Features:
- Sixteen monitored guarded outputs arranged in two groups of eight
- 18–36 V DC field power with a 5 mA specified minimum load
- Automatic output testing with open- and short-circuit monitoring
T7481A is an ICS Triplex Regent+Plus monitored guarded output module. It provides 16 field outputs and supports up to 2 A per output at 0–40°C.
Redundant output switches and module diagnostics support guarded output operation. Single-module and documented parallel dual-module configurations are supported.
Confirm the Regent+Plus chassis, slot, field supply, minimum load, fuse, wiring and safety configuration before installing or replacing T7481A.
ICS Triplex T7481A Manuals, Datasheets and Links
Documentation Note: Use the official T7481A document for identification and technical reference. Verify the complete model and system configuration before use.
ICS Triplex T7481A General Information
General
- Manufacturer ICS Triplex
- Model T7481A
- Condition New
- Product Family Regent+Plus monitored guarded output modules
- Monitored 18–36 V DC field outputs with a 5 mA minimum load
- De-energize-to-trip circuits in documented configurations
- Parallel dual-module output control where specified
- Field loads requiring open- and short-circuit monitoring
- Follow the OEM procedure for fuse inspection and replacement
- Use only the specified fuse type and rating
- Hot replacement applies only to the documented dual-module configuration
- Verify load status before removing or replacing a module
- Configure 16 outputs as two groups of eight
- Use separate common field supplies as documented for each group
- Use one T7481A or a documented parallel pair of identical modules
- Confirm chassis, slot, wiring, field voltage and load settings
