          Apter Power provides rapid quotation, procurement support, and system integration assistance for this model.

        146054-011-20-02-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The Bently Nevada 146054-011-20-02-05 is a 3300 Series eddy current probe designed specifically for extreme environments, such as those involving anhydrous ammonia, highly corrosive conditions, and high pressure.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 146054-011-20-02-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 146054-011-20-02-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          146054-011-20-02-05
        • Product Family:
          3300 System
        • Product Type:
          Ceramic Capped Probe
        • Stock:
          1
        • Overall Case Length Option:
          1.1 in (1.1 inches / 28 mm)
        • Total Length Option:
          2.0 meters (6.6 feet)
        • Connector and Cable Option:
          Miniature coaxial ClickLoc connector, standard cable
        • Agency Approval Option:
          CSA, ATEX, IECEx (Multiple Approvals)
        • Probe Tip Material:
          Alumina ceramic (Al2O3)
        • Probe Case Material:
          AISI 304 stainless steel
        • Thread Engagement Limit:
          0.563 in (14.3 mm) maximum
        • Probe Case Diameters:
          7.0 mm (0.273 in) / Tip 7.2 mm (0.285 in)
        • Connector Material:
          Gold-plated brass or gold-plated beryllium copper
        • Cable Minimum Bend Radius:
          25.4 mm (1.0 in)
        • Probe Pressure Rating:
          Rated to seal 34 Bar (500 psi) nitrogen
        • Operating and Storage Temperature:
          -51°C to +177°C (-60°F to +351°F)
        • Linear Range:
          1.52 mm (60 mils), from 0.25 to 1.78 mm (10 to 70 mils)
        • Incremental Scale Factor (ISF):
          7.87 V/mm (200 mV/mil) $\pm$6.5%
        • Hazardous Area Certifications:
          Class I, Zone 0/2; Ex ia IIC T4/T5; Ex nA/ec IIC T4/T5
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Certifications & Standards Physical & Mechanical Protection

        Features:

        • Hermetically sealed alumina ceramic tip prevents liquid and gas ingress at process entry.
        • 3/8-24 UNF threaded 304 stainless steel case provides robust chemical resistance.
        • Pre-configured 2.0-meter flexible coaxial cable with miniature ClickLoc connector.
        The Bently Nevada 146054-011-20-02-05 configuration specifies a 1.1-inch case length, 2.0-meter cable length, miniature coaxial ClickLoc connector, and multiple agency safety approvals.

        Designed as a key sensing element for 3300 XL proximity transducer systems, this unit conditions non-contact gap measurements for continuous machinery protection.

        Always gap the probe tip electrically without applying direct mechanical load and keep the unsealed rear tubing protected from corrosive environments.

        Availability: The 146054-011-20-02-05 is a new original product supplied by the manufacturer (OEM).
        Bently Nevada 146054-011-20-02-05 Ceramic Capped Probe Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Continuous shaft vibration and position monitoring in anhydrous ammonia processes.
        • Non-contact gap measurement in extreme pH chemical fluids and corrosive environments.
        • Rotor displacement detection inside high-pressure vessels up to 34 Bar (500 psi).
        • Certified for CSA, ATEX, and IECEx intrinsically safe and non-incendive hazardous area usage.
        • Complies with European Community ROHS Directive 2011/65/EU and China RoHS standards.
        • Meets FCC Part 15 class requirements and Maritime classification rules for offshore units.
        • 3/8-24 UNF 2A mounting threads with a maximum engagement limit of 0.563 inches.
        • 75-ohm fluoroethylene propylene (FEP) insulated cable with 1.0-inch minimum bend radius.
        • Gold-plated brass or beryllium copper ClickLoc connector with finger-tight torque mechanism.
        • Protects against chemical corrosion and fluid penetration using a helium-sealed ceramic cap.
        • Provides continuous gap signal inputs for early machinery malfunction diagnostics and alarms.
        • Includes a robust 304 stainless steel case to prevent mechanical damage in severe environments.
        Description
        The Bently Nevada 146054-011-20-02-05 ceramic capped probe is an advanced sensing solution engineered for continuous machine condition monitoring in aggressive chemical and high-pressure applications. Equipped with a durable alumina ceramic tip and an AISI 304 stainless steel case, this probe ensures reliable operation and long-term service life when exposed to corrosive media such as anhydrous ammonia or extreme pH process fluids.

        Designed for front-end process isolation, the 146054-011-20-02-05 features a helium leak-tested ceramic-to-metal interface that creates a hermetic seal against liquid and gas ingress. The unit operates as a key component in 3300 XL proximity transducer systems, connecting via flexible 75-ohm FEP coaxial cable to deliver precise gap measurements for rotating equipment protection systems.

        Featuring a 1.1-inch overall case length with 3/8-24 UNF threads, a 2.0-meter cable, and a miniature coaxial ClickLoc connector, the 146054-011-20-02-05 provides robust mechanical integration and easy installation. With full multiple agency approvals for hazardous area operations, it supports dependable, non-contact measurement in hazardous industrial environments

        Alternative Names
        146054-011-20-02-05 146054 011 20 02 05 146054011200205 BN 146054-011-20-02-05 Bently Nevada 146054-011-20-02-05 Bently Nevada 146054-011-20-02-05 Probe 3300 Ceramic Capped Probe 146054-011-20-02-05
        Technical notes
        The Bently Nevada 146054-011-20-02-05 features a sealed ceramic front end, but its unsealed rear end must never be exposed to corrosive gases or liquids like NH3 or H2S.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What is the primary function of the Bently Nevada 146054-011-20-02-05 probe?
        The Bently Nevada 146054-011-20-02-05 provides non-contact gap and vibration measurement in high-pressure or chemically aggressive environments like anhydrous ammonia.
        What are the exact structural options configured for 146054-011-20-02-05?
        The 146054-011-20-02-05 configuration specifies a 1.1-inch threaded case length, a 2.0-meter total cable length, a miniature coaxial ClickLoc connector, and multiple agency safety approvals.
        What mounting environment considerations apply to the 146054-011-20-02-05?
        The front ceramic end of the 146054-011-20-02-05 is hermetically sealed for corrosive media, but the rear of the probe lacks a rear seal and must be kept protected from direct liquid or gas exposure.
        Is the Bently Nevada 146054-011-20-02-05 available for ordering and replacement?
        Yes, the 146054-011-20-02-05 is an official active part number that can be ordered directly or supplied as an exact certified replacement part for existing machinery systems.
        What are the installation requirements when replacing a 146054-011-20-02-05?
        When installing the 146054-011-20-02-05, check that thread engagement does not exceed 0.563 inches to prevent binding, and gap the tip electrically without applying mechanical direct load.
        How do I request pricing and lead time for 146054-011-20-02-05?
        You can request a quote for the Bently Nevada 146054-011-20-02-05 by contacting your authorized sales representative with your required project quantities and delivery schedule.
