        • Lifecycle status

          Active / Available from OEM
          Apter Power provides quotation, documentation, approval checks, and five-metre system guidance.

        330876-01-50-01-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330876-01-50-01-05 is a 1/2-20 threaded 3300 XL 50 mm probe with a 5.0 m armored high-temperature FluidLoc cable and multiple approvals.
        In Stock
        Ships by Wednesday, September 30
        Fast Shipping Available
        Get a quick price for 330876-01-50-01-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330876-01-50-01-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330876-01-50-01-05
        • Product Family:
          3300 XL 50mm Proximity Transducer System
        • Product Type:
          Proximity Probe
        • Stock:
          1
        • Probe case option:
          01 = 1/2-20 thread
        • Total probe length:
          5.0 m (16.4 ft)
        • Armor option:
          01 = High-temperature FluidLoc cable with armor
        • Agency approval:
          05 = Multiple approvals
        • Probe exit:
          Straight exit
        • Locknut:
          Included with predrilled safety-wire holes
        • System linear range:
          27.9 mm (1100 mils)
        • Nominal scale factor:
          0.394 V/mm (10 mV/mil)
        • Reference target:
          AISI 4140 steel, 102 mm minimum diameter
        • System power:
          -17.5 to -26 VDC without barriers; 12 mA maximum
        • Output resistance:
          50 ohms
        • Extension-cable capacitance:
          69.9 pF/m typical
        • Recommended field wiring:
          Three-conductor shielded triad, 0.2 to 1.5 mm2
        • Continuous probe temperature:
          Up to 200 C
        • Intermittent probe temperature:
          Up to 250 C
        • Connector family:
          High-temperature ClickLoc
        • Cable construction:
          High-temperature FluidLoc
        • Probe case diameter:
          1.99 in
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Compatibility Environmental Ratings Safety

        Features:

        • Uses a 1/2-20 straight-exit threaded case with safety-wire locknut.
        • Provides a 5.0 m high-temperature FluidLoc cable protected by armor.
        • Carries the multiple-approval ordering option for the defined 50 mm system configuration.
        The current ordering configuration is 330876-01-50-01-05, the 1/2-20 threaded, 5.0 m, armored FluidLoc 50 mm probe with multiple approvals.

        It converts extended axial target movement into the probe signal used by a matching Proximitor Sensor for turbine differential-expansion monitoring.

        Before fitting the probe, confirm thread depth, safety-wire practice, cable support, approval markings, five-metre sensor compatibility and target calibration.

        Availability is subject to Apter Power inventory and sourcing confirmation.
        Verified resources for Bently Nevada 330876-01-50-01-05:
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Monitors differential expansion on large steam turbine generators with direct threaded probe mounting.
        • Provides a protected lead for routes exposed to mechanical contact or maintenance activity.
        • Supports approved 50 mm transducer installations that require the 05 ordering option.
        • The five-metre probe is designed for the five-metre 3300 XL 50 mm Proximitor Sensor.
        • Probe, extension cable and sensor must all belong to the 3300 XL 50 mm component family.
        • The nominal calibration assumes an AISI 4140 steel target of at least 102 mm diameter.
        • High-temperature construction supports 200 C continuous probe operation and 250 C intermittent exposure.
        • FluidLoc limits process liquid movement through the cable interior.
        • The 05 suffix identifies the multiple-approval option; apply only approvals present on the delivered label.
        • Secure the threaded case with the supplied locknut and project-approved safety wiring.
        • Support the armored lead so vibration and bend load are not transferred to the probe body.
        • Isolate the monitored machine and confirm safe target clearance before any gap adjustment.
        Description
        330876-01-50-01-05 is a threaded extended-range probe for the Bently Nevada 3300 XL 50 mm transducer system. The 1/2-20 case supports direct threaded mounting and includes a locknut prepared for safety wiring.

        Its five-metre high-temperature FluidLoc lead is protected by armor for demanding routes around turbine casings. The probe and cable use high-temperature ClickLoc connection hardware and must be matched to the five-metre 50 mm Proximitor configuration.

        The assembly is suited to differential-expansion and rotor-expansion measurements where a protected cable path and documented approvals are required. Target geometry, installed gap and the complete system calibration remain part of the measurement design.
        Alternative Names
        330876-01-50-01-05 33087601500105 330876 01 50 01 05 330876-01-50-01-05 3300 XL 50 mm Proximity Probe 330876-01-50-01-05 1/2-20 Threaded Proximity Probe 330876-01-50-01-05 5.0 m Armored FluidLoc Probe 330876-01-50-01-05 Multiple-Approval Probe Bently Nevada 3300 XL 50 mm Proximity Transducer System
        Technical notes
        330876-01-50-01-05 is a five-metre probe and must not be connected to a nine-metre 50 mm Proximitor configuration without a documented system-length match.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What mechanical interface identifies 330876-01-50-01-05?
        It uses the straight-exit 1/2-20 threaded case rather than the M14 or smooth side-exit alternatives.
        Why is cable armor part of 330876-01-50-01-05?
        Option 01 adds armor over the high-temperature FluidLoc lead for routes needing extra mechanical protection.
        Which Proximitor configuration belongs with 330876-01-50-01-05?
        Use the matching five-metre 3300 XL 50 mm Proximitor Sensor and ensure any extension maintains the documented system length.
        Where is 330876-01-50-01-05 normally used?
        It is intended for extended differential-expansion or rotor-expansion measurements on large rotating machinery.
        What replacement detail is most likely to be missed for 330876-01-50-01-05?
        Confirm the 1/2-20 thread and five-metre armored lead; a visually similar smooth or unarmored probe is not equivalent.
        What should accompany an inquiry for 330876-01-50-01-05?
        Send the full nameplate code, required approval, installed Proximitor number, cable route and quantity for matching review.
