    Honeywell documentation lists FC-IO-0001 as the conformal-coated I/O extender for Safety Manager I/O chassis configurations.

FC-IO-0001

/ 4.9
1001 reviews | Need a Specific Revision?
FC-IO-0001 is a conformal-coated i/o extender module for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FC-IO-0001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FC-IO-0001

  • Manufacturer:
    Honeywell
  • Part Number:
    FC-IO-0001
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    I/O extender module
  • Stock:
    1
  • Module role:
    I/O communication extender
  • Non-redundant location:
    One module in slot 21
  • Redundant locations:
    Two modules in slots 20 and 21
  • Supply voltage:
    5 V DC
  • Supply current:
    35 mA
  • Maximum ripple:
    Less than 50 mV p-p
  • Module size:
    4 TE, 3 HE (4 HP, 3U)
  • Coating:
    Conformal-coated FC version
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • Conformal-coated I/O extender module
  • One module for S chassis or two for R chassis
  • 35 mA at 5 V DC

FC-IO-0001 provides the communication bridge between the Safety Manager control processor and the I/O chassis modules.

The FC construction is used where the project specifies conformal-coated hardware, without changing the fixed extender slot arrangement.

Verified resources for FC-IO-0001:

Verified specifications for FC-IO-0001:

  • Module role: I/O communication extender
  • Non-redundant location: One module in slot 21
  • Redundant locations: Two modules in slots 20 and 21
  • Supply voltage: 5 V DC
  • Supply current: 35 mA
  • Maximum ripple: Less than 50 mV p-p
  • Module size: 4 TE, 3 HE (4 HP, 3U)
  • Coating: Conformal-coated FC version

Typical applications:

  • Conformal-coated Safety Manager I/O communication
  • Slot-21 extender service in S chassis
  • Two-path extender service in R chassis

The FC module is intended for the same communication role as the FS variant where the installation calls for coated hardware.

Safety and compliance:

  • Documented approvals: CE, TÜV, UL, CSA and FM
  • Safety-related powered replacement may shut down the system
  • Key-coded chassis connection

Verify maintenance permissions, controller state and the affected safety channels before removing a live extender module.

Performance and efficiency:

  • 5 V DC operation
  • 35 mA current requirement
  • Standard 4 HP, 3U Safety Manager module size

The conformal-coated module extends chassis communication with low power demand and fixed keyed connections.

Description

FC-IO-0001 is a conformal-coated i/o extender module for the Honeywell Safety Manager platform. FC-IO-0001 transfers control-processor communication to the I/O modules through the chassis horizontal bus while providing the FC conformal-coated hardware variant.

Install one module in slot 21 of IOCHAS-0001S or two modules in slots 20 and 21 of IOCHAS-0001R. Verify coating requirements, chassis topology, connector coding and the approved powered-maintenance procedure before replacement.

Alternative Names
FC-IO-0001 FC IO 0001 Honeywell FC-IO-0001 Honeywell FC IO 0001 Safety Manager FC-IO-0001 FC-IO-0001 I/O extender module FCIO0001 I/O extender module Honeywell Safety Manager FC-IO-0001
Technical notes
FC-IO-0001 is the conformal-coated Safety Manager I/O extender rated for 5 V DC operation at 35 mA. Its slot position depends on the S or R chassis architecture.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is FC-IO-0001 integrated into a Safety Manager configuration?
Use it in an FC-specified Safety Manager project with the S or R chassis, corresponding backplane and correct horizontal bus assembly.
Which technical interfaces or ratings define FC-IO-0001?
The key documented points are Module role: I/O communication extender; Non-redundant location: One module in slot 21; Redundant locations: Two modules in slots 20 and 21; Supply voltage: 5 V DC. Confirm these values against the installed chassis and project hardware list.
Which compatibility checks are required before installing FC-IO-0001?
Confirm conformal coating, chassis configuration, extender slot, A5/A7 connector coding, flat-cable interface and controller system release.
Which slot, bus position or chassis location is specified for FC-IO-0001?
Place it in slot 21 for S chassis service or in slots 20 and 21 as two separate paths for R chassis service.
What diagnostic symptoms can indicate a FC-IO-0001 connection or hardware problem?
Loss of FC-IO-0001 communication can make the associated chassis I/O unavailable and may cause a Safety Manager shutdown when safety-related channels are affected. Review extender, bus-cable and 5 V diagnostics together.
Can FC-IO-0001 replace a related FS, FC, S or R version directly?
An FS version should not be substituted without confirming the project environmental and coating specification.
Which commissioning checks should be completed after fitting FC-IO-0001?
Confirm the correct slot, A5/A7 key coding, horizontal-bus cable, 5 V DC supply, ripple limit and clear controller diagnostics before enabling the affected I/O channels.
Which engineering data is needed to match and quote FC-IO-0001?
Provide the complete FC-IO-0001 reference, controller and chassis type, Safety Manager release, slot or bus arrangement, coating requirement, existing hardware revision, required quantity and project approval requirements.
