    Apter Power can quote and source IC600PM542 and provide the applicable General Electric GEK-90762 manufacturer documentation.

IC600PM542

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC600PM542 is a Series Six 24 VDC high-capacity I/O rack power supply with 20–32 VDC input and regulated +5, +12, and -12 VDC outputs.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC600PM542
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC600PM542

  • Manufacturer:
    General Electric
  • Part Number:
    IC600PM542
  • Product Family:
    GE Series Six Plus
  • Product Type:
    24 VDC High-Capacity I/O Rack Power Supply
  • Stock:
    1
  • Rack use:
    Series Six high-capacity I/O rack
  • Input voltage:
    20 to 32 VDC
  • +5 VDC output:
    Regulated rack backplane rail
  • +12 VDC output:
    Regulated rack backplane rail
  • -12 VDC output:
    Regulated rack backplane rail
  • Rack load capacity:
    275 load units
  • Application:
    High-current and remote-with-modem I/O configurations
  • Replacement scope:
    Can replace an AC-input high-capacity I/O supply when source voltage changes
  • Standard-supply substitution:
    Not a substitute for a standard I/O power supply
  • Main switch:
    Front LOGIC POWER ON/OFF switch
  • Input fuse:
    8 A slow-blow internal fuse
  • Polarity protection:
    Protected against reversed DC input
  • Power indicator:
    Monitors +5, +12, and -12 VDC output tolerance
  • Power-fail signal:
    PSOK for initialization and error indication
  • Input termination:
    Covered front-panel source terminal block
  • Rack location:
    Far right side of the I/O rack
  • Main-board connection:
    Internal terminal strip
  • Grounding:
    Dedicated chassis-ground terminal
  • Auxiliary connection:
    Auxiliary-circuit-board connector
  • Front-panel connection:
    Front-panel connector block
  • Module retention:
    Upper and lower quarter-turn thumbscrews
  • Installation check:
    Confirm estimated I/O load before installation
  • Compliance:
    UL 508 industrial control equipment
  • Tariff Code:
    8504409999
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Input Outputs Install Status

Features:

  • IC600PM542 accepts a 20–32 VDC industrial source.
  • Three regulated rails power high-current I/O loads.
  • PSOK signaling supports rack initialization and fault reporting.
The supply serves high-capacity Series Six I/O racks and remote I/O applications that include modem equipment.

Its POWER indicator monitors the +5, +12, and -12 VDC rails, while the input stage guards against reversed polarity.

A covered source terminal block, 8 A slow-blow fuse, and quarter-turn mounting hardware support field replacement.

Apter Power supports quotation requests for the General Electric IC600PM542 24 VDC High-Capacity I/O Rack Power Supply and can provide relevant manufacturer manuals or product documentation.
General Electric IC600PM542 24 VDC High-Capacity I/O Rack Power Supply Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Preparing the 20–32 VDC source

  • Range: Use a source between 20 and 32 VDC.
  • Polarity: Verify positive and negative conductors before energizing.
  • Fuse: Reversed polarity can open the internal 8 A slow-blow fuse.
  • Terminal safety: Refit the lower plastic cover after wiring.

Powering high-capacity I/O configurations

  • Rails: IC600PM542 supplies regulated +5, +12, and -12 VDC.
  • Capacity: Use the module only for high-capacity I/O rack loads.
  • Remote I/O: The output set supports remote-with-modem installations.
  • Load check: Total the current units for every installed I/O module.

Replacing the I/O rack power supply

  • Shutdown: Stop the CPU and remove all system power.
  • Position: Locate the supply at the far right of the I/O rack.
  • Connections: Record input and internal wire positions before removal.
  • Restart: Lock both thumbscrews, restore power, and confirm the POWER light.

Interpreting power-supply status

  • POWER on: All three regulated output rails are within tolerance.
  • POWER off: At least one regulated output is too low.
  • PSOK: The rack receives initialization and power-fail status.
  • Fault path: Recheck polarity, fuse, rack load, and internal connections.
Description
The General Electric IC600PM542 24 VDC High-Capacity I/O Rack Power Supply operates from a 20–32 VDC source and feeds regulated +5, +12, and -12 VDC rails to Series Six I/O modules.

High-current configurations use IC600PM542 when the standard I/O supply cannot meet the rack load. The three regulated outputs also support remote I/O applications that include modem equipment.

Front-panel hardware on IC600PM542 includes the LOGIC POWER switch, an 8 A slow-blow fuse, a covered source terminal block, and a POWER indicator that monitors all three output rails.

Located at the far right of the rack, IC600PM542 connects to the backplane through internal wiring and an auxiliary-board connector. A PSOK signal supports system initialization and power-failure indication.
Alternative Names
IC600 PM542 IC600-PM542 IC-600-PM-542 GE IC600PM542 General Electric IC600PM542 Series Six 24 VDC I/O Supply IC600PM54Z IC600PMS42
Technical notes
Before energizing IC600PM542, verify the 20–32 VDC input polarity, confirm the estimated I/O load is within the high-capacity supply rating, and reinstall the terminal cover.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can IC600PM542 remain off after a DC-source change?
IC600PM542 requires 20-32 VDC with correct polarity; reversed wiring can open the internal 8 A slow-blow fuse.
Can IC600PM542 replace an AC high-capacity supply without changing rack duty?
Yes. IC600PM542 can serve the same high-capacity I/O role when the source changes to 24 VDC, but it is not a standard-rack supply.
Which rack installations need an adapter with IC600PM542?
IC600PM542 fits IC600YR511 directly; IC600YR510 and IC600YR512 require the applicable I/O power-supply cable adapter kit.
What does an unlit IC600PM542 POWER indicator mean?
On IC600PM542, the light goes off when at least one of the +5, +12, or -12 VDC outputs is below tolerance.
How does IC600PM542 PSOK help during startup diagnosis?
IC600PM542 sends PSOK to the rack for initialization and power-failure indication, helping separate supply loss from normal I/O behavior.
Why must the load be calculated before installing IC600PM542?
IC600PM542 is a high-capacity supply, but the installed I/O modules must still remain within its available rack load.
What must be isolated before removing IC600PM542 from the rack?
Stop the controller and remove all system power before disconnecting IC600PM542 input, backplane, ground, and auxiliary-board connections.
