2711P-T12W22D9P

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2711P-T12W22D9P pairs a 12.1-inch WXGA widescreen with resistive touch and dual DLR-capable Ethernet for information-dense machine visualization.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2711P-T12W22D9P
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-T12W22D9P

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-T12W22D9P
  • Product Family:
    Allen Bradley Panelviews
  • Product Type:
    Graphic Terminal
  • Stock:
    1
  • Display Size:
    12.1 in. widescreen
  • Operator Input:
    Analog resistive touch
  • Resolution:
    1280 × 800 WXGA
  • Aspect Ratio:
    16:10
  • Viewing Area:
    261 × 163 mm
  • Ethernet:
    Two 10/100Base-T ports with DLR
  • Software:
    FactoryTalk View Studio for Machine Edition
  • Input Voltage:
    24 V DC nominal (18…30 V DC)
  • Weight:
    2.54 kg
  • Estimated shipping dimensions:
    24 × 34 × 6.96 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Widescreen Layout Application Storage Network Topology Product Applications

Features:

  • 12.1-inch WXGA widescreen with 16:10 aspect ratio
  • Resistive touch for direct operator interaction
  • Two Ethernet ports for DLR, linear, or star connectivity
Allen-Bradley 2711P-T12W22D9P uses its widescreen geometry to place more horizontal process context, trends, or navigation on one HMI view.

Dual Ethernet ports let the same terminal fit documented ring, linear, or star layouts without changing the operator-interface role.

Project conversion should protect the 16:10 layout, terminal Series, firmware target, communication shortcuts, and storage method instead of relying on automatic resizing.

Apter Power can review 2711P-T12W22D9P screen format, Series, and project-transfer requirements before supply.
2711P-T12W22D9P Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Design the project for a 1280 × 800 WXGA canvas
  • Use the 16:10 width for trends, navigation, or process context
  • Review every touch target after screen conversion
  • Keep the FactoryTalk View project source with the runtime file
  • Record SD-card or USB transfer media by terminal Series
  • Protect communication shortcuts and security settings during restore
  • Choose DLR when ring recovery is part of the design
  • Use linear or star wiring for documented non-ring architectures
  • Verify both Ethernet ports and IP settings during acceptance
  • Display information-dense machine and process views
  • Provide operator control for supported ControlLogix and CompactLogix systems
  • Support networked HMI applications that benefit from a 12.1-inch wide screen
Description
A 16:10 display distinguishes the Allen-Bradley 2711P-T12W22D9P within the PanelView Plus 7 Performance line. Its 12.1-inch, 1280 × 800 WXGA screen provides a wide operator workspace with analog resistive touch.

For networked visualization, Allen-Bradley 2711P-T12W22D9P supplies two 10/100Base-T ports that can be arranged as DLR, linear, or star. FactoryTalk View Studio for Machine Edition creates the application, while FactoryTalk ViewPoint support begins at the documented version boundary.

The wide aspect ratio makes the Allen-Bradley 2711P-T12W22D9P a different project target from 4:3 terminals even when the controller data is unchanged. Confirm the cutout, screen layout, Series-specific platform, storage plan, and project archive before replacement.
Revisions

Revision Part #

Also known as

2711P-T12W22D9P Ser A
2711P-T12W22D9P/A, Series A, Rev A
2711P-T12W22D9P Ser B
2711P-T12W22D9P/B, Series B, Rev B
Alternative Names
Allen-Bradley 2711P-T12W22D9P terminal 2711P T12W22D9P 2711PT12W22D9P PanelView Plus 7 Performance 12-inch widescreen AB WXGA operator terminal
Technical notes
Allen-Bradley 2711P-T12W22D9P uses a 16:10 WXGA canvas, so a project moved from a 4:3 PanelView requires screen-by-screen layout review rather than simple scaling. Also identify Series A or B before download because operating system, memory, USB interfaces, and power consumption differ between platforms.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should 2711P-T12W22D9P screens be migrated from a 4:3 terminal?
Rework navigation, alarm banners, trend width, and touch targets for the 16:10 canvas, then test every production screen instead of stretching the old layout.
What changes when 2711P-T12W22D9P moves from Series A to Series B?
The operating system, memory, storage, USB arrangement, graphics depth, and power figures change; validate the application and media workflow on the target Series.
Can 2711P-T12W22D9P join a Device Level Ring directly?
Yes. Its two Ethernet ports support DLR when configured as part of a complete, documented ring architecture.
How should 2711P-T12W22D9P application backups be managed?
Keep the FactoryTalk View project source, runtime file, terminal Series, firmware, communication shortcuts, and any SD-card content under revision control.
What should be examined when 2711P-T12W22D9P touch targets feel misaligned?
Check screen calibration, bezel contamination, overlay condition, object placement, and whether the project was resized from another aspect ratio.
Which panel measurements matter before 2711P-T12W22D9P installation?
Use the official terminal and cutout dimensions, then verify mounting clearance, cable bend space, gasket seating, and enclosure depth at the actual panel.
