Allen-Bradley 22F-D1P5N103 is a convection-cooled Frame A PowerFlex 4M drive delivering 1.5 A for compact 0.4 kW machine-speed control.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 22F-D1P5N103
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 22F-D1P5N103

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    22F-D1P5N103
  • Product Family:
    PowerFlex
  • Product Type:
    PowerFlex 4M AC Drive
  • Stock:
    1
  • Input:
    380–480 V AC, three phase
  • Output current:
    1.5 A
  • Motor rating:
    0.4 kW / 0.5 HP
  • Frame:
    A
  • Enclosure:
    IP20, NEMA/UL Type Open
  • Cooling:
    Convection
  • Brake IGBT:
    Not included
  • Communication:
    Integral RS485 (DSI)
  • Weight:
    1.6 kg
  • Estimated shipping dimensions:
    7.2 × 17.4 × 13.6 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Passive Cooling Input Logic Compact Retrofit Product Applications

Features:

  • Passive cooling: convection serves this 0.4 kW Frame A rating
  • Retrofit layout: feed-through wiring supports compact machine panels
  • Local control: fixed keypad and potentiometer provide direct setup access
This exact rating is best distinguished by its narrow Frame A body and passive cooling rather than by the shared PowerFlex 4M family name.

Feed-through wiring can simplify a small-drive retrofit, but it does not remove the need to verify source/sink logic and command ownership.

The thermal decision depends on installed ambient and spacing, especially where multiple drives are placed side by side.

Apter Power can review 22F-D1P5N103 identity, official documents, compact-panel requirements, and quotation details before supply.
22F-D1P5N103 Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Convection: this rating has no cooling fan
  • Orientation: mount upright on a flat vertical surface
  • Heat boundary: use zero stacking only within the documented 40 °C ambient limit
  • Selector: verify sink or source mode before wiring control inputs
  • Stop circuit: preserve the documented terminal logic during retrofit
  • Reference: identify whether speed comes from the keypad, analog input, or communication
  • Feed-through path: plan incoming and motor wiring through the documented layout
  • Panel width: use the 7.2 cm Frame A width in space calculations
  • Acceptance: test direction, speed reference, stop action, and current under load
  • Small machines: provide variable-speed control for a matched 0.4 kW motor
  • Space-limited panels: use the compact feed-through wiring arrangement
  • Local adjustment: apply the fixed keypad and potentiometer within documented control schemes
Description
For narrow machine panels, 22F-D1P5N103 places 1.5 A of 380–480 V three-phase motor control in the smallest Frame A PowerFlex 4M format. Rockwell Automation rates this exact IP20 open-type configuration for 0.4 kW / 0.5 HP duties.

Speed commands for 22F-D1P5N103 can come from its fixed keypad potentiometer, a supported analog input, or integral RS485 (DSI). Feed-through wiring and programmable inputs help keep the control path accessible without turning the drive into a larger network platform.

Because 22F-D1P5N103 is convection cooled, it has no fan-maintenance task, but the upright installation and cabinet air path remain part of its operating boundary. This makes it best understood as a compact machine drive whose thermal behavior depends on the surrounding panel rather than a self-contained enclosure.
Alternative Names
Allen-Bradley 22F-D1P5N103 Rockwell Automation 22F-D1P5N103 22F D1P5 N103 22FD1P5N103 PowerFlex 4M 0.4 kW drive PowerFlex 4M 0.5 HP drive
Technical notes
22F-D1P5N103 is the N103 PowerFlex 4M variant without an internal brake IGBT. A machine that regenerates energy during rapid deceleration therefore cannot rely on this drive for resistor braking. Choose a separately engineered stopping method, or stop the selection if the machine design requires an integral braking transistor.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can 22F-D1P5N103 be selected when the panel specification requires an integral EMC filter?
No. Rockwell identifies N103 as the configuration without a CE-compliant filter, while N113 is the corresponding integral-filter configuration. Choose from the documented EMC plan rather than assuming the drive completes installation-level compliance.
Why can 22F-D1P5N103 receive a run command yet hold its output at 0 Hz?
The selected speed source may be providing no reference, or a digital input may override P108. Read d012, d014, and d002 to identify the active path before changing a frequency setting.
Correct RS485 wiring is present, so why might a Modbus master still read the wrong register from 22F-D1P5N103?
The master may use zero-based or one-based addressing. Apply the documented offset before remapping the network; the Logic Command register can appear as 8192 or 8193 depending on that convention.
Before remote control is commissioned, which communication-loss behavior should be observed on 22F-D1P5N103?
C304 defines the response and C305 defines its delay. Prove whether the machine faults and coasts, stops through P107, or continues the last state; do not release remote control until the observed action matches the approved design.
Why can an external analog reference make the speed command of 22F-D1P5N103 indeterminate?
Only one analog frequency source may be connected at a time. If both 0–10 V and 4–20 mA references are present, remove the unused source before continuing commissioning.
Can two DSI accessories share 22F-D1P5N103 through an RJ45 splitter without assigning roles?
No. One peripheral must use the splitter Master port and operate as Master, while the other operates as Slave. Stop setup if both remain in Auto or Master mode, then establish the documented pair.
