3500/05

/ 4.9
1001 reviews | Need a Specific Revision?
The 3500/05 System Rack is the central framework for the Bently Nevada 3500 series machinery condition monitoring system. It provides housing, power, and connectivity for monitoring modules.
Get a quick price for 3500/05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/05
  • Product Family:
    3500 System
  • Rack Size Types:
    Full-size rack, 3500/05 Mini-Rack
  • Full-size Rack Specification:
    19-inch EIA rack with 14 available module slots
  • 3500/05 Mini-Rack Specification:
    12-inch rack with 7 available module slots
  • Rack Ordering Formats:
    Panel Mount / Rack Mount / Bulkhead Mount
  • Rack Mount Features:
    Mounts on 19-inch EIA rails; wiring and I/O access from the rear
  • Bulkhead Mount Features:
    Mounts against a wall or panel where rear access is not possible; wiring and I/O accessible from the front
  • 3500/05 Bulkhead Mount Availability:
    Not available in Bulkhead Mount format
  • Weight:
    6.4 kg
  • Estimated shipping dimensions:
    48.8x26.5x26.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The 3500 System rack is designed to mount all 3500 monitor modules and power supplies. By placing the modules close to each other, the rack enables smooth communication between them and provides the necessary structure to install power supplies that distribute power to every module. Among these options, the 3500/05 plays a key role as the Mini-Rack format within the system lineup.

3500 racks come in two size options. The full-size rack is a standard 19-inch EIA rack offering 14 available module slots, while the 3500/05 Mini-Rack is a compact 12-inch version providing seven available module slots. These options give users flexibility in selecting the optimal configuration for their installation environment.
Alternative Names
3500-05 3500-05-01-02-00-CN-01 3500-05-01-01-00-00-01 3500-05-01-02-00-00-00 3500-05-01-02-00-00-01 3500-05-02-05-00-00-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the features of the Panel Mount format?
It mounts to rectangular panel cutouts and is secured using supplied clamps. Wiring connections and I/O modules are accessible from the rear.
Which positions must the power supplies and rack interface module occupy?
They must occupy the far-left rack positions.
How many module slots are available in the full-size rack?
There are 14 slots available for any combination of modules.
How many module slots are available in the 3500/05 Mini-Rack?
There are 7 slots available for any combination of modules.
