    Apter Power can support sensor-converter identification, documentation, and sourcing for PR6424/000-101 CON031.

PR6424/000-101 CON031

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR6424/000-101 CON031 is a 16 mm PR6424 eddy-current probe configuration paired with a CON031 signal converter for non-contact shaft displacement measurement. Use the complete order code when matching a replacement.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PR6424/000-101 CON031
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6424/000-101 CON031

  • Manufacturer:
    Emerson
  • Part Number:
    PR6424/000-101 CON031
  • Product Family:
    Epro
  • Product Type:
    Eddy Current Sensor and Signal Converter
  • Stock:
    1
  • Sensor family:
    PR6424
  • Nominal tip class:
    16 mm
  • Measurement principle:
    Eddy current
  • Converter model:
    CON031
  • Connection form:
    Open-wire probe input
  • Primary measurement:
    Relative displacement
  • Typical machinery use:
    Shaft vibration and position
  • Sensor temperature range:
    -35 to +120 °C nominal
  • Pressure resistance:
    10000 hPa at sensor head
  • Vibration resistance:
    5 g at 60 Hz
  • Cable construction:
    Oil and chemical resistant
  • Converter supply:
    -23 to -32 V DC
  • Mounting dependency:
    Order-code specific thread and sleeve
  • Calibration dependency:
    Probe, cable and converter set
  • Standards context:
    API 670 machinery monitoring
  • Weight:
    0.26 kg
  • Estimated shipping dimensions:
    16x15x3cm
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Temperature Range Control Environmental

Features:

  • The ordered configuration is a 16 mm PR6424 eddy-current probe configuration paired with a CON031 signal converter for non-contact shaft displacement measurement.
  • In service, the hardware turns the probe's target-distance response into a conditioned signal for machinery protection and condition monitoring.
  • Correct selection depends on probe suffix, cable length, converter range, target material, mounting thread and monitoring-channel polarity.
The current order is identified by the complete PR6424/000-101 CON031 marking and its documented relationship to EPRO PR6424 Eddy Current Measurement.

The hardware is used in radial vibration, axial position and relative shaft-displacement measurement on large rotating machinery, where it turns the probe's target-distance response into a conditioned signal for machinery protection and condition monitoring.

Installation planning must account for probe suffix, cable length, converter range, target material, mounting thread and monitoring-channel polarity. probe and converter calibration form one measuring chain; changing cable length or converter range can alter scale and linearity

Availability is confirmed against the complete model, revision, quantity and delivery destination.
Verified resources for Emerson PR6424/000-101 CON031:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Supports radial vibration, axial position and relative shaft-displacement measurement on large rotating machinery without changing the documented host architecture.
  • Serves maintenance teams restoring the original EPRO PR6424 Eddy Current Measurement signal, control or power path.
  • Fits modernization planning when the existing installation must remain operational while a long-term migration is evaluated.
  • Operate the unit only inside the environmental limits published for the complete EPRO PR6424 Eddy Current Measurement assembly.
  • Cabinet temperature, condensation control, contamination and airflow remain installation-level responsibilities.
  • Storage and transport conditions should protect connectors, electronics and calibration-sensitive elements before commissioning.
  • Use host-system status, alarms and service indications to verify the eddy current sensor and signal converter after installation.
  • Trend or diagnostic records from the original unit provide the baseline for detecting a channel, network or configuration mismatch.
  • A successful replacement requires both a clear hardware status and a functional test of the assigned radial vibration.
  • Operate the unit only inside the environmental limits published for the complete EPRO PR6424 Eddy Current Measurement assembly.
  • Cabinet temperature, condensation control, contamination and airflow remain installation-level responsibilities.
  • Storage and transport conditions should protect connectors, electronics and calibration-sensitive elements before commissioning.
Description
Emerson PR6424/000-101 CON031 defines a 16 mm PR6424 eddy-current probe configuration paired with a CON031 signal converter for non-contact shaft displacement measurement. The complete order identity ties this hardware to the EPRO PR6424 Eddy Current Measurement platform rather than to a visually similar device.

Within the installed architecture, it turns the probe's target-distance response into a conditioned signal for machinery protection and condition monitoring. Its principal connection boundary is the complete probe cable and matching CON031 converter connected to a compatible monitoring input, making the unit suitable for radial vibration, axial position and relative shaft-displacement measurement on large rotating machinery.

For a controlled replacement, confirm probe suffix, cable length, converter range, target material, mounting thread and monitoring-channel polarity. Probe and converter calibration form one measuring chain; changing cable length or converter range can alter scale and linearity
Alternative Names
PR6424/000-101 CON031 PR6424000101CON031 PR6424 000 101 CON031 Emerson PR6424/000-101 CON031 Emerson PR6424000101CON031 PR6424/000-101 CON031 Eddy Current Sensor and Signal Converter Emerson 16 mm Eddy Current Sensor with Converter PR6424/000-101 CON031 EPRO PR6424 Eddy Current Measurement
Technical notes
During a PR6424/000-101 CON031 exchange, probe and converter calibration form one measuring chain; changing cable length or converter range can alter scale and linearity
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What eddy current sensor and signal converter confirms the exact PR6424/000-101 CON031 configuration?
Use the complete model and the defining configuration: a 16 mm PR6424 eddy-current probe configuration paired with a CON031 signal converter for non-contact shaft displacement measurement. Include every suffix and secondary assembly number shown on the nameplate.
Which installed-system evidence is decisive for matching PR6424/000-101 CON031 as a eddy current sensor and signal converter?
Confirm probe suffix, cable length, converter range, target material, mounting thread and monitoring-channel polarity. The match must be made to the installed EPRO PR6424 Eddy Current Measurement records, not only to appearance.
Where does PR6424/000-101 CON031 perform its documented eddy current sensor and signal converter duty?
The documented application is radial vibration, axial position and relative shaft-displacement measurement on large rotating machinery. In service, it turns the probe's target-distance response into a conditioned signal for machinery protection and condition monitoring.
How should a buyer establish the present supply route for PR6424/000-101 CON031?
The OEM lifecycle is recorded as Active / Available from OEM. Apter Power confirms actual condition, available quantity, lead time and destination before issuing a dated offer.
What field condition can prevent a like-for-like PR6424/000-101 CON031 replacement?
Probe and converter calibration form one measuring chain; changing cable length or converter range can alter scale and linearity Compare the proposed unit with other PR6424 cable and converter options only through official service documentation.
Which records should accompany a PR6424/000-101 CON031 datasheet and quotation request?
Send clear nameplate photos, host model, revision, wiring or slot reference, required quantity, destination and requested delivery date so the exact datasheet and quotation can be matched.
