IC200ALG325

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC200ALG325 is an eight-channel 13-bit VersaMax voltage output module with jumper-selectable bipolar or unipolar operation.
In Stock
Ships by Thursday, October 1
Fast Shipping Available
Get a quick price for IC200ALG325
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200ALG325

  • Manufacturer:
    General Electric
  • Part Number:
    IC200ALG325
  • Product Family:
    GE VersaMax
  • Product Type:
    Analog Output Module
  • Stock:
    1
  • Output Channels:
    8 single-ended voltage outputs, one group
  • Selectable Ranges:
    –10.24 to +10.24 VDC or 0 to +10.24 VDC
  • Resolution:
    13-bit; 1.25 mV per step
  • Module Update:
    10 ms maximum
  • External Supply:
    +18 to +30 VDC at 102 mA maximum
  • Load:
    5 kΩ minimum resistive; 1.0 µF maximum capacitive
  • Crosstalk Rejection:
    70 dB minimum
  • Configuration:
    Range and output default by carrier jumpers
  • Diagnostics:
    Loss of user-side power
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Range Mode Output Recovery Terminal Groups Applications

Features:

  • Eight 13-bit voltage output channels
  • Hardware choice of bipolar or unipolar range
  • Independent jumper for interruption fallback
The General Electric IC200ALG325 catalog identifier refers to the eight-point, selectable-range voltage output module for VersaMax stations.

One range jumper selects how the full bank interprets controller words, and a separate hold jumper defines the result of a PLC, communications or backplane interruption.

Commissioning aligns both carrier links with the hardware configuration, applies field power and confirms the shared-return wiring plus load limits for all eight devices.

The General Electric IC200ALG325 Voltage Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200ALG325 Voltage Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

JMP1 Voltage-Span Selection

  • No link: Open B1–B2 terminals establish the –10 to +10 V bipolar range.
  • Installed link: Joining B1 and B2 selects 0 to +10 V unipolar operation.
  • Bank-wide effect: The chosen range applies to every output rather than one channel at a time.
  • Configuration mirror: The CPU or NIU project uses the same span selected on the carrier.
  • Power-off work: Field and backplane sources are removed before JMP1 is changed.

JMP2 Response to an Interruption

  • Hold-last state: Leaving B2–B3 open preserves the latest output command.
  • Zero default: Installing JMP2 sends the channels to 0 V for the documented loss events.
  • Field continuity: The external supply stays available if either fallback is expected to remain at the terminals.
  • Application awareness: Controller logic identifies the interruption so a retained value is not mistaken for a newly updated command.

Paired Returns Across Eight Outputs

  • Channels 1–2: The first pair uses the common return assigned at B6.
  • Channels 3–4: B10 provides the return for the second pair of voltage outputs.
  • Channels 5–6: A3 is the shared return for the third pair.
  • Channels 7–8: The final output pair returns through A7.
  • Shield points: Adjacent carrier terminals provide the documented cable-shield grounding locations.
  • Field feed: B18 and B17 carry the external DC source and return for the output circuits.

Selectable-Span Eight-Point Control

  • Uniform unipolar bank: Eight 0–10 V receivers can share one module and a common range selection.
  • Uniform bipolar bank: Signed commands support equipment that operates above and below a zero reference.
  • Cabinet consolidation: The eight-channel density reduces the number of carrier positions needed for a like-ranged device group.
  • Defined fallback: JMP2 lets machine design choose retained demand or a neutral 0 V response.
Description
Range flexibility is built into the eight outputs of the General Electric IC200ALG325. An open B1–B2 range link selects –10 to +10 V bipolar operation, while the installed jumper changes the entire bank to 0 to +10 V unipolar service.

Two carrier decisions shape the response of General Electric IC200ALG325: JMP1 selects the voltage span and JMP2 selects hold-last or 0 V after a rack or communications interruption. The physical links and the CPU or NIU configuration must describe the same operating mode before field devices are connected.

External +18 to +30 VDC powers the field side of General Electric IC200ALG325, and eight host words drive the channels at a 10 ms maximum module update. Shielded twisted-pair wiring, the numbered shared returns and the carrier's earth-ground method complete the analog output path.
Revisions

Revision Part #

Also known as

IC200ALG325E
IC200ALG325-E, Series E, Rev E
IC200ALG325H
IC200ALG325-H, Series H, Rev H
IC200ALG325J
IC200ALG325-J, Series J, Rev J
Alternative Names
IC200-ALG325 IC200 ALG325 IC 200 ALG 325 GE IC200ALG325 GE Fanuc IC200ALG325 Emerson IC200ALG325 VersaMax IC200ALG325 8-Channel Voltage Output IC200ALG32S
Technical notes
General Electric IC200ALG325 offers eight 13-bit voltage outputs with a module-wide jumper choice between bipolar and unipolar ranges. A second jumper selects hold-last or 0 V fallback.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is General Electric IC200ALG325 producing 0–10 V when the project expects a bipolar signal?
General Electric IC200ALG325 changes the complete output bank to unipolar operation when JMP1 links B1 and B2. Remove power, correct the jumper if bipolar operation is required and make the hardware configuration match the physical setting.
How does General Electric IC200ALG325 preserve a commanded value through a PLC stop?
General Electric IC200ALG325 holds the last state when JMP2 is absent between B2 and B3. The external field source must remain energized; installing JMP2 selects 0 V instead.
What must match after the voltage range on General Electric IC200ALG325 is changed?
General Electric IC200ALG325 requires the CPU or NIU hardware configuration to agree with the JMP1 range selection. Recheck scaling, zero behavior and the receiving device before enabling the outputs.
Eight channels on General Electric IC200ALG325 respond slowly together; is the load a factor?
General Electric IC200ALG325 is specified for 5 kΩ minimum resistive and 1.0 µF maximum capacitive loading. Compare every connected device and cable with those limits, then confirm the 10 ms module update is acceptable for the application.
Can General Electric IC200ALG325 use different voltage ranges on adjacent channels?
General Electric IC200ALG325 applies one JMP1 selection to the entire eight-channel group. Mixed bipolar and unipolar outputs therefore require separate modules or another supported hardware arrangement.
Where should shields from General Electric IC200ALG325 output cables terminate?
General Electric IC200ALG325 uses carrier-specific shield points. Terminal-style carriers can use their documented shield terminals or a grounded auxiliary strip, while connector-style installations route shields through a grounded interposing terminal.
