51307038-100

/ 4.9
1001 reviews | Need a Specific Revision?
51307038-100 is a Honeywell Series 8 power control module assembly with two 16–32 V DC inputs and eight outputs. It supplies the documented 24 V DC module-power path with voltage shutdown and alarm functions.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 51307038-100
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 51307038-100

  • Manufacturer:
    Honeywell
  • Part Number:
    51307038-100
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Series 8 Power Control Module Assembly
  • Stock:
    1
  • Official description:
    Power Control Module Assembly
  • System family:
    Experion Series 8
  • Power role:
    24 V DC module-power control
  • Number of inputs:
    2
  • Input voltage range:
    16 to 32 V DC
  • Number of outputs:
    8
  • Total load current:
    20 A maximum at 24 V DC
  • Under-voltage shutdown:
    Output below 19 V
  • Over-voltage shutdown:
    Output above 28 V
  • Alarm condition:
    DC input voltage outside normal status
  • Documented integration:
    Power source for Series 8 FIM4 modules
  • Weight:
    1.54 lbs (0.7 kg)
  • Estimated shipping dimensions:
    15 x 12 x 7.5 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Diagnostics Communication Efficiency

Features:

  • Accepts two independent 16 to 32 V DC input feeds.
  • Provides eight outputs with a 20 A total maximum load at 24 V DC.
  • Includes under-voltage, over-voltage, and abnormal-input alarm behavior.
The current ordering configuration is 51307038-100, the Honeywell Power Control Module Assembly identified in the Series 8 specification.

It controls the 24 V DC distribution path used to power supported modules in the documented FIM4 arrangement.

Confirm source redundancy, polarity, load budget, protection, grounding, alarm wiring, mounting, and the full part number before installation.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Honeywell 51307038-100:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Provide controlled 24 V DC power distribution for documented Series 8 FIM4 module arrangements.
  • Supervise redundant or dual DC inputs and signal abnormal source-voltage status.
  • Support cabinet power-control maintenance after total connected load and wiring are verified.
  • The complete system DC output is shut down when output voltage falls below 19 V.
  • The complete system DC output is shut down when output voltage rises above 28 V.
  • An alarm signal is generated when the DC input voltage is not in normal status.
  • Two DC input connections provide the documented source path for the assembly.
  • Eight output connections distribute controlled power to the supported Series 8 arrangement.
  • The alarm output must be wired to the cabinet monitoring circuit defined by the project.
  • The output bank supports a combined maximum load of 20 A at 24 V DC.
  • Load allocation must keep the total demand within the documented assembly limit.
  • Voltage supervision disconnects the system output rather than powering loads outside the specified window.
Description
Honeywell 51307038-100 is a Series 8 Power Control Module Assembly for the 24 V DC module-power path used with FIM4 installations. Two DC inputs feed eight supervised outputs within the documented Experion power arrangement.

The assembly accepts 16–32 V DC, supports a combined 20 A load at 24 V DC, and monitors abnormal source conditions. Under- and over-voltage shutdown plus alarm signaling protect connected module power and improve cabinet-level supply visibility.

Integration depends on source polarity, protective devices, grounding, total load, output allocation, alarm wiring, and the Series 8 mounting design. A verified current budget and output test ensure stable distribution to the connected fieldbus interface hardware.
Alternative Names
51307038-100 51307038 100 51307038100 Honeywell 51307038-100 Honeywell PCM 51307038-100 Honeywell Power Control Module Assembly Series 8 51307038-100 Honeywell Experion LX PCM
Technical notes
Calculate the combined Series 8 load for 51307038-100 and verify both DC sources, polarity, protection, grounding, shutdown thresholds, and alarm wiring before energizing outputs.
