          Apter Power supports 3611E quotation, termination review, and documentation checks.

        3611E

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Triconex 3611E is an eight-point 115 VAC supervised TMR output module for critical AC field loads, combining relay voting with continuous circuit and load diagnostics.
        In Stock
        Ships by Wednesday, September 30
        Fast Shipping Available
        Get a quick price for 3611E
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 3611E

        • Manufacturer:
          Invensys
        • Part Number:
          3611E
        • Product Family:
          Triconex
        • Product Type:
          Supervised TMR Digital Output Module
        • Stock:
          1
        • Model:
          3611E
        • Architecture:
          TMR supervised digital output
        • Nominal voltage:
          115 VAC
        • Points:
          8 commoned
        • Voltage range:
          90 to 155 VAC
        • Frequency range:
          47 to 63 Hz
        • Maximum switching power:
          2,000 VA resistive
        • Typical on-state drop:
          Less than 2 V
        • Maximum current per point:
          2 A
        • Surge current:
          10 A per AC cycle
        • Minimum required load:
          50 mA
        • Secondary supply:
          Not applicable
        • Chassis leakage:
          1 mA maximum at 60 Hz
        • Load leakage:
          4 mA maximum
        • Field termination fuse:
          2.5 A fast-acting, one per output
        • Point isolation:
          1,500 VDC minimum
        • Indicators:
          POINT, PWR, LOAD, PASS, FAULT, ACTIVE
        • Color code:
          Deep green
        • Hot spare:
          Supported
        • External termination:
          Separate ETP and cable required
        • Tariff Code:
          8537101190
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Monitoring Safety Operating Environment

        Features:

        • Provides eight commoned 115 VAC outputs with fully fault-tolerant TMR relay voting.
        • Supervises field power, fuse continuity and connected load through voltage and current loopback circuits.
        • Supports a hot-spare module using a separate external termination panel and cable interface.
        The 3611E ordering code identifies the deep-green 115 VAC SDO module with eight commoned output points and hot-spare capability.

        Its 2,000 VA resistive switching capacity serves critical AC output circuits that may hold one state for extended periods while the supervision paths continue checking field conditions.

        Match the 90–155 VAC, 47–63 Hz source and 50 mA minimum load, then confirm the separate ETP, cable interface, and 2.5 A point fuse before commissioning.

        Availability is subject to Apter Power inventory and sourcing confirmation.
        Verified resources for Triconex 3611E: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Drives critical 115 VAC shutdown and trip loads that need continuous supervision while energized or de-energized.
        • Detects loss of field power, an open load and field shorts within the limits of the selected AC or DC model.
        • Supports long-dwell protective outputs in emergency shutdown, fire-and-gas and burner-management systems.
        • Three processor commands enter a quadruplicated relay voter that determines the state of each of the eight supervised AC outputs.
        • Voltage and current feedback monitor the external source and connected load instead of observing only the internal relay command.
        • POINT, PWR and LOAD indications separate commanded state, field-power condition and load supervision from PASS, FAULT and ACTIVE status.
        • Supervision detects loss of field power, a blown fuse and an open or disconnected load while the output circuit remains under monitoring.
        • A field short that energizes an AC load when its command is Off is reported as a supervised external-circuit fault.
        • Each channel uses a 2.5 A fast-acting fuse on the dedicated 9661-510F termination arrangement.
        • The field circuit is designed for 90–155 VAC operation across the documented 47–63 Hz frequency range.
        • Each output carries 2 A continuously and permits 10 A inrush for one AC cycle when the connected load remains within the switching limit.
        • Reliable supervision requires at least 50 mA of load; leakage-sensitive coils must also tolerate the specified 4 mA maximum.
        Description
        Triconex 3611E is an eight-point, commoned 115 VAC supervised TMR digital output module for critical loads that may remain energized or de-energized for long periods. Mechanical power relays within the fully fault-tolerant quadruplicated voter pass the approved command to each external circuit. The module is intended for AC trip, relay and actuator duties where the condition of the field path must be observed as well as the logical command.

        Voltage and current feedback extend supervision beyond the internal output switch. The module can identify loss of field power, a blown fuse, an open or missing load and a field short that energizes an AC load when its command should be off. Separate POINT, PWR and LOAD indications help technicians distinguish command state, source condition and load-path faults from PASS, FAULT or ACTIVE events within the module itself.

        The connected circuit must satisfy the 90–155 VAC range, 47–63 Hz frequency range, 50 mA minimum load and documented continuous and inrush limits for supervision to remain dependable. Each point uses the specified fast-acting fuse on the dedicated termination panel, and sensitive coils should be checked against the leakage current. Unlike supported supervised DC variants, this AC model does not use a secondary low-voltage supply for additional off-state short detection.
        Alternative Names
        3611E Triconex 3611E Invensys Triconex 3611E 3611 E Triconex Model 3611E Triconex 3611E Supervised Digital Output Module Triconex 3611E 8-Point SDO Module
        Technical notes
        3611E does not use the 5 VDC secondary-supply method for detecting a shorted load while de-energized; verify the AC circuit and ETP protection scheme before replacement.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why does 3611E require at least a 50 mA load?
        The supervised loop needs the documented minimum current to distinguish a connected AC load from an open or missing field circuit.
        Which field fault is not available on 3611E?
        The AC model does not provide the optional-secondary-supply method for detecting a shorted load while the output is de-energized.
        Where is 3611E preferable to a standard digital output?
        Use it for long-dwell 115 VAC trip loads where power, fuse and load continuity need continuous supervision.
        What commercial checks precede a 3611E quotation?
        Apter Power verifies exact model, ETP, module condition, test scope, quantity, destination and required delivery timing.
        Can 3611E be exchanged for a DC supervised module?
        No. Field source, frequency, minimum load, surge, fuse, leakage and secondary-power behavior differ materially.
        Which circuit values should accompany a 3611E technical request?
        Provide field voltage and frequency, load VA, steady and inrush current, minimum load, ETP, fuse, cable and safety function.
