1756-EN3TR

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-EN3TR is a dual-port ControlLogix EtherNet/IP communication module for Device Level Ring or linear networks, controller messaging, I/O, and integrated motion.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1756-EN3TR
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-EN3TR

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-EN3TR
  • Product Family:
    ControlLogix
  • Product Type:
    ControlLogix EtherNet/IP Communication Module
  • Stock:
    1
  • Network:
    EtherNet/IP
  • Copper ports:
    Two RJ45
  • Data rate:
    10/100 Mbps
  • Supported topologies:
    Device Level Ring and linear
  • TCP connections:
    128
  • CIP connections:
    256
  • CIP unconnected messages:
    128 plus 128
  • Packet rate capacity:
    25,000 packets per second
  • Integrated-motion capacity:
    Up to 128 axes
  • Backplane current at 5.1 V DC:
    1 A
  • Backplane current at 24 V DC:
    3 mA
  • Power dissipation:
    5.1 W
  • Thermal dissipation:
    17.4 BTU/h
  • Isolation voltage:
    30 V continuous
  • Module location:
    Any ControlLogix chassis slot
  • USB data rate:
    12 Mbps, temporary local programming only
  • Operating temperature:
    0 to 50°C in Series B chassis; 0 to 60°C in Series C chassis
  • Storage temperature:
    -40 to 85°C
  • Relative humidity:
    5 to 95%, non-condensing
  • Dimensions:
    3.5 × 14 × 14.5 cm
  • Weight:
    0.44 kg
  • Tariff Code:
    8517623990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Network Design Capacity Chassis Fit Application
  • Two 10/100 Mbps copper ports support DLR and linear EtherNet/IP layouts
  • Provides controller messaging, distributed I/O, and integrated-motion connectivity
  • Combines high connection capacity with temporary USB local programming

1756-EN3TR is built for ControlLogix networks that need two embedded switch ports rather than an external switch at the chassis. The topology can continue as a line or close as a DLR ring.

Capacity planning should consider connections, packet rate, and motion traffic together. Chassis series also changes the permitted upper operating temperature, so mechanical fit alone is not sufficient.

Before commissioning, verify the chassis series, power budget, DLR supervisor, IP plan, firmware, electronic keying, cabling, and saved Studio 5000 module definition.

Availability, condition, price, and shipping time for 1756-EN3TR are confirmed during quotation.

Allen-Bradley 1756-EN3TR ControlLogix EtherNet/IP Communication Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use both RJ45 ports for the engineered DLR or linear topology
  • Assign and document the intended DLR supervisor before commissioning
  • Preserve IP addressing and module-definition data during replacement
  • Plan within 128 TCP and 256 CIP connection limits
  • Evaluate the 25,000-packet-per-second module capacity against the application
  • Coordinate controller, update-rate, and network-load limits for integrated motion
  • Install 1756-EN3TR in any compatible ControlLogix chassis slot with an adequate power budget
  • Apply the documented 0 to 60°C operating-temperature range
  • Use the USB connection only for temporary local programming and maintenance
  • Device Level Ring EtherNet/IP control networks
  • Linear EtherNet/IP communication between ControlLogix and distributed devices
  • Integrated-motion architectures engineered for the documented axis capacity
Description
1756-EN3TR adds two 10/100 Mbps copper EtherNet/IP ports to a ControlLogix chassis for Device Level Ring or linear network topologies.

The module supports controller messaging, distributed I/O and integrated motion, with published limits of 128 TCP connections, 256 CIP connections, 25,000 packets per second and as many as 128 motion axes.

Installation planning must cover the DLR supervisor, IP configuration, firmware, electronic keying, chassis power, cabling, network load and the saved Studio 5000 module definition.
Revisions

Revision Part #

Also known as

1756-EN3TR Ser B
1756-EN3TR/B, Series B, Rev B
Alternative Names
1756-EN3TR 1756-EN3TR/B Allen-Bradley 1756-EN3TR Allen Bradley 1756-EN3TR Rockwell Automation 1756-EN3TR ControlLogix EtherNet/IP 1756-EN3TR
Technical notes
1756-EN3TR installation requires matching chassis series, firmware, electronic keying, IP plan, and DLR role; an incorrect module definition or duplicate address can stop EtherNet/IP communication.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can 1756-EN3TR join an existing Device Level Ring built with another module generation?
It can participate only when the ring design, firmware, DLR roles, update requirements, and Studio 5000 module definition are compatible. Verify the complete ring before inserting the module.
When should 1756-EN3TR be selected for a Device Level Ring?
Select it when the engineered EtherNet/IP architecture requires two copper ports and DLR participation. Confirm which device is the ring supervisor and retain the documented ring parameters.
Can the USB port on 1756-EN3TR remain connected for normal plant communication?
No. Rockwell Automation designates the USB port for temporary local programming and configuration. It is not a substitute for either EtherNet/IP network port.
Can the two 1756-EN3TR ports be assigned to unrelated plant networks?
No. They form the module's embedded EtherNet/IP switch for the engineered DLR or linear topology; they are not two independent network interfaces with separate IP configurations.
Can 1756-EN3TR be installed in any free ControlLogix slot?
The module can occupy any ControlLogix chassis slot, but the chassis series, operating-temperature limit, power budget, network cabling, and controller project must still satisfy the documented installation.
Why might a replacement 1756-EN3TR remain offline after cabling?
Check for a duplicate IP address, incorrect subnet or gateway, incompatible firmware or keying, a mismatched module definition, bad Ethernet cabling, or an incomplete DLR ring configuration.
Is 1756-EN3TR suitable for high-axis-count integrated motion?
Rockwell Automation documents integrated-motion capacity up to 128 axes, but actual design limits depend on the controller, update rates, network load, firmware, and complete motion architecture.
