The ABB TC625 3BSE002224R1 is an AF100 coaxial modem for Advant Master systems, enabling communication between controllers and field devices via coaxial bus.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for TC625 3BSE002224R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for TC625 3BSE002224R1

  • Manufacturer:
    ABB
  • Part Number:
    TC625 3BSE002224R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Communication Module
  • Stock:
    5
  • Communication Protocol:
    AF100 (Advant Fieldbus 100)
  • Medium:
    Coaxial bus
  • WEEE Category:
    5. Small Equipment (No External Dimension > 50 cm)
  • RoHS Status:
    Exempted (2011/65/EU Article 2(4)(c),(e),(f),(j))
  • Compatible Controllers:
    AC410, AC460, Advant Controller 410/450/450RMC
  • Software Platforms:
    Advant OCS with Master SW, MOD 300 SW
  • SCIP Registration:
    12be43f6-3616-4362-85d3-73598a6fc016 (Sweden)
  • Used In Kits:
    CI522AK01, AK02, AK03, AK11, AK12, AK13, AK21, AK22, AK23
  • Weight:
    0.68 kg
  • Estimated shipping dimensions:
    4.4x15x17.6cm
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Certifications Compatibility

Features:

  • Enables reliable coaxial bus communication for Advant Master process control systems.
  • Supports AC410, AC460, Advant Controller 410/450/450RMC across multiple versions.
  • Exempted from RoHS Directive 2011/65/EU under specific articles for legacy compliance.
The TC625 3BSE002224R1 serves as an AF100 coaxial modem, providing robust communication between Advant Master controllers and field devices . It operates on a coaxial bus medium, ensuring reliable data transfer in industrial automation environments. The module is a critical component in Advant OCS with Master SW and MOD 300 SW platforms . It is used in various AF100 communication interface kits including CI522AK01 through CI522AK23, making it versatile for different system configurations.

The TC625 3BSE002224R1 is compatible with a wide range of ABB controllers, including AC410, AC460, Advant Controller 410 (version 1.5), Advant Controller 450 (version 2.3), and Advant Controller 450RMC (version 2.x) . This extensive compatibility allows the TC625 3BSE002224R1 to be deployed across various system architectures without requiring major hardware changes. Whether used in legacy installations or modernized systems, the TC625 3BSE002224R1 provides consistent performance and reliable data transfer, making it a versatile solution for industrial automation communication needs.

The TC625 3BSE002224R1 is exempted from the scope of the RoHS Directive 2011/65/EU as provided in Article 2(4)(c), (e), (f), and (j) . This exemption allows the use of certain materials critical for the module's long-term reliability in industrial applications. The TC625 3BSE002224R1 is classified under WEEE Category 5 (Small Equipment) and carries SCIP registration number 12be43f6-3616-4362-85d3-73598a6fc016 in Sweden .

The TC625 3BSE002224R1 ABB Communication Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

ABB TC625 3BSE002224R1 Communication Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB TC625 3BSE002224R1 Communication Module Specs

General

  • Manufacturer ABB
  • Model TC625 3BSE002224R1
  • Condition New Original ready stock
  • Product Family TC630 3BSE002253R1,TC520 3BSE001449R1,TC530 3BUR000101R1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Pulp & Paper Mills: Interconnects distributed Advant Controllers managing continuous-run paper machines, chemical pulping lines, and rolling sections.
  • Metal Processing & Rolling Mills: Facilitates fast cyclic data exchanges between master controllers and localized motor drive systems to maintain tight mill tension control.
  • Chemical & Petrochemical Refineries: Manages safety-interlocked communication networks linking hazardous process zones to central control systems.
  • Thermal Power Generation: Embedded in old-to-new migration architectures for boiler control, turbine monitoring, and balance of plant utilities.
  • CE Marking: Fully compliant with European Union Directives, including low voltage and industrial safety mandates.
  • EMC Compliance (EN 61000-6-2 / EN 61000-6-4): Certified for extreme industrial electromagnetic compatibility, ensuring resistance to voltage spikes and high frequency ambient noise caused by surrounding variable speed drives.
  • Shock and Vibration (IEC 60068-2): Structurally validated to withstand sustained structural mechanical vibrations common in heavy production facilities.
  • Environmental/RoHS: Manufactured following hazardous substance guidelines to ensure safe operation and disposal parameters within global industrial standards.
  • Advant Fieldbus 100 (AF100): Strictly optimized to operate over AF100 coaxial cabling infrastructures, supporting standard network configurations and deterministic cyclic communication.
  • Advant Controller 400 Series: Directly compatible as a modular plug-in transceiver or sub-rack modem for classic AC 410 and AC 450 processing stations.
  • S800 I/O Ecosystem: Connects seamlessly with remote S800 I/O clusters utilizing CI810 or CI820 AF100 fieldbus communication interfaces.
  • System 800xA Migration: Interoperable with modern ABB System 800xA platforms through specialized connectivity servers (e.g., CI857 or AC 800M controllers acting as a bridge). This allows facilities to upgrade their software environments while retaining operational TC625-driven coaxial cable field networks.
Description
The ABB TC625 3BSE002224R1 is a communication module designed for the Advant Master process control system, specifically serving as an AF100 coaxial modem. This module enables seamless data exchange between controllers and field devices via a coaxial bus network. The TC625 3BSE002224R1 is an essential component for connecting Advant Controller 410, 450, and 450RMC systems.

The ABB TC625 3BSE002224R1 is exempted from the scope of 2011/65/EU (RoHS) as provided in Article 2(4)(c), (e), (f), and (j). The TC625 3BSE002224R1 is compatible with Advant OCS with Master SW and MOD 300 SW platforms.

The ABB TC625 3BSE002224R1 includes SCIP (Substances of Concern In Products) registration 12be43f6-3616-4362-85d3-73598a6fc016 (Sweden). The TC625 3BSE002224R1 is part of the AC 400 communication module family and is listed as an Advant Fieldbus 100 Interface.
Alternative Names
TC625 3BSEOO2224R1 TC625 3BSE002224RI TC630 3BSE002253R1 DSTC170 57520001-BK NTCS04 TC520 TC520 3BSE001449R1 BSTC176 SE98424140
Technical notes
The ABB TC625 3BSE002224R1 is an AF100 coaxial modem for Advant Master systems, enabling communication between controllers (AC410, AC460, Advant 410/450) and field devices.RoHS-exempted, WEEE Category 5. Used in CI522AK series kits. Essential spare part for legacy ABB DCS.
