        • Lifecycle status

          Active / Available from OEM
          Apter Power supports sourcing and configuration matching for General Electric IC200UDD112.

        IC200UDD112

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC200UDD112 is a 14-point VersaMax Micro PLC with eight 12 VDC inputs and six 12 VDC outputs for compact low-voltage control.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IC200UDD112
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC200UDD112

        • Manufacturer:
          General Electric
        • Part Number:
          IC200UDD112
        • Product Family:
          GE VersaMax
        • Product Type:
          14-Point VersaMax Micro PLC
        • Stock:
          1
        • Built-in I/O:
          14 points
        • DC inputs:
          8 points, 12 VDC
        • DC outputs:
          6 points, 12 VDC
        • Logic memory:
          9K words
        • Data storage:
          256 words
        • Scan rate:
          1.1 ms per K
        • Serial interface:
          RS-232
        • Expansion capacity:
          Up to 4 modules
        • High-speed counters:
          Up to 4 at 10 kHz, 16-bit
        • Pulse/PWM outputs:
          Up to 4 at 5 kHz, 16-bit
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals 12 VDC I/O Memory RS-232 Applications

        Features:

        • Integrates eight 12 VDC inputs and six 12 VDC outputs in a 14-point footprint.
        • Executes four 16-bit high-speed counters at frequencies up to 10 kHz.
        • Generates as many as four 16-bit pulse or PWM channels at rates up to 5 kHz.
        General Electric IC200UDD112 targets low-voltage machines where fourteen local control points are sufficient and panel space is limited.

        The single RS-232 connection can serve program transfer or a supported serial peripheral, with communication parameters assigned in the controller project.

        Supercapacitor retention protects program resources during short interruptions, while applications requiring calendar time should provide that function elsewhere.

        The General Electric IC200UDD112 14-Point VersaMax Micro PLC may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        General Electric IC200UDD112 14-Point VersaMax Micro PLC Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Twelve-Volt Signal Coordination

        • Input Points: Eight input channels accept 12 VDC states from compatible proximity devices, switches, or interface relays.
        • Output Points: Six solid-state outputs provide 12 VDC commands to loads that stay within the permitted point current.
        • Logic Reference: Common connections should be arranged to match the positive or negative logic used by the field devices.
        • Load Suppression: Inductive loads require suitable suppression so switching transients do not disturb adjacent low-voltage signals.

        Compact Program Capacity

        • Logic Memory: The controller supplies 9K words of logic memory for machine sequences and safety-related interlocks outside the safety function.
        • Data Area: A 256-word data area holds setpoints, counters, and application variables needed by the control routine.
        • Scan Performance: The nominal scan performance is 1.1 milliseconds per K of logic, allowing task timing to be estimated during design.
        • Backup Method: Supercapacitor backup maintains retained resources without the battery and clock features found in larger Micro sizes.

        RS-232 Integration

        • Serial Interface: One RS-232 port supports programming access or communication with a compatible serial device.
        • Communication Format: Baud rate, data bits, parity, and protocol selection must be identical at both ends of the connection.
        • Cable Assignment: A point-to-point cable should follow the required pin assignment rather than a generic Ethernet wiring pattern.
        • Service Clearance: Service access remains easier when the panel design leaves clearance around the connector and cable bend radius.

        Compact Twelve-Volt Automation

        • Low-Voltage Equipment: Battery-powered or low-voltage equipment can read local sensors and drive small DC loads from one controller.
        • Test Fixtures: Test fixtures can use the built-in high-speed channels for event capture or pulse generation.
        • Small Conveyors: Small conveyors can coordinate permissives and actuator timing without a separate CPU and I/O rack.
        • Future Expansion: Expansion modules allow the original 14-point station to add specialized signals as the machine design evolves.
        Description
        The General Electric IC200UDD112 is a compact 14-point VersaMax Micro PLC that integrates eight 12 VDC inputs and six 12 VDC outputs for self-contained machine control.

        Its matching 12 VDC signal levels simplify direct coordination between low-voltage sensors and compatible actuators, while the input commons and output load paths remain defined by the controller terminal arrangement.

        The Micro 14 resource set provides 9K words of logic memory, 256 words of data storage, an RS-232 port, and supercapacitor-backed retention in the smallest controller size.

        Up to four expansion modules can supplement the built-in points, and PAC Machine Edition supports ladder and instruction-list programming for commissioning or program maintenance.
        Alternative Names
        IC200UDD112 VersaMax Micro PLC GE IC200UDD112 GE Fanuc IC200UDD112 IC200-UDD112 IC200UDD112 14-Point PLC IC200UDDI12 IC20OUDD112 1C200UDD112
        Technical notes
        General Electric IC200UDD112 is the 12 VDC Micro 14 configuration with supercapacitor retention and one RS-232 port. It does not include a real-time clock.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Which field voltage should be used with General Electric IC200UDD112?
        General Electric IC200UDD112 is arranged for 12 VDC input and output circuits, so field devices should match that voltage and the point ratings.
        Can General Electric IC200UDD112 run a high-speed counting task?
        General Electric IC200UDD112 supports as many as four 16-bit high-speed counter channels at rates up to 10 kHz when configured for the required mode.
        Does General Electric IC200UDD112 include a real-time clock?
        General Electric IC200UDD112 does not include a real-time clock, so applications that depend on calendar scheduling need an external timing source or another controller.
        How is a program retained in General Electric IC200UDD112?
        General Electric IC200UDD112 uses supercapacitor-backed retention for its program resources and does not use the battery arrangement of larger Micro units.
        Can an operator terminal communicate directly with General Electric IC200UDD112?
        A compatible operator terminal can use the RS-232 port on General Electric IC200UDD112 when its protocol, cable pinout, and serial settings agree.
        When is expansion appropriate for General Electric IC200UDD112?
        Expansion is appropriate when General Electric IC200UDD112 needs more I/O than its fourteen built-in points and the combined module power demand remains supported.
