Emerson 1C31222G01 5A26458G05 is an Ovation relay-output panel combining a KUEP-style base, electronics module and 12 Form X relays.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1C31222G01 5A26458G05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1C31222G01 5A26458G05

  • Manufacturer:
    Emerson
  • Part Number:
    1C31222G01 5A26458G05
  • Product Family:
    Ovation
  • Product Type:
    12-Channel Form X Relay Output Panel
  • Stock:
    1
  • Ovation output channels:
    12
  • Relay contact form:
    Form X, KUEP electromechanical
  • Relay output base:
    1C31222G01
  • Panel kit:
    5A26458G05
  • Electronic module:
    1C31219G01
  • Form X contact rating:
    10 A at 240 VAC, PF 0.8; 10 A at 150 VDC
  • Relay-coil supply:
    Ovation auxiliary supply, 25 V typical
  • Weight:
    1.66 kg
  • Estimated shipping dimensions:
    42.2 x 12.4 x 8.2 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Singapore
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Relay Architecture Terminal Wiring Branch Power Product Applications

Features:

  • Form X execution: twelve KUEP electromechanical relays provide the output contact arrangement listed for G05.
  • Assembly identity: 1C31222G01 names the base and 5A26458G05 names the populated relay-panel kit.
  • Ovation interface: the 1C31219G01 electronics module links controller output commands to the relay assembly.
Contact decision: The G05 kit uses Form X contacts, unlike the G04 Form C version; match the installed terminal plan before selecting a spare.

Power decision: Relay coils depend on the compatible Ovation auxiliary-power branch, so the base is not selected as a free-standing relay bank.

Service decision: The base, electronics module and twelve installed relays define the assembly scope when comparing an exact-model replacement.

Apter Power supports Emerson 1C31222G01 5A26458G05 Ovation relay-panel sourcing with quotations, technical documentation and wiring-configuration review.
Emerson 1C31222G01 5A26458G05 12-Channel Form X Relay Output Panel Manuals,Datasheets,Link
Important Notice: Match the G05 Form X kit and 1C31222G01 base to the installed Ovation output drawing when requesting documentation.
  • Controller interface: 1C31219G01 receives the Ovation command path and drives the panel's mechanical relays.
  • Installed form: the G05 assembly contains twelve KUEP Form X relays rather than the G04 Form C set.
  • Base distinction: 1C31222G01 is the high-power relay base, not the separate 16-channel G2R base.
  • Form X access: the usable field connections are normally open and common.
  • Unused position: the NC terminal position has no Form X contact and remains outside the field circuit.
  • Panel record: labeled channel terminals should be reconciled with the as-built field wiring before a replacement.
  • Coil source: Emerson recommends the internal Ovation auxiliary supply for relay-coil power.
  • Ground reference: the specified distribution module ties Main and Aux grounds through its installed ground bars.
  • Branch fit: the relay base belongs only on an I/O branch with the specified +24 V typical auxiliary supply.
  • Power-plant outputs: an Ovation controller can use the relay panel to command suitable field switching circuits.
  • Process equipment: twelve Form X contact channels support multiple discrete output duties within one cabinet panel.
  • Exact-panel maintenance: the G05 identifier distinguishes the required Form X populated assembly from other KUEP variants.
Description
In an Ovation relay-output branch, 1C31222G01 5A26458G05 identifies a 12-channel KUEP-style panel assembly. Emerson lists the G05 kit with a relay-output electronics module, the relay base and twelve Form X relays; the base and kit numbers describe related but different parts of the requested assembly.

The electronics module coordinates controller commands with electromechanical relay outputs, while the installed Form X contacts switch the connected field circuits. For 1C31222G01 5A26458G05, the Form X arrangement matters because the contact access and DC switching capability differ from the Form C and 16-channel G2R alternatives.

A power-generation or process-control cabinet may use this panel where the Ovation controller must command higher-current field loads through relay contacts. When specifying 1C31222G01 5A26458G05 for service, the panel-kit suffix, contact form, branch auxiliary supply and terminal wiring should agree with the installed drawing.
Alternative Names
Emerson 1C31222G01 5A26458G05 Ovation 1C31222G01 5A26458G05 Westinghouse Ovation 1C31222G01 5A26458G05 1C31222G01 Form X relay base 5A26458G05 Form X relay panel kit 1C31222 G01 5A26458 G05 1C31222G01/5A26458G05 1C31222G01-5A26458G05
Technical notes
The Form X panel uses its NO and common terminals; the NC position is not a usable Form X contact. Emerson requires external current limiting for the relay-output circuit and specifies shared Main/Aux grounding with a compatible +24 V auxiliary branch. Apter Power can help compare the existing wiring and power-distribution drawing before an exact-assembly quotation.
