          For IC200UEO116 quotation requests, Apter Power provides pricing assistance and access to applicable official GE and Emerson technical documentation.

        IC200UEO116

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC200UEO116 is a VersaMax Micro expansion unit that adds sixteen 24 VDC sink outputs to a compatible controller.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for IC200UEO116
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC200UEO116

        • Manufacturer:
          General Electric
        • Part Number:
          IC200UEO116
        • Product Family:
          GE VersaMax
        • Product Type:
          VersaMax Micro 16-Point Output Expansion Unit
        • Stock:
          1
        • Expansion Type:
          16-point output unit
        • Output Channels:
          16
        • Output Technology:
          Transistor, sink type
        • Field Voltage:
          24 VDC
        • Power Supply:
          24 VDC
        • Isolation:
          Field outputs optically isolated from logic
        • Field Common:
          Shared supply and common
        • Load Inrush Capability:
          Up to 8 times rated current
        • Negative Pulse Protection:
          Included
        • Short-Circuit Protection:
          External fast-acting fuse required
        • Tariff Code:
          8538901100
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Wiring Loads Protection Expansion

        Features:

        • Adds sixteen DC load-control points without introducing another processor.
        • Separates field-output circuitry from the controller logic through optical isolation.
        • Handles defined inrush and negative-pulse conditions encountered with industrial loads.
        The IC200UEO116 expansion format dedicates every point to output service, making it appropriate where a base controller needs additional actuators but no corresponding input channels.

        All sixteen points share the field-side supply and common architecture, so group-level power distribution has a direct effect on multiple channels at once.

        As part of the VersaMax Micro expansion family, the unit extends a compatible base PLC within that controller's supported number of expansion modules and overall power budget.

        Apter Power supports quotation requests and official GE/Emerson documentation access for the General Electric IC200UEO116 VersaMax Micro 16-Point Output Expansion Unit.
        General Electric IC200UEO116 VersaMax Micro 16-Point Output Expansion Unit Manuals, Datasheets, Links
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Field Circuit Arrangement for IC200UEO116

        • Switching direction: Each transistor point completes the load path toward the DC common instead of sourcing positive current.
        • Supply relationship: Field devices connect to the shared 24 VDC group supply with polarity suited to sink operation.
        • Common integrity: A loose or open common can affect several commanded outputs even when individual logic states are valid.
        • Logic boundary: Optical isolation prevents the field group from being treated as a direct electrical extension of the CPU electronics.

        Output Transients on IC200UEO116

        • Starting surge: A channel accepts a brief load inrush up to eight times its rated current within the specified pulse conditions.
        • Steady loading: Continuous current remains governed by the normal point and group ratings after startup.
        • Negative pulse: Output circuitry includes protection for reverse-going voltage transients produced by connected loads.
        • Load selection: Contactors, indicators, and other devices are checked for both holding demand and their switch-on behavior.

        Branch Protection for IC200UEO116

        • External fuse: A fast-acting protective device clears a sustained field-load short before damage propagates through the group.
        • Fault scope: Group supply and common conductors are inspected when several channels stop operating together.
        • Energy isolation: Field power is removed before changing output wiring or replacing the expansion unit.
        • Coordination: Fuse, conductor, terminal, and load ratings are selected as one branch circuit rather than independently.

        Adding IC200UEO116 to VersaMax Micro

        • Output growth: One unit adds sixteen actuator points to a controller that has insufficient built-in outputs.
        • CPU ownership: Logic execution remains in the base PLC while the expansion supplies only field-output channels.
        • Unit count: The complete chain stays within the expansion limit specified for the selected VersaMax Micro controller.
        • System power: Both logic-side and 24 VDC field demands are included before the expanded assembly is released.
        Description
        Sixteen additional actuator points are supplied by the General Electric IC200UEO116, a VersaMax Micro expansion unit whose transistor outputs switch 24 VDC loads in a sink arrangement.

        The field group on IC200UEO116 shares its supply and common while remaining optically isolated from controller logic. A loss in the common or group feed can therefore affect several loads even when CPU-side communication continues.

        Output circuitry accommodates the specified load inrush and includes negative-pulse protection for connected industrial devices. Continuous loading still remains governed by the point and group limits after the starting transient has passed.

        Logic execution stays in the compatible base PLC while IC200UEO116 supplies output expansion only. The unit count and combined logic-side and field-side demand must fit the expansion capacity of the selected VersaMax Micro controller.
        Alternative Names
        GE IC200UEO116 General Electric IC 200 UEO 116 IC 200 UEO 116 IC200-UEO116 IC200UEO-116 IC200UEO1I6 IC2O0UEO116 1C200UEO116
