DSQC 643 3HAC024488-001

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DSQC 643 3HAC024488-001 is an IRC5 panel board used with documented M2004 Flexible and Design 2006 controller covers and connector kit 3HAC021377-001.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for DSQC 643 3HAC024488-001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSQC 643 3HAC024488-001

  • Manufacturer:
    ABB
  • Part Number:
    DSQC 643 3HAC024488-001
  • Product Family:
    ABB Robots
  • Product Type:
    IRC5 Panel Board
  • Stock:
    1
  • Controller family:
    IRC5
  • M2004 Flexible cover:
    3HAC020869-001
  • Design 2006 Dual/Single cover:
    3HAC024476-001
  • Connector kit:
    3HAC021377-001
  • Connector positions:
    X8, X14 and X17
  • Gross volume:
    4.851 dm³
  • Dimensions:
    29.2 × 26.2 × 3.5 cm
  • Weight:
    0.34 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cover Selection Connector Planning Installation Control Application
  • IRC5 panel board identified by ABB product ID 3HAC024488-001
  • Documented for M2004 Flexible and Design 2006 Dual or Single controller arrangements
  • Uses connector kit 3HAC021377-001 at X8, X14 and X17

DSQC 643 3HAC024488-001 is the ABB panel board documented as a replacement component within the IRC5 controller structure. Selection must use the complete product ID rather than the DSQC designation or physical appearance alone.

ABB associates cover 3HAC020869-001 with the IRC5 M2004 Flexible arrangement and cover 3HAC024476-001 with the IRC5 Design 2006 Dual and Single arrangements. The installed controller design and cover number must therefore be confirmed before ordering.

ABB identifies connector kit 3HAC021377-001 for positions X8, X14 and X17 and specifies a product net weight of 0.34 kg. Record the existing cover and all three connector positions before removing the installed panel board.

Availability, condition, price, and shipping time for DSQC 643 3HAC024488-001 are confirmed during quotation.

ABB DSQC 643 3HAC024488-001 IRC5 Panel Board Datasheet, Manuals, and Support Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Identify the installed controller design before ordering the panel board.
  • Match cover 3HAC020869-001 only to the documented M2004 Flexible arrangement.
  • Match cover 3HAC024476-001 to the documented Design 2006 Dual or Single arrangement.
  • Record the existing X8 connection before board removal.
  • Record the existing X14 connection and cable route.
  • Record the existing X17 connection and verify connector kit 3HAC021377-001.
  • Keep the removed board and replacement labels available for side-by-side comparison.
  • Seat the documented cover without forcing cables or connectors.
  • Complete the appropriate IRC5 controller checks before returning the robot to operation.
  • IRC5 M2004 Flexible controller panels using cover 3HAC020869-001
  • IRC5 Design 2006 Dual controller panels using cover 3HAC024476-001
  • IRC5 Design 2006 Single controller panels using cover 3HAC024476-001
Description
DSQC 643 3HAC024488-001 is the ABB panel board identified for specific IRC5 controller constructions.

ABB associates it with cover 3HAC020869-001 for IRC5 M2004 Flexible and cover 3HAC024476-001 for IRC5 Design 2006 Dual and Single arrangements.

Connector kit 3HAC021377-001 serves X8, X14 and X17, so the installed cover, connectors and complete product ID must be checked together.
Alternative Names
DSQC 643 3HAC024488-001 DSQC643 3HAC024488-001 3HAC024488-001 DSQC 643 3HAC024488-001 DSQC643 ABB DSQC 643 3HAC024488-001 ABB 3HAC024488-001 DSQC 643
Technical notes
DSQC 643 3HAC024488-001 requires verification of the IRC5 controller design, matching cover and X8, X14 and X17 connector kit before replacement to avoid mechanical or wiring mismatch.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which cover must be checked for ABB DSQC 643 3HAC024488-001?
Use 3HAC020869-001 for the documented IRC5 M2004 Flexible arrangement, or 3HAC024476-001 for the documented Design 2006 Dual or Single arrangement.
Is ABB DSQC 643 3HAC024488-001 a complete IRC5 controller?
No. ABB identifies it as a replacement panel board and lists it as a spare part within the IRC5 controller structure. The applicable controller cover and connector arrangement must be checked separately.
Can ABB DSQC 643 3HAC024488-001 be ordered as a single replacement piece?
Yes. ABB lists a minimum order quantity and order multiple of one piece. The product data also identifies it as neither quote-only nor made-to-order, although current supply must still be confirmed when requesting a quotation.
What should be recorded before removing ABB DSQC 643 3HAC024488-001?
Record the controller design, cover number and all X8, X14 and X17 connections before isolating and removing the panel board.
Is ABB DSQC 643 3HAC024488-001 suitable for both Dual and Single Design 2006 controllers?
ABB product data associates the same 3HAC024476-001 cover with Design 2006 Dual and Single contexts; the installed configuration must still be verified.
What should be checked after fitting ABB DSQC 643 3HAC024488-001?
Confirm connector seating at X8, X14 and X17, check the correct cover fit, then follow the applicable IRC5 controller diagnostic procedure.
Can a visually similar IRC5 panel board replace ABB DSQC 643 3HAC024488-001?
Do not substitute a panel board based on appearance or dimensions. Confirm the exact 3HAC024488-001 product identity, the controller design, the applicable cover and the X8, X14 and X17 connector arrangement before replacement.
