Bently Nevada 3500/05-01-01-01-00-01 is a 19-inch, 14-slot panel-mount 3500 System rack with CSA/NRTL/C Class I Division 2 approval and CE compliance.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 3500/05-01-01-01-00-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/05-01-01-01-00-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/05-01-01-01-00-01
  • Product Family:
    3500 System
  • Product Type:
    System Rack
  • Stock:
    1
  • Rack size:
    19-inch full-size rack
  • Available monitor positions:
    14
  • Mounting option:
    Panel mount
  • Agency approval:
    CSA/NRTL/C, Class I Division 2
  • Reserved option:
    None
  • European compliance:
    CE
  • Power-supply position:
    Far left
  • Interface-module position:
    Adjacent to power supplies
  • Full-size rack width:
    482.60 mm (19.000 in)
  • Mounting width:
    441.96 mm (17.400 in)
  • Rack depth:
    349.25 mm (13.750 in)
  • Depth with internal barriers:
    422.91 mm (16.650 in)
  • Panel cutout width:
    452.1 +/- 1.5 mm
  • Panel cutout height:
    251.5 +/- 1.5 mm
  • EMC:
    EN 61000-6-2 and EN 61000-6-4
  • Electrical safety:
    EN 61010-1
  • Maritime references:
    DNV GL and ABS rules listed in Datasheet 141525
  • Weight:
    14.37 lbs (6.52 kg)
  • Estimated shipping dimensions:
    265.94 x 482.60 x 246.38 mm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Rack Architecture Compatibility Standards

Features:

  • Provides fourteen monitor positions in the full-size 19-inch 3500 rack.
  • Uses the panel-mount configuration selected by ordering option 01.
  • Includes the Class I Division 2 approval and CE ordering options.
The current ordering configuration is 3500/05-01-01-01-00-01, the 19-inch panel-mount rack with fourteen monitor slots, CSA/NRTL/C approval and CE compliance.

The backplane houses the power, interface and monitoring modules that form a 3500 machinery protection and condition-monitoring system.

Before panel installation, verify the cutout, rack depth, power-supply arrangement, RIM or TDI selection, module count, barrier requirement and project approval drawings.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Bently Nevada 3500/05-01-01-01-00-01:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Builds a centralized 3500 rack for continuous protection of turbines, compressors, motors and generators.
  • Supports panel-mounted machinery monitoring in control rooms and packaged equipment cabinets.
  • Provides the chassis platform for mixed vibration, position, temperature, speed and relay modules.
  • Power supplies and the rack interface module occupy the dedicated positions at the far left.
  • Fourteen remaining full-size positions accept compatible 3500 monitoring and relay modules.
  • The backplane provides the internal power and data path between installed rack components.
  • Full-size 3500 modules use the standard rack positions documented for the system.
  • Internal barriers require the 3500/04-01 earthing module and consume a dedicated position.
  • The selected panel-mount chassis must be matched to the recommended cutout dimensions.
  • The 01 approval code selects CSA/NRTL/C Class I Division 2 suitability when installed as documented.
  • The final 01 field selects CE compliance for the rack configuration.
  • EMC and electrical-safety references include EN 61000-6-2, EN 61000-6-4 and EN 61010-1.
Description
3500/05-01-01-01-00-01 is the full-size panel-mount rack configuration for the Bently Nevada 3500 machinery protection system. It provides fourteen monitor positions after the fixed power-supply and rack-interface positions at the left side.

The ordering code selects a 19-inch rack, panel-mount construction, CSA/NRTL/C Class I Division 2 approval, no reserved option and CE compliance. The backplane distributes power and internal communications to the installed 3500 modules.

This rack forms the mechanical and electrical platform for a configured protection system in control panels and equipment cabinets. Module layout, power supplies, interface hardware, barriers and panel cutout must be engineered as one documented assembly.
Alternative Names
3500/05-01-01-01-00-01 3500050101010001 3500 05 01 01 01 00 01 3500/05-01-01-01-00-01 3500 System Rack 3500/05-01-01-01-00-01 19-inch Full-Size Rack 3500/05-01-01-01-00-01 14-Slot System Rack 3500/05-01-01-01-00-01 Panel-Mount CE Rack Bently Nevada 3500/05 System Rack
Technical notes
3500/05-01-01-01-00-01 reserves the far-left positions for power supplies and the rack interface; do not insert monitor modules into those locations.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How many monitor positions does 3500/05-01-01-01-00-01 provide?
It is the full-size rack with fourteen available monitor positions after the fixed power and interface locations.
Which mounting style is encoded by 3500/05-01-01-01-00-01?
The second option field selects the full-size panel-mount arrangement.
Can internal barriers be added to 3500/05-01-01-01-00-01 without another rack component?
No. Internal barriers require the 3500/04-01 earthing module and the additional rack position specified by the manufacturer.
What protection systems use 3500/05-01-01-01-00-01?
It supports configured 3500 racks for continuous machinery protection and condition monitoring across critical rotating assets.
Which dimensions should be checked before replacing 3500/05-01-01-01-00-01?
Confirm the panel cutout, 19-inch rack width, rear clearance and the increased depth if internal barriers are installed.
What information is needed to quote 3500/05-01-01-01-00-01?
Provide the rack layout, power-supply count, TDI or RIM type, barrier requirement, approvals and destination.
