    Maintain the integrity of your safety systems with this original ICS Triplex T8431C module, sourced by Apter Power for dependable performance.

T8431C

/ 4.9
1001 reviews | Need a Specific Revision?
The T8431C is a Trusted TMR 24 Vdc Analog Input Module with 40 channels, designed for high-availability safety applications requiring triple modular redundancy.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for T8431C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for T8431C

  • Manufacturer:
    ICS Triplex
  • Part Number:
    T8431C
  • Product Family:
    Trusted Triple Modular Redundant
  • Product Type:
    Analog Input Module
  • Stock:
    2
  • Number of Channels:
    40
  • Architecture:
    Triple Modular Redundant (TMR)
  • Input Types:
    24 Vdc analog signals
  • Configuration:
    Software-based (IEC 61131 TOOLSET, System Configuration Manager)
  • Diagnostics:
    Line fault detection, channel discrepancy monitoring, housekeeping registers
  • Safety Certification:
    IEC 61508 SIL 3
  • Key Benefit:
    Model T8431C provides 40 channels of TMR analog input with per-channel threshold configuration and line fault monitoring, enabling early detection of sensor wiring issues.
  • Weight:
    1.15 kg
  • Estimated shipping dimensions:
    3x30.1x26.4cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Firmware & Updates Configuration

Features:

  • The T8431C is a Trusted TMR 40-channel 24 Vdc analog input module with triple modular redundancy architecture for SIL 3 safety applications.
  • No physical configuration is required on the module; all setup is performed via the IEC 61131 TOOLSET and System Configuration Manager software tools.
  • Comprehensive diagnostics include per-channel threshold configuration, line fault detection, channel discrepancy monitoring, and engineering unit conversion.
The T8431C is built on Trusted Triple Modular Redundant (TMR) architecture, providing 40 analog input channels for high-integrity signal acquisition in safety instrumented systems. The TMR design ensures that no single point of failure can compromise system integrity, as three independent processing paths continuously vote on input values to guarantee accurate and reliable data. This makes the T8431C ideal for SIL 3 certified applications in oil and gas, power generation, and chemical processing where continuous operation and fault tolerance are essential.

The T8431C requires no physical configuration on the module itself, streamlining installation and reducing field errors. All configurable characteristics are performed using the IEC 61131 TOOLSET and System Configuration Manager on the Engineering Workstation, where engineers define I/O variables, create module definitions specifying chassis and slot locations, and set per-channel thresholds. The TMR Processor automatically configures the T8431C after applications are downloaded, eliminating manual setup and simplifying system integration.

The T8431C offers extensive diagnostic capabilities through its Complex Equipment Definition, which includes line fault detection, channel discrepancy monitoring, and per-channel threshold configuration. These features enable early detection of sensor wiring issues, signal degradation, and input inconsistencies before they compromise system integrity. The module also provides engineering unit conversion, field input status, and housekeeping registers, delivering complete visibility into both process variables and module health for effective predictive maintenance and system optimization.

The T8431C ICS Triplex Analog Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS Triplex T8431C Analog Input Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ICS Triplex T8431C Analog Input Module Specs

General

  • Manufacturer ICS Triplex
  • Model T8431C
  • Condition New Original ready stock
  • Product Family T8431,T8403C,T8432,T8432C
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Safety Instrumentation Systems (SIS): Monitors analog signals such as pressure, liquid level, and temperature in high-risk industries such as oil, gas, power, and rail transportation.
  • Emergency Shutdown Systems (ESD): Serving as a core input, triggers system shutdown protection when field analog data exceeds safety thresholds.
  • Fire and Gas Monitoring (F&G): Collects 4-20 mA signals from various gas detectors for real-time monitoring and interlocking alarms.
  • Update Tools: Firmware upgrades are typically performed using ControlFLASH™ or ControlFLASH Plus™ software.
  • Hot-Swap: The T8431C supports hot-swapping online. When a new module is inserted into the Companion Slot or SmartSlot, the system automatically "educates" it, synchronizing the configuration and programs to the new module without stopping system operation.
  • Programming Environment: Developed using Trusted Toolset compliant with IEC 61131-3, supporting multiple programming languages ​​including ladder logic and function blocks.
  • Channel Parameters: Supports 4-20 mA or 0-5 Vdc signal inputs with extremely fast sampling update time (approximately 0.5 ms).
  • Line Monitoring: Allows independent configuration of open-circuit or short-circuit detection for each channel, enabling timely detection of field wiring faults.
Description
The T8431C operates as a 40-channel analog input module within the Trusted TMR system, providing high-integrity signal acquisition for safety-critical applications. It features triple modular redundancy architecture that ensures no single point of failure can compromise system integrity.

The T8431C requires no physical configuration on the module itself; all setup is performed using the IEC 61131 TOOLSET and System Configuration Manager tools on the Engineering Workstation. The T8431C's configurable characteristics include custom LED indicator modes, per-channel threshold levels, noise filtering, and line fault detection parameters.

The T8431C provides comprehensive diagnostic capabilities through its Complex Equipment Definition, which includes eight I/O boards for field input status, engineering unit values, threshold data, line fault status, discrepancy monitoring, housekeeping registers, and module information. The T8431C's OEM parameters define the primary module position, declaring chassis and slot location without requiring secondary module definition.

The T8431C solves the critical pain point of reliable analog signal acquisition in safety-critical applications where input accuracy and fault detection are paramount. Its 40-channel capacity with per-channel threshold configuration and line fault monitoring enables early detection of sensor wiring issues before they compromise system integrity.
Alternative Names
T8431 T8432C T8403C T8441 T8433 T8433C T8432 T843IC
Technical notes
Engineered for high-density safety systems, the ICS Triplex T8431C Analog Input Module monitors 40 independent channels with an ultra-fast sample update time of 0.5 ms.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How many analog input channels does the T8431C provide?
The T8431C provides 40 analog input channels with triple modular redundancy, making it ideal for large-scale safety instrumented systems requiring extensive analog signal acquisition.
How is the T8431C configured for a specific application?
All configuration is performed via software using the IEC 61131 TOOLSET and System Configuration Manager, with no physical configuration required on the module itself.
What diagnostic features does the T8431C offer?
The T8431C includes comprehensive diagnostics such as line fault detection, channel discrepancy monitoring, housekeeping registers, and per-channel threshold configuration for early fault detection.
What is the safety certification of the T8431C?
The T8431C is designed for SIL 3 certified safety instrumented systems per IEC 61508, making it suitable for critical applications in oil and gas, power generation, and chemical processing industries.
