        07DI92

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB 07DI92 is a remote CS31 digital input module with 32 inputs arranged in electrically separated groups for 24 V DC field signals.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 07DI92
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 07DI92

        • Manufacturer:
          ABB
        • Part Number:
          07DI92
        • Product Family:
          ABB Procontic
        • Product Type:
          Digital input module
        • Stock:
          1
        • Input type:
          32 digital inputs
        • Nominal input voltage:
          24 V DC
        • Isolation:
          Four input groups isolated from each other and from the rest of the unit
        • System bus:
          CS31
        • Address allocation:
          Two digital input addresses on the CS31 system bus
        • Bus isolation:
          System bus connection electrically isolated from the rest of the unit
        • Front indication:
          32 green input LEDs and red error LED
        • Test control:
          Front test button
        • Mounting:
          15 mm DIN rail or 4 screws
        • Dimensions:
          12 × 14 × 8.5 cm
        • Weight:
          0.3 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Signal Groups CS31 Addressing Installation Application
        • CS31 digital input module
        • Grouped 24 V DC field sensing
        • Electrically separated input groups

        07DI92 is an ABB CS31 digital input module for grouped 24 V DC field signals.

        Its isolated group arrangement supports separated field commons and a documented CS31 address map.

        Before installation or replacement, verify the address assignment, group wiring, terminal labels, mounting, and controller project.

        Availability, condition, price, and shipping time for 07DI92 are confirmed during quotation.

        ABB 07DI92 Digital Input Module Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • 32 digital inputs accept 24 V DC field signals in four groups.
        • The four input groups are electrically isolated from one another and from the rest of 07DI92.
        • Thirty-two green LEDs show input status; a red LED reports errors and the front test button checks the indicators.
        • 07DI92 occupies two consecutive digital input addresses on the CS31 system bus.
        • The address DIL switch is beneath the right-side slide cover; switches 2–7 set the address and switches 1 and 8 must remain OFF.
        • The module reads the switch setting only during initialization, so an address change takes effect only after a new initialization.
        • Mount 07DI92 on a 15 mm DIN rail or with four M4 screws.
        • Install it vertically with the connectors pointing upward and downward.
        • Keep cable ducts and other cabinet components clear so natural-convection cooling is not obstructed.
        • Remote acquisition of 32 on/off 24 V DC field signals on the CS31 system bus.
        • Distributed digital-input stations requiring four electrically isolated input groups.
        • CS31 installations using 07 KR 91 or 07 KT 92, 07 KT 93, or 07 KT 94 basic units as bus masters.
        Description
        07DI92 is an ABB CS31 digital input module with 32 digital inputs for 24 V DC field signals.

        The inputs are arranged in four groups, with electrical separation between the groups and from the rest of the unit; the module occupies two digital input addresses on the CS31 system bus.

        Installation uses a 15 mm DIN rail or four screws, and the official drawing gives the body dimensions as 12 × 14 × 8.5 cm.
        Alternative Names
        07 DI 92 07DI92 07-DI-92 GJR5252400R0101 GJR 525 2400 R0101 ABB 07DI92 ABB 07 DI 92 07DI92 GJR5252400R0101
        Technical notes
        07DI92 installation requires a CS31 address, 24 V DC wiring, isolated input groups, and matching field terminals. Check the group commons and project map before returning the module to service.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What signal wiring should be checked before installing ABB 07DI92?
        Confirm the 24 V DC source, the common arrangement for each isolated group, field polarity, and the terminal wiring shown for the CS31 installation.
        How should ABB 07DI92 be addressed in a CS31 project?
        Reserve the two digital input addresses assigned to the module and compare them with the saved CS31 I/O map before commissioning.
        Can ABB 07DI92 inputs be wired as one common group?
        The module has four electrically separated input groups, so the field wiring must preserve the intended group boundaries rather than shorting all commons together.
        What should be retained before replacing ABB 07DI92?
        Retain the CS31 address assignment, group wiring, terminal labels, diagnostic settings, and verified controller project.
        What is the purpose of the test control on ABB 07DI92?
        The front test control supports service checking of the module; it does not replace verification of the actual field circuits and controller image.
        Can ABB 07DI92 be mounted without a special cabinet rail?
        ABB documents mounting on a 15 mm DIN rail or with four screws, subject to cabinet and wiring clearances.
        Why might ABB 07DI92 show an input error after replacement?
        A wrong CS31 address, incorrect group common, missing 24 V DC, or wiring across an isolation boundary can prevent valid input data.
