs; confirm both 5/P1 and the 5 A input option.
When allocating alarm wiring, why can Woodward 8440-1934 not treat all twelve inputs as freely assignable?
Woodward 8440-1934 has twelve configurable alarm inputs, but only nine are described as freely configurable, so the remaining input roles must be preserved in the I/O plan.
Which communication duties can be separated across Woodward 8440-1934 interfaces?
Three configurable CAN ports on Woodward 8440-1934 carry CANopen or J1939 traffic, while its RS-232 and RS-485 path serves Modbus RTU slave communication.
How should analog sensing and analog commands be divided on Woodward 8440-1934?
Woodward 8440-1934 receives three configurable FlexIn analog channels and provides two configurable analog outputs, so measurement sources and commanded outputs require separate channel assignments.
Why should the real-time clock be checked when reviewing a Woodward 8440-1934 event history?
The 300-entry recorder in Woodward 8440-1934 timestamps operating and protection events with its battery-backed real-time clock, allowing sequence review only when clock time is valid.
