5X00241G02

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson 5X00241G02 is an Ovation OCR400 processor module for redundant controller operation.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 5X00241G02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5X00241G02

  • Manufacturer:
    Emerson
  • Part Number:
    5X00241G02
  • Product Family:
    Ovation
  • Product Type:
    Ovation OCR400 Processor Module
  • Stock:
    1
  • Controller Platform:
    OCR400
  • Module Function:
    Processor Module
  • Processor:
    Intel Celeron, 400 MHz
  • Operating System:
    VxWorks
  • Flash Memory:
    64 MB
  • DRAM:
    64 MB, expandable to 128 MB
  • Process-Point Capacity:
    Up to 32,000 points
  • I/O Capacity:
    Up to 4,778 I/O points
  • Control Tasks:
    5
  • Tariff Code:
    9032900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Network Redundancy Software Application
  • Documented Emerson processor-module catalog option for the Ovation OCR400 controller
  • Provides processor-side execution and communication with the Ovation network
  • Operates in an OCR400 architecture documented for redundancy and watchdog supervision

5X00241G02 is an Emerson OCR400 Processor Module designed for the Ovation distributed control platform.

Its role is separated from the OCR400 IOIC module: the processor module communicates with the Ovation network, while the IOIC module communicates with connected I/O devices.

Before installation or replacement, verify the complete catalog label, controller assembly, IOIC pairing, network connections, controller database, and redundant-partner configuration.

Availability, condition, price, and shipping time for 5X00241G02 are confirmed during quotation.

Emerson 5X00241G02 Ovation OCR400 Processor Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The processor module communicates with the Ovation network
  • Nine processor-module indicators report documented network-status conditions
  • Controller-to-controller communication is supported within the Ovation system architecture
  • The OCR400 controller is documented as an entirely redundant design
  • Bumpless failover transfers control to the backup controller when required
  • Watchdog operation supervises the documented controller pair
  • OCR400 controller operation uses the VxWorks operating system
  • Control execution is divided among five controller tasks
  • The platform supports standard Ovation control and documented third-party communications
  • Redundant Ovation process control in power-generation facilities
  • OCR400 controller applications in water-process automation
  • Distributed control applications requiring Ovation network and local I/O integration
Description
5X00241G02 is an Emerson Ovation OCR400 Processor Module for the documented OCR400 distributed control platform.

The module provides processor-side controller execution and Ovation-network communication within an OCR400 architecture that assigns I/O-device communication to a separate IOIC module.

Before installation or replacement, confirm the complete 5X00241G02 label, OCR400 assembly, IOIC pairing, network wiring, controller database, and redundant-partner arrangement.
Alternative Names
Emerson 5X00241G02 Emerson Ovation 5X00241G02 Ovation 5X00241G02 Ovation OCR400 5X00241G02 5X00241 G02 5X00241G02 Processor Module OCR400 Processor Module 5X00241G02
Technical notes
Emerson 5X00241G02 must be identified by its complete label and matched to the installed OCR400 assembly, IOIC module, Ovation network, database, and redundant-partner setup.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is Emerson 5X00241G02 the same component as the OCR400 IOIC module?
No. Emerson identifies 5X00241G02 as a processor-module option. The processor module handles Ovation-network communication, while the separate IOIC module communicates with I/O devices.
What modernization path should be evaluated for an Ovation OCR400 system using Emerson 5X00241G02?
Emerson documents the OCR1100 as sharing the OCR400 packaging concept and providing backward hardware compatibility. Before selecting this migration path, verify the installed Ovation release, controller cabinet, I/O interfaces, and project-specific conversion requirements.
Does Emerson 5X00241G02 support bumpless redundant-controller failover?
The OCR400 controller architecture is documented as redundant and supports bumpless failover between the primary and backup controllers.
What should be preserved before replacing Emerson 5X00241G02?
Preserve the controller database and record the installed processor/IOIC arrangement, Ovation-network connections, redundant-partner configuration, and complete module labels.
Can the control logic and database from an Emerson 5X00241G02 installation be carried forward during an OCR1100 upgrade?
Emerson states that migration programs are available for updating control logic and databases from earlier Ovation controller models. Back up and validate the active database, custom control sheets, tuning constants, and I/O mapping before conversion.
What should be checked before retaining existing I/O during modernization of Emerson 5X00241G02?
Do not assume that every installed I/O component can remain unchanged. Verify the exact local and remote I/O families, companion interface modules, branch and node arrangement, termination hardware, and Ovation software release against the selected replacement controller.
What identification should a buyer require before accepting Emerson 5X00241G02 as the correct spare?
Require a clear module-label image showing the complete 5X00241G02 catalog number. An OCR400 family description, memory statement, or 5X00241G01 label alone does not confirm that the offered processor module is the required G02 catalog item.
