Features:
- Defined length: The order code retains a 4.00 m electrical-length configuration.
- Armored build: Adds mechanical protection for the installed cable route.
- Signal path: Extends the coaxial connection within a documented proximity system.
The electrical-length code matters to the complete transducer circuit.
Armor protects the cable but does not remove bend-radius or connector-care requirements.
System suitability should be checked against the applicable probe and signal-conditioner documentation.
Apter Power supports 24710-040-01 quotations, legacy document searches, and proximity-system cable review.
Bently Nevada 24710-040-01 Legacy Proximity-System Armored Extension Cable, 4.00 m Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Armor: Inspect the protective layer for crushing, separation, or sharp deformation.
- Jacket: Reject cuts, heat damage, or contamination that may expose the signal path.
- Connectors: Protect mating surfaces from dirt, impact, and excessive tightening.
- Label: Keep the complete order code readable throughout installation.
- Bend radius: Avoid tight turns that can damage the coaxial structure.
- Support: Secure the cable without clamping hard enough to deform it.
- Separation: Follow the site drawing for distance from heat, power wiring, and moving parts.
- Continuity: Test the cable with the approved method before connection.
- Connector seating: Clean and engage both ends without twisting the cable body.
- Grounding: Retain the documented shield and armor bonding practice.
- System test: Verify sensor output and conditioner response after the route is complete.
- Proximity systems: Extends the signal cable in documented legacy transducer installations.
- Protected routing: Supports paths that require additional mechanical protection.
- Maintenance spares: Provides an exact-code cable for retained machinery-monitoring loops.
