ABB ICDG32L1 ICDG32L1B GJR5251400R0101 is a 24 VDC CS31 remote I/O module with 16 inputs, 8 transistor outputs, and 8 configurable I/O points.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for ICDG32L1 ICDG32L1B GJR5251400R0101
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ICDG32L1 ICDG32L1B GJR5251400R0101

  • Manufacturer:
    ABB
  • Part Number:
    ICDG32L1 ICDG32L1B GJR5251400R0101
  • Product Family:
    ABB Procontic
  • Product Type:
    CS31 Remote I/O Module
  • Stock:
    1
  • Weight:
    0.45 kg
  • Estimated shipping dimensions:
    12x14x8.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals I/O Configuration CS31 Integration Service Checks Product Applications

Features:

  • Mixed-I/O role: fixed inputs, transistor outputs, and configurable points share one CS31 station.
  • Order identity: the GJR5251400R0101 reference distinguishes the documented ICDG 32 L1 hardware.
  • Commissioning boundary: station address and flexible-point direction must match the controlled I/O record.
This hardware consolidates several discrete-I/O roles, so replacement work must treat the channel allocation as part of the station identity.

Using the complete ICDG and GJR markings keeps quotation and document review tied to the intended module rather than a similar CS31 device.

A successful exchange restores the recorded address and I/O direction before field circuits are returned to service.

Apter Power provides exact-model document review, quotation, and procurement support for the ABB ICDG32L1 ICDG32L1B GJR5251400R0101 CS31 Remote I/O Module.
ABB ICDG32L1 ICDG32L1B GJR5251400R0101 CS31 Remote I/O Module Manuals,Datasheets,Link
Important Notice: No qualified exact-model English PDF is attached. Use the complete product model in every document request.
  • Fixed inputs: 16 digital input channels for 24 VDC signals.
  • Fixed outputs: 8 transistor output channels.
  • Flexible points: 8 channels configurable for input or output use.
  • Configuration record: preserve the assigned direction and terminal purpose of each flexible point.
  • Fieldbus: connect the module within the documented ABB CS31 system bus.
  • Station identity: retain the installed address and controller mapping.
  • Supply: verify 24 VDC polarity and common wiring.
  • Program boundary: reconcile physical channels with the approved controller configuration.
  • Pre-removal: label terminals, photograph wiring, and save the I/O allocation.
  • Output loads: check type, polarity, and current before reconnecting transistor outputs.
  • Diagnostics: investigate bus, supply, and channel indications before replacing a second module.
  • Acceptance: prove each commanded output and monitored input through the controller.
  • CS31 remote I/O: distributed discrete input and transistor-output stations.
  • Mixed I/O cabinets: installations using both fixed and configurable 24 VDC points.
  • Exact-order maintenance: replacement where GJR5251400R0101 is specified in the controlled parts record.
Description
ICDG32L1 ICDG32L1B GJR5251400R0101 is an ABB Procontic CS31 remote I/O module for 24 VDC systems. ABB documents 16 digital inputs, 8 transistor outputs, and 8 channels configurable as inputs or outputs.

The complete GJR order reference distinguishes ICDG32L1 ICDG32L1B GJR5251400R0101 within the CS31 hardware family. Its station address and flexible-channel allocation belong to the controller design, so module identity and configuration records must be reviewed together.

When replacing ICDG32L1 ICDG32L1B GJR5251400R0101, retain the complete order reference and reconcile all fixed and configurable channels with the controller program. Confirm supply polarity, output load behavior, bus addressing, and the terminal record before energizing the station.
Alternative Names
ICDG32L1 ICDG32L1B GJR5251400R0101 GJR5 2514 00 R0101
Technical notes
The configurable points are the critical boundary for ICDG32L1 ICDG32L1B GJR5251400R0101: a module can power up while its input/output directions still disagree with the controller image. Preserve the station address and channel allocation, reconcile every flexible point with the terminal record, and stop startup if either record is incomplete.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Before removing ICDG32L1 ICDG32L1B GJR5251400R0101 from a mixed-I/O CS31 station, which records prevent a channel-allocation error?
Capture the station address, terminal schedule, fixed input and output circuits, and the configured direction of every flexible point. The exchange should stop if those records cannot be reconciled with the controller image.
If flexible points on ICDG32L1 ICDG32L1B GJR5251400R0101 disagree with the controller image after exchange, what should commissioning staff do?
Do not force the field wiring to fit the new indication. Compare the approved program, channel-direction assignment, terminal record, and original station evidence, then correct the documented configuration before startup.
When ICDG32L1 ICDG32L1B GJR5251400R0101 is powered but absent from the CS31 bus, which checks should precede another hardware swap?
Start with supply polarity and common reference, then inspect bus continuity, station addressing, connector seating, and controller diagnostics. Replace more hardware only after those conditions match the station record.
How should a technician diagnose a commanded load that remains off after ICDG32L1 ICDG32L1B GJR5251400R0101 replacement?
Trace the commanded channel from the controller image to the transistor-output terminal, load supply, polarity, common wiring, and field device. A mismatch in mapping or load wiring should be corrected before the module is blamed.
Why must a sourcing request for ICDG32L1 ICDG32L1B GJR5251400R0101 include both the ICDG and GJR markings?
The combined markings tie the request to the documented hardware order reference rather than a visually similar CS31 module. Include clear label photos and the installed station record so that identity can be checked before quotation.
What acceptance test should close an ICDG32L1 ICDG32L1B GJR5251400R0101 exchange in an operating CS31 cabinet?
Prove every monitored input, commanded transistor output, and configured flexible point through the controller while confirming the retained station address. Any point that differs from the approved I/O schedule requires investigation before handover.
