Features:
- Integrates sixteen 12 VDC inputs and twelve normally open relay outputs.
- Provides RS-232 and RS-485 ports for programming, monitoring and serial networks.
- Adds a time-of-day clock, status LEDs and optional long-term battery backup.
The expanded point count lets General Electric IC200UDR006 handle more switches, proximity sensors, interlocks and externally powered actuators than a 14-point Micro PLC. Input polarity remains selectable for the field scheme.
Port 1 uses RS-232 on an RJ-45 connector, and Port 2 uses RS-485 on a DB-15 connector behind a removable door. Both channels monitor at once, while the project assigns programming and network roles to the appropriate port.
Four removable covered terminal strips organize field conductors, and individual I/O LEDs accompany the Power, OK and Run indicators. The battery holder accepts the optional backup assembly used with RAM and the real-time clock.
The General Electric IC200UDR006 28-Point 12 VDC VersaMax Micro PLC may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200UDR006 28-Point 12 VDC VersaMax Micro PLC Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Programming and Network Roles
- Port 1: Use the RS-232 RJ-45 interface for programming or SNP slave communication.
- Port 2: Configure the covered RS-485 DB-15 channel for SNP or RTU master/slave operation.
- RTU master support: Use Modbus RTU Master on Port 2 with firmware version 2.02 or later.
- Dual monitoring: Observe the controller through both ports concurrently while reserving programming for one channel.
Retention and Clock Support
- Capacitor reserve: RAM and the time-of-day clock retain data for at least 30 minutes without input power.
- Battery extension: Fit the optional lithium assembly when longer powered-down retention is necessary.
- Condition reporting: Read the PLC fault table and designated status bits for battery-state information.
- Flash source: Store configuration or application data in non-volatile flash for power-up loading.
Status and Field Checks
- CPU indicators: Use Power, OK and Run LEDs to identify the controller operating state.
- Point indicators: Compare each I/O LED with the wired device and the corresponding program reference.
- Input isolation: Field inputs are isolated from logic and separated into groups according to the wiring diagram.
- Covered terminals: After isolating power, remove a terminal assembly with its field wiring still attached.
Expanded Compact Control
- Multi-device sequencing: Sixteen inputs and twelve relay outputs coordinate larger compact machines.
- Mixed-voltage actuation: Relay contacts switch suitable AC or DC starters, solenoids and indicators.
- Serial supervision: Two ports connect programming tools and compatible serial equipment around one CPU.
- Timed operation: The integrated clock supports schedules and time-based controller logic.
