        T3401

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The ICS Triplex T3401 DC Digital Input Module is a 16-channel industrial input solution designed for sensing field switch signals in safety-critical control systems.
        Get a quick price for T3401
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for T3401

        • Manufacturer:
          ICS Triplex
        • Part Number:
          T3401
        • Product Family:
          ICS Regent+Plus
        • Product Type:
          DC Digital Input Module
        • Safetybus Power:
          1.15 load units
        • Number of Inputs:
          16 circuits divided into two groups of eight
        • Voltage Range:
          14 to 30 VDC
        • Turn-On Voltage:
          12 VDC, min
        • Turn-Off Voltage:
          4.7 VDC, max
        • Input Current:
          8.7 mA
        • Turn-On Delay:
          minimum: 0.2 msec / maximum: 1.8 msec.
        • Protection:
          continuous: 50 VAC / burst: 80 VAC, for 5 sec
        • Heat:
          10 Watts
        • Dissipation:
          34 BTUs/hour
        • Fusing:
          None, fuse external if required
        • Isolation:
          2500 volts minimum (field wiring to control logic); 2500 volts minimum (input group 1-8 to input group 9-16).
        • Operating Temperature:
          0° to 60° C (32° to 140° F)
        • Storage Temperature:
          -40° to 85° C (-40° to 185° F)
        • Weight:
          1.3 kg
        • Estimated shipping dimensions:
          3.2x26.5x35.6cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Diagnostic Monitoring Application Connection Safety

        Features:

        • Supports 16 input channels arranged in two isolated groups of eight, enabling structured and organized signal processing.
        • Features triplicated Safetybus architecture, ensuring fault-tolerant operation and maintaining high system reliability under critical conditions.
        • Provides high electrical isolation up to 2500 volts between field and logic circuits, effectively protecting against electrical disturbances and transients.
        The T3401 DC Digital Input Module is designed for industrial automation systems that require stable and reliable digital signal monitoring. It integrates 16 input channels to efficiently handle field switch data in complex control environments. With its Safetybus-based architecture, the T3401 DC Digital Input Module ensures that input data remains consistent even under fault conditions. This makes it suitable for high-integrity control systems where reliability is essential.

        In practical industrial applications, the T3401 DC Digital Input Module plays a key role in ensuring accurate signal acquisition from field devices. Its dual-group isolation design helps maintain signal clarity while reducing interference between channels. The module’s ability to operate with redundant configurations enhances system availability. As a result, the T3401 DC Digital Input Module is widely applied in continuous process industries.

        From a maintenance and operational perspective, the T3401 DC Digital Input Module supports hot-replacement, allowing technicians to replace units without shutting down the system. This significantly reduces downtime in critical operations. Its built-in diagnostics and self-testing functions further improve system reliability. The T3401 DC Digital Input Module therefore contributes to safer and more efficient industrial automation infrastructure.

        The T3401 ICS Triplex DC Digital Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        ICS Triplex T3401 DC Digital Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        ICS Triplex T3401 DC Digital Input Module Specs

        General

        • Manufacturer ICS Triplex
        • Model T3401
        • Condition New Original ready stock
        • Product Family T3402,T3408,T3421
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Real-time Channel Self-test: The module's built-in microprocessor continuously monitors the circuit integrity of each input channel, preventing false signals.
        • Line Fault Identification: Equipped with open-circuit and short-circuit monitoring functions, it accurately distinguishes between on-site equipment faults and wiring connection problems.
        • Panel Status Indication: A visually intuitive display of the on/off status of each channel and system alarm status via an LED array, facilitating on-site inspection and maintenance.
        • Remote Health Tracking: Uploads diagnostic data such as module temperature and voltage fluctuations to a host computer via a communication bus, enabling predictive maintenance.
        • Switch Status Monitoring: Real-time acquisition of the closed status of manual buttons, limit switches, and pressure switches on-site.
        • Interlock Protection Logic: Serving as the input to a logic solver, it transmits on-site signals to the processor to execute safety protection actions.
        • Unit Status Feedback: Integrates operation/stop feedback signals from pumps, motors, and valves, ensuring the control system has real-time operational status.
        • Sequential Event Recording (SOE): High-precision timestamping of critical input signals for post-accident failure analysis and tracing.
        • Electrical and Opto-isolation: The input terminals and system logic side employ opto-coupling technology to effectively block external electromagnetic interference and high-voltage surges.
        • Hot-swap Protection: Supports hot-swappable operation; module replacement will not cause backplane bus fluctuations or affect the operation of other channels.
        • Physical Error-Proofing: Equipped with a mechanically coded key to prevent the accidental insertion of different types of modules into the base during maintenance.
        • Redundant Communication Interface: Employs a dual-redundant serial bus connection to the controller, ensuring reliable control signal transmission even if a single link is damaged.
        Description
        The ICS Triplex T3401 DC Digital Input Module is engineered with 16 input circuits divided into two isolated groups of eight channels, enabling structured signal acquisition for industrial control applications. It operates within a voltage range of 14 to 30 VDC and supports a turn-on threshold of 12 VDC minimum with a turn-off limit of 4.7 VDC maximum. With an input current of 8.7 mA, the T3401 DC Digital Input Module ensures consistent signal detection across field devices while maintaining stable electrical performance.

        One of the key strengths of the T3401 DC Digital Input Module is its triplicated I/O Safetybus interface, which ensures that no single failure can compromise system operation. The module supports fault-tolerant configurations when operated in parallel with redundant modules, allowing continuous system operation even during maintenance or replacement. In comparison to non-redundant input modules in the same ICS Triplex series, the T3401 DC Digital Input Module offers significantly higher system availability due to its built-in voting and redundancy logic.

        The T3401 DC Digital Input Module provides strong electrical isolation, with a minimum rating of 2500 volts between field wiring and logic circuits as well as between input groups. This isolation protects internal circuitry from electrical disturbances such as transients and over-voltages. The module also features automatic self-testing of Safetybus circuits and logic functions, ensuring continuous diagnostic coverage and reliable operation of the T3401 DC Digital Input Module in safety systems.

        Thermal performance and operational durability are also key aspects of the T3401 DC Digital Input Module, with power dissipation of approximately 10 watts and heat output of 34 BTUs/hour. It operates reliably in environments from 0°C to 60°C and can be stored between -40°C and 85°C. With hot-replaceable capability, the T3401 DC Digital Input Module allows maintenance without interrupting system operation, making it suitable for continuous industrial processes.
        Alternative Names
        T3402 T3408 T340I T34O1 T3419 T3411 T3480 T3411F
        Technical notes
        DC digital input module T3401 operates with 16 circuits in two isolated groups of eight, input voltage range 14–30 VDC, turn-on voltage 12 VDC minimum, turn-off voltage 4.7 VDC maximum, input current 8.7 mA, turn-on delay 0.2–1.8 msec, Safetybus power 1.15 load units, protection 50 VAC continuous and 80 VAC burst for 5 seconds, heat 10 watts, dissipation 34 BTUs/hour, no internal fusing (external if required), isolation 2500 V minimum field-to-logic and group-to-group, operating temperature 0–60°C, storage temperature −40–85°C.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What is the input configuration of the T3401 DC Digital Input Module?
        The T3401 DC Digital Input Module contains 16 input circuits arranged into two isolated groups of eight channels for structured and safe signal handling.
        How does the T3401 DC Digital Input Module support fault tolerance?
        It allows parallel operation with redundant modules of the same type, enabling continuous operation even if one T3401 DC Digital Input Module fails.
        How does the T3401 DC Digital Input Module perform in temperature variations?
        It operates between 0°C and 60°C and can be stored from -40°C to 85°C, ensuring stable performance of the T3401 DC Digital Input Module in industrial environments.
        Why is hot-replace capability important in the T3401 DC Digital Input Module?
        Hot-replace functionality allows the T3401 DC Digital Input Module to be replaced without shutting down the system, minimizing downtime in industrial operations.
