        • Lifecycle status

          Discontinued / Obsolete by OEM
          Apter Power provides quotations, legacy technical data and system-matching support for General Electric IC3600LCDA1.

        IC3600LCDA1

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC3600LCDA1 is a clock logic driver control board that amplifies Directo-Matic II logic and drives multiple downstream logic loads.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IC3600LCDA1
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC3600LCDA1

        • Manufacturer:
          General Electric
        • Part Number:
          IC3600LCDA1
        • Product Family:
          GE Mark V/VI Driver Board
        • Product Type:
          Clock Logic Driver Control Board
        • Stock:
          1
        • Expansion Inputs:
          A-E and OR-E
        • Output Capacity:
          32 L-logic loads
        • Logic Function:
          Two-input AND with expansion paths
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Input Logic Expansion Paths Output Drive State Evaluation

        Features:

        • Supports Directo-Matic II clock-logic distribution.
        • Accepts separate A-E and OR-E expansion paths.
        • Retains two-input AND behavior without expansion.
        In the IC3600LCDA1 logic block, A and B serve as the normal inputs, while dedicated terminals accept expanded AND and OR results.

        The IC3600LCDA1 output changes after the board resolves both direct inputs and any connected expansion condition, keeping the complete equation in one signal path.

        Revision markings IC3600LCDA1A and IC3600LCDA1B identify complete board assemblies within the same LCDA functional family.

        The General Electric IC3600LCDA1 Clock Logic Driver Control Board is available from Apter Power with quotation and technical-data support.
        General Electric IC3600LCDA1 Clock Logic Driver Control Board Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Normal Input Behavior

        • Input A: Serves as one normal condition in the LCDA AND relationship.
        • Input B: Provides the second normal condition for the same logic stage.
        • True Result: Both normal inputs must be high when no expansion is connected.
        • Low Condition: Either normal input can hold the basic AND result low.

        Expanded Logic Connections

        • A-E Path: Accepts an additional AND condition from an external logic expander.
        • OR-E Path: Adds an alternate OR branch to the combined equation.
        • LGXA Link: Extends the number of AND conditions presented to IC3600LCDA1.
        • LLXA Link: Supplies expanded OR logic to the IC3600LCDA1 input network.

        Amplified Logic Output

        • Power Amplifier: The LCDA circuit includes an integrated output-driving stage.
        • Fan-Out: IC3600LCDA1 can operate as many as 32 L-logic loads.
        • Resolved State: The amplifier follows the result of the complete input equation.
        • Signal Distribution: One logic result can be delivered to multiple receiving points.

        Combined Logic Response

        • Basic Mode: Unused A-E and OR-E paths leave IC3600LCDA1 in two-input AND operation.
        • Input Inhibit: A low normal input prevents the basic AND term from becoming true.
        • AND Expansion: An added condition can inhibit the result through the A-E path.
        • OR Expansion: The OR-E branch contributes an alternate true condition to the equation.
        Description
        General Electric IC3600LCDA1 is the LCDA clock logic driver control board used with Directo-Matic II sequential logic. Its circuit combines two normal AND inputs with a power-amplified output for distributing a resolved logic state to downstream elements.

        The expansion paths on General Electric IC3600LCDA1 are identified as A-E and OR-E. These inputs allow additional AND or OR conditions to participate in the output decision through related logic-expander cards; when both expansion points are unused, the circuit performs ordinary two-input AND operation.

        At its output stage, General Electric IC3600LCDA1 can drive as many as 32 L-logic loads. This fan-out capacity allows one resolved logic result to feed multiple receiving points within the original control architecture.
        Revisions

        Revision Part #

        Also known as

        IC3600LCDA1A
        IC3600LCDA1-A, Series A, Rev A
        Get Parts Quote
        IC3600LCDA1B
        IC3600LCDA1-B, Series B, Rev B
        Get Parts Quote
        Alternative Names
        GE IC3600LCDA1 Clock Driver General Electric IC3600LCDA1 Logic Board IC3600 LCDA 1 IC 3600 LCDA1 IC3600-LCDA1 Clock Logic Driver Directo-Matic II IC3600LCDA1 GE Mark II LCDA Clock Driver IC36OOLCDA1
        Technical notes
        General Electric IC3600LCDA1 accepts two normal AND inputs plus A-E and OR-E expansion paths, with output fan-out for 32 L-logic loads.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why might an IC3600LCDA1 output remain low even when its two normal inputs are high?
        On IC3600LCDA1, a low condition entering through A-E or the expanded logic path can hold the combined result low; inspect the complete expansion chain rather than only the two normal inputs.
        What should be checked before fitting an IC3600LCDA1A or IC3600LCDA1B board?
        Confirm that the required assembly belongs to the IC3600LCDA1 family, then match the full suffix on the removed board and verify the cabinet logic drawing before installation.
        Can IC3600LCDA1 operate when no logic-expander card is connected?
        Yes. With A-E and OR-E left unconnected, IC3600LCDA1 functions as a normal two-input AND gate followed by its power-amplifier stage.
        How should a technician trace an expanded AND condition associated with IC3600LCDA1?
        Follow the external expansion wiring into the A-E path and check each contributing logic condition; IC3600LCDA1 will not produce a high result while that combined path is held low.
        Why is IC3600LCDA1 not an interchangeable generic PLC output board?
        IC3600LCDA1 is a dedicated Directo-Matic II clock logic driver with defined A-E and OR-E paths, so the surrounding control architecture must preserve those signal relationships.
        When many receiving logic points depend on one signal, what role does IC3600LCDA1 perform?
        The power-amplifier output of IC3600LCDA1 distributes the resolved logic state to multiple L-logic loads while the upstream inputs determine the final condition.
