Emerson PR6423/010-110 CON021 is an M10 x 1 armoured 8 mm eddy current probe system with a 5 m LEMO cable and CON021 converter. It delivers a linearized two-millimetre shaft-displacement measurement for rotating machinery protection.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for PR6423/010-110 CON021
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/010-110 CON021

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/010-110 CON021
  • Product Family:
    Epro
  • Product Type:
    Armoured Eddy Current Transducer System
  • Stock:
    1
  • Probe tip diameter:
    8 mm
  • Nominal range:
    2 mm
  • Static gap setting:
    0.5 mm
  • Scale factor:
    8 V/mm ±5% from 0 to 45 °C
  • Linearity deviation:
    ±0.025 mm
  • Dynamic response:
    0 to 20 kHz
  • Probe thread:
    M10 x 1
  • Cable armour:
    Provided
  • Sensing-body length:
    25 mm
  • Overall probe-body length:
    34 mm
  • Adapter plug:
    Not fitted
  • System cable length:
    5 m
  • Termination:
    LEMO
  • Calibration steel:
    42CrMo4 / AISI 4140
  • Ingress protection:
    IP66
  • Hot-end temperature range:
    -35 to 180 °C
  • Converter and cable temperature range:
    -35 to 150 °C
  • Signal converter:
    CON021
  • Converter output span:
    -2 to -18 V
  • Converter linearity error:
    1% maximum
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    24x21x4cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Performance Integration Safety & Compliance

Features:

  • Uses protective cable armour around the five-metre probe lead.
  • Fits an M10 x 1 mounting thread with the standard 25 mm sensing body.
  • Produces a CON021 output proportional to the shaft gap across the calibrated range.
This option is the straight M10 probe with cable armour, standard body length and no adapter plug.

It supplies the primary radial-vibration or axial-position signal required by a machinery-monitoring channel.

Mounting stiffness and undisturbed cable routing are critical because mechanical movement outside the shaft gap becomes measurement error.

Apter Power can review sourcing, documentation and system matching for PR6423/010-110 CON021.
Verified resources for Emerson PR6423/010-110 CON021: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Turbine bearing brackets use the armoured cable where the route passes near metalwork that could abrade an unprotected lead.
  • Gearboxes can measure shaft relative vibration before it reaches damaging levels.
  • Condition-monitoring systems record the converter output to correlate rotor movement with speed and load changes.
  • The calibrated scale factor is 8 V/mm with the stated tolerance from 0 to 45 °C.
  • The transducer follows shaft motion from static displacement through 20 kHz dynamic content.
  • Differential sensitivity linearity is held within the documented ±0.025 mm deviation.
  • The LEMO cable end mates to the CON021 converter used for signal conditioning.
  • Protection systems must accept the standard negative-voltage output of the converter.
  • A five-metre total electrical length is part of the calibration and must be preserved.
  • Cable armour provides mechanical protection but must remain free of crushing and sharp bends.
  • The probe bracket should prevent the tip from contacting the shaft throughout expected movement.
  • Installation work requires the monitored machine to be secured against rotation before gap adjustment.
Description
PR6423/010-110 CON021 uses the standard 25 mm sensing-body length with M10 x 1 thread and protective cable armour. The option code defines a five-metre cable without an adapter plug, terminated for the CON021 converter.

High-frequency excitation at the probe creates an eddy-current field in the shaft surface. Shaft approach changes the coil response, and the converter translates that response into the voltage used for vibration and position channels.

Armour protects the cable mechanically but does not remove bend-radius or temperature restrictions. Thread engagement, cable routing, steel target properties and the complete five-metre electrical length must remain within the calibrated installation.
Alternative Names
PR6423/010-110 CON021 Emerson PR6423/010-110 EPRO PR6423/010-110 PR6423 010 110 PR6423010110 CON021 PR6423 M10 Armoured Probe EPRO PR6423 5 m Probe CON021 PR6423/010-110
Technical notes
Protect the armour and connector on PR6423/010-110 CON021 during installation; kinks or cable-length changes invalidate the matched measurement path.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which mechanical option is built into Emerson PR6423/010-110 CON021?
It has an M10 x 1 straight probe body with protective armour over the cable.
How long is the calibrated lead for Emerson PR6423/010-110 CON021?
The complete option code specifies a five-metre system cable ending in a LEMO connector.
What role does Emerson PR6423/010-110 CON021 play in machinery protection?
It measures shaft-relative displacement or vibration and feeds the linearized signal to a monitoring channel.
Why should Emerson PR6423/010-110 CON021 target material be confirmed?
Its scale and linearity are calibrated against 42CrMo4 or AISI 4140 steel and can shift on other metals.
Which installation details decide whether Emerson PR6423/010-110 CON021 fits?
Check M10 thread depth, 25 mm body length, bracket stiffness, cable path, target diameter and available gap.
How can the exact Emerson PR6423/010-110 CON021 system be quoted?
Specify the entire suffix and CON021 converter, not only the PR6423 family name.
