Features:
- Interface Between PROFIBUS DP Field Devices and ABB Advant 800xA Control System
- Combines Capability of PROFIBUS DP-V0/V1 Communication with Flexible Master/Slave Operation
- Operates in Conjunction with ABB S800 I/O Series and Standard Advant 800xA Controllers
The CI830 3BSE013252R1 operates as the PROFIBUS DP-V1 Communication Interface Module in an S800 I/O rack, enabling deterministic data exchange between ABB Advant 800xA controllers and PROFIBUS DP field devices. It continuously handles cyclic real-time I/O transfer (DP-V0) and advanced acyclic services (DP-V1) for device configuration, parameterization, and diagnostics, distributing communication capabilities through the rack backplane to support steady state operation of all connected modules. Seamless integration with the PROFIBUS network is standard with the CI830 3BSE013252R1, with hot-swappable functionality allowing module replacement without system shutdown. The CI830 3BSE013252R1 has made improvements in several areas over previous communication interface designs in addition to incorporating support for both DP-V0 and DP-V1 protocol capabilities within the S800 I/O rack.
The CI830 3BSE013252R1 provides essential communication functions common to the entire rack, and is a critical component of the control path, directly affecting the proper, normal operation of the overall distributed control system. One CI830 3BSE013252R1 communication module is required per PROFIBUS DP segment to establish connectivity. The CI830 3BSE013252R1 occupies a dedicated slot in the S800 I/O rack and interfaces directly with the controller and field devices through the PROFIBUS DP network.
For expanded network applications, the Advant 800xA System may require additional CI830 3BSE013252R1 communication modules installed in separate segments. In addition to standard single module operation, the CI830 3BSE013252R1 configuration also performs advanced device diagnostics. The CI830 3BSE013252R1 communication system executes diagnostic monitoring using the internal circuitry specified in the module specifications. Using this method, the communication system continually monitors the health of connected PROFIBUS devices. If the system detects that a field device is no longer responding properly (outside configured communication parameters or diagnostic thresholds), it will automatically report the event and place diagnostic information in the System Event List for maintenance personnel.
The CI830 3BSE013252R1 ABB Communication Interface Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB CI830 3BSE013252R1 Communication Interface Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB CI830 3BSE013252R1 Communication Interface Module Specs
General
- Manufacturer ABB
- Model CI830 3BSE013252R1
- Condition New Original ready stock
- Product Family DI810、DI814、DO810、DO814
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Process Industries: Extensively used in chemical, petroleum, and power plants to monitor and control process instruments like flow meters, level gauges, and control valves.
- Factory Automation: Employed on production lines to manage robots, conveyors, and automated assembly systems.
- Energy Management: Integrated into power distribution and energy monitoring systems to ensure stable operations.
- Warehouse Logistics: Facilitates communication with stackers and automated shelving for precise goods handling.
- IEC 61508 & IEC 61511: Certified as part of the 800xA High Integrity product line for functional safety in industrial applications.
- Industrial IT Certification: Officially certified for integration within the ABB Industrial IT architecture.
- Environmental Standards: Designed with robust EMC protection, high vibration resistance, and an operating temperature range from -20°C to +60°C.
- Regional Compliance: Holds certifications such as CQ (Certificate of Quality) and COO (Country of Origin), typically manufactured in Switzerland or Poland.
- Protocols: Primarily supports PROFIBUS DP-V1, but is also noted for interoperability with systems using Modbus TCP/IP and HART via data exchange protocols.
- System Integration: Seamlessly integrates with the ABB System 800xA and can be connected to AC 800M controllers using a PROFIBUS Master like the CI854.
- I/O Module Constraints: Note that the basic system software in some versions does not support certain I/O modules, such as AI843, AI845, AI895, AO845, AO895, DI830, DI831, and DI840.
- Redundancy: While the CI830 supports standard PROFIBUS communication, full redundancy typically requires related units like the CI840 for PROFIBUS-DPV1.
