- High-speed parallel-bus receiver for Series 90-70 expansion racks
- Supports a daisy chain of up to seven expansion racks
- Uses two 25-pin connectors and IC697ACC702 termination at the last rack
IC697BEM711 is a GE Fanuc Series 90-70 Bus Receiver Module designed for GE Fanuc Series 90-70 PLC expansion racks.
Installed in expansion-rack slot 1, it receives the PLC expansion bus and passes that bus to the next rack while monitoring rack and bus status.
Before installation or replacement, match rack ID jumpers to software, preserve cable order, install the last-rack terminator, and verify backplane power and diagnostic LEDs.
Availability, condition, price, and shipping time for IC697BEM711 are confirmed during quotation.
General Electric IC697BEM711 Series 90-70 Bus Receiver Module Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Install the module in expansion-rack slot 1
- Set the rack ID with jumpers behind the power supply
- Match the physical ID to the PLC hardware configuration
- Connect the upstream cable to the incoming bus connector
- Use the outgoing connector only when another expansion rack follows
- Fit IC697ACC702 termination at the final rack
- BOARD OK indicates successful module diagnostics
- BUS ACTIVE indicates communication on the expansion bus
- LAST RACK confirms the terminated end of the physical chain
- Series 90-70 PLC expansion racks
- Multi-rack industrial automation systems
- Distributed Series 90-70 I/O expansion over the parallel bus
