    Apter Power provides Honeywell 51305348-100 quotations, product selection, and model matching.

51305348-100

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell 51305348-100 is a media adapter unit assembly that connects processor-side equipment to the legacy TPN coaxial control network.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 51305348-100
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 51305348-100

  • Manufacturer:
    Honeywell
  • Part Number:
    51305348-100
  • Product Family:
    Honeywell TPS Series
  • Product Type:
    TPN Media Adapter Unit Assembly
  • Stock:
    1
  • Media direction:
    System-side equipment to TPN coax path
  • Official group:
    Infrastructure
  • Network context:
    TPN coaxial control network
  • Hardware format:
    Printed wiring assembly with two system connectors
  • Interface role:
    Processor-side to control-network media connection
  • Weight:
    0.265 lbs (0.12 kg)
  • Estimated shipping dimensions:
    13.6x6x4cm
  • Tariff Code:
    8537109000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Media Function Connector Layout Hardware Form Network Identity

Features:

  • Media Adapter Unit assembly for legacy TPN coax infrastructure
  • Compact PWA carries separate system-side and media-side connectors
  • Infrastructure-group part bridges processor equipment to the control network
The adapter places the processor-facing and coax-network connections on opposite sides of one media interface path rather than operating as an I/O channel card.

Its compact board format omits operator controls, making the part number, connector arrangement, and receiving position the main identification points.

The MAU function belongs to the TPN infrastructure layer, where it transfers communication between node hardware and the network medium.
The Honeywell 51305348-100 TPN Media Adapter Unit Assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 51305348-100 TPN Media Adapter Unit Assembly Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Position between node and network

  • Network position: The MAU sits between processor-side equipment and the TPN coax path.
  • Signal path: Adapter circuitry transfers the communication signal between those two media positions.
  • Module class: The assembly is infrastructure hardware rather than a process I/O module.

Separating the two sides of the adapter

  • System side: One connector position faces the system-side hardware.
  • Media side: The second position continues the path toward the control-network medium.
  • Orientation: Connector location must be preserved because the two sides perform different roles.

Compact printed wiring assembly

  • Board format: The adapter electronics are carried on a small PWA.
  • Operator interface: No operator key or display is present on the assembly.
  • Matching points: The board outline and connector placement provide the physical matching points.

Boundaries of the TPN coax application

  • Product group: 51305348-100 is grouped as Honeywell Infrastructure hardware.
  • Media context: The documented context is the legacy TPN coax network.
  • Excluded interfaces: Ethernet or unrelated serial interfaces are not implied by the MAU designation.
Description
Honeywell 51305348-100 is a Media Adapter Unit assembly in the Infrastructure group for legacy TPN coaxial nodes. It occupies the interface path between processor-side equipment and the private industrial control network.

Across the printed wiring assembly, 51305348-100 routes the system-side connection through the media-adapter circuitry toward the coax network connection. The two connector positions keep the equipment interface and network path physically distinct on one compact board.

The hardware form of 51305348-100 concentrates the media interface on a small PWA without front-panel controls or operator keys. Its identity therefore depends on the complete assembly number and the connector position in the receiving TPN infrastructure.
Alternative Names
Honeywell 51305348-100 51305348-100 MAU Assembly Honeywell TPN Media Adapter Unit Honeywell MAU PWA 51305348-100 51305348-100 LCN Media Adapter Honeywell Infrastructure MAU Board TPN Coax Media Adapter Assembly Honeywell 51305348-100 Interface Card
Technical notes
Honeywell 51305348-100 is an Infrastructure-group MAU assembly; match the complete part number and receiving connector position before installation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does the MAU designation mean for Honeywell 51305348-100?
For Honeywell 51305348-100, MAU identifies a Media Adapter Unit assembly in the TPN infrastructure path. It is not a general-purpose I/O card, so match the receiving network position before selection.
Which network context should be confirmed for Honeywell 51305348-100?
Confirm a legacy TPN coaxial node before selecting Honeywell 51305348-100. The MAU belongs to that media path and does not establish an Ethernet or unrelated serial interface.
Why must both connectors be documented before removing Honeywell 51305348-100?
The two Honeywell 51305348-100 connector positions serve the system side and media path of the adapter assembly. Photograph and label both positions so the connections are not crossed during reinstallation.
How should Honeywell 51305348-100 be identified when no operator faceplate is present?
Use the complete Honeywell 51305348-100 assembly number on the PWA and compare the board outline and connector locations. The small adapter board does not have front-panel controls that can serve as a secondary identity check.
What should be tested after Honeywell 51305348-100 is installed?
After fitting Honeywell 51305348-100, verify the receiving node's approved network status and the affected processor-to-TPN communication path. A powered board alone does not confirm that both sides of the media connection are passing data.
