20AD3P4A0AYNNNC0

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 20AD3P4A0AYNNNC0 is a PowerFlex 70 drive rated for 480 VAC three-phase input, 3.4 A output, and 2 HP normal-duty motor control.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 20AD3P4A0AYNNNC0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 20AD3P4A0AYNNNC0

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    20AD3P4A0AYNNNC0
  • Product Family:
    PowerFlex
  • Product Type:
    PowerFlex 70 480 VAC 2 HP AC Drive
  • Stock:
    1
  • Drive family:
    PowerFlex 70
  • Input class:
    480 VAC, three phase
  • Output current:
    3.4 A
  • Normal-duty rating:
    2 HP
  • Heavy-duty rating:
    1.5 HP
  • Enclosure:
    Panel mount IP20 / NEMA 1
  • Control option:
    Enhanced control
  • Braking:
    Brake IGBT, no resistor
  • Communication option:
    No communication module
  • Feedback option:
    No feedback
  • Weight:
    2.71 kg
  • Estimated shipping dimensions:
    22.57x12.24x17.98cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Mexico
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Drive Ratings Order-Code Options Lifecycle Planning Product Applications

Features:

  • Documented output: 3.4 A supports a 2 HP normal-duty application at the stated class
  • Complete order code: enclosure, control, braking, filter, communication, and feedback options are fixed
  • Planned transition: Rockwell publishes an OEM discontinuation date for advance service planning
Allen-Bradley 20AD3P4A0AYNNNC0 is a specific PowerFlex 70 configuration for established low-horsepower 480 VAC motor applications.

Its order code defines the supplied hardware and prevents a visually similar drive with different control or interface options from being treated as equivalent.

Selection must align supply and motor data, duty, enclosure, braking, protection, control wiring, parameter backup, and the published lifecycle window.

Apter Power supports document review, quotation, and procurement for the Allen-Bradley 20AD3P4A0AYNNNC0 PowerFlex 70 480 VAC 2 HP AC Drive.
Allen-Bradley 20AD3P4A0AYNNNC0 PowerFlex 70 480 VAC 2 HP AC Drive Manuals,Datasheets,Link
Important Notice: No qualified exact-model English PDF is attached. Use the complete product model in every document request.
  • Supply class: the drive is configured for a 480 VAC three-phase installation.
  • Output current: the documented rating is 3.4 A.
  • Normal duty: the applicable motor rating reaches 2 HP under the stated conditions.
  • Heavy duty: the lower 1.5 HP duty rating must be considered for demanding loads.
  • Panel enclosure: IP20/NEMA 1 requires a suitable cabinet environment.
  • Enhanced control: the configuration must be restored with the correct firmware and parameter record.
  • Brake IGBT: braking electronics are included, but an external resistor is not.
  • Interface scope: no communication or feedback module is included in the coded assembly.
  • Current OEM path: the exact catalog remains available for quotation under the approved status.
  • Published date: Rockwell identifies 30 May 2027 as the planned discontinuation.
  • Spare strategy: parameter backup and bench qualification reduce outage risk before that transition.
  • Migration record: motor, control, braking, and network evidence define any successor-drive study.
  • Small 480 VAC motors: control an approved 2 HP normal-duty or 1.5 HP heavy-duty load.
  • Legacy PowerFlex 70 service: replace the exact coded drive without losing option identity.
  • Planned shutdown work: restore parameters, verify rotation, and test braking under controlled conditions.
  • Lifecycle preparation: qualify spares and migration evidence before the published OEM transition.
Description
Compact machinery can use 20AD3P4A0AYNNNC0 where a 480 VAC three-phase PowerFlex 70 drive must deliver 3.4 A and up to 2 HP in normal-duty service. The complete order string also identifies the enclosure, control, braking, filtering, communication, and feedback selections that a short family name would omit.

Its panel-mount IP20/NEMA 1 construction makes 20AD3P4A0AYNNNC0 dependent on the cabinet environment, upstream protection, motor data, grounding, and cooling design. A built-in brake IGBT does not mean that an external braking resistor is included, while the no-filter and no-communication selections remain important during replacement planning.

Rockwell Automation provides a current OEM path for 20AD3P4A0AYNNNC0 while also publishing a planned discontinuation date of 30 May 2027. Owners can use that window to capture parameters, verify motor and load behaviour, qualify a spare, and decide whether a controlled migration should accompany the next scheduled outage.
Alternative Names
Allen Bradley 20AD3P4A0AYNNNC0 Allen-Bradley 20AD 3P4 A0 AYNNNC0 PowerFlex 70 20AD3P4A0AYNNNC0 20AD3P4A0AYNNNC0 drive 20AD3P4A0AYNNNC0 inverter 20AD3P4A0AYNNNC0 VFD PowerFlex 70 480V 2HP drive AB PowerFlex 70 3.4A drive 20A D3P4 A0AYNNNC0
Technical notes
For 20AD3P4A0AYNNNC0 service, preserve the complete order code, 480 VAC supply, motor nameplate, normal- and heavy-duty load data, control wiring, parameters, braking circuit, protection, grounding, ventilation, and rotation record. The built-in brake IGBT does not include a resistor; verify the external braking design and perform controlled motor tests before automatic release.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What motor duty is documented for 20AD3P4A0AYNNNC0?
The exact PowerFlex 70 configuration is rated 2 HP for normal duty and 1.5 HP for heavy duty, subject to the documented installation conditions.
Does 20AD3P4A0AYNNNC0 include a dynamic braking resistor?
No. The order code includes a brake IGBT but no resistor, so the external braking circuit must be verified separately for the application.
Can 20AD3P4A0AYNNNC0 be replaced using only the PowerFlex 70 family name?
No. Use the complete order code because enclosure, control, braking, EMC filter, communication, and feedback selections can differ within the same family.
What should stop commissioning of 20AD3P4A0AYNNNC0?
Stop if supply, motor, duty, protection, grounding, braking, wiring, parameter, ventilation, or rotation evidence conflicts with the approved drive and machine record.
How does the published lifecycle date affect 20AD3P4A0AYNNNC0 planning?
The product currently has an OEM sourcing path, but Rockwell identifies 30 May 2027 as planned discontinuation, so owners should qualify spares and migration data early.
Which tests should follow installation of 20AD3P4A0AYNNNC0?
Verify insulation and wiring, restore approved parameters, test direction and speed at controlled load, prove interlocks and braking, record diagnostics, and then release automatic control.
