MVI56-MBP

/ 4.9
1001 reviews | Need a Specific Revision?
ProSoft MVI56-MBP is a Modbus Plus communication module that connects ControlLogix processors with Modbus Plus devices while supporting Master, Slave, global data, and backplane data exchange.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for MVI56-MBP
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI56-MBP

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI56-MBP
  • Product Family:
    ProSoft
  • Product Type:
    Modbus Plus Communication Module
  • Stock:
    1
  • Backplane Current Load:
    800 mA @ 5 V DC, 3mA @ 24V DC.
  • Operating Temperature:
    0 to 60°C (32 to 140°F)
  • Storage Temperature:
    -40 to 85°C (-40 to 185°F)
  • Shock:
    30g Operational, 50g non-operational.
  • Vibration:
    5 g from 10 to 150 Hz
  • Relative Humidity:
    5% to 95% (non-condensing)
  • LED Indicators:
    Module Status, Backplane Transfer Status, Application Status, Serial Activity.
  • CFG Port (CFG):
    RJ45 (DB-9M with supplied cable), RS-232 only
  • Modbus Plus Connector:
    Two DB9 Female Standard Modbus Plus connectors
  • Shipped with Unit:
    RJ45 to DB-9M cable, 6-foot RS-232 configuration cable.
  • Baud:
    57,600 (fixed)
  • Parity:
    none (fixed)
  • Stop:
    1 (fixed)
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    3.5x14x14.5cm
  • Tariff Code:
    9032900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Communication Application Scenarios Firmware

Features:

  • Combines Modbus Plus Master and Slave capabilities with support for peer communication, global data, broadcast commands, and all five routing levels.
  • Handles up to 4,000 words of backplane data and up to 200 Master commands, with configurable node addressing, polling, and event-driven writes.
  • Integrates into a single 1756 slot with dual DB9 Modbus Plus connectors, an RS-232 configuration interface, and status LEDs for communication and module diagnostics.
ProSoft MVI56-MBP provides a practical way to integrate ControlLogix automation with established Modbus Plus networks. Industrial facilities may contain Modicon processors alongside drives, relays, power monitoring equipment, and other devices that continue to communicate through Modbus Plus. The module creates a direct interface between such equipment and the ControlLogix backplane without requiring communication activity on both sides to operate synchronously. Processor memory is accessible through the module, while ladder logic manages data movement and configuration. The arrangement supports mixed automation environments where reliable exchange between different control platforms is required.

Network communication through ProSoft MVI56-MBP can be adapted to different control strategies using Master, Slave, and global data functions. Master operation provides conditional or continuous command polling and supports event-driven bit and register writes controlled through ladder logic. Slave operation allows other processors to read from or write to module memory and also accepts broadcast commands from the host. Global input and output data receive priority to provide a high-speed mechanism for exchanging control information. Communication error and status information can be returned to ladder logic to support application monitoring and troubleshooting.

ProSoft MVI56-MBP is also suited to industrial control cabinets where environmental and mechanical conditions require robust communication hardware. Operation is specified from 0 to 60°C with storage capability from -40 to 85°C and relative humidity up to 95% without condensation. Shock ratings reach 30 g during operation and 50 g when non-operational, while vibration resistance is rated at 5 g from 10 to 150 Hz. Dedicated LEDs allow maintenance personnel to observe module, backplane transfer, application, and serial activity status. Combined with local or remote rack installation, the module provides a flexible communication path for ControlLogix systems working with Modbus Plus equipment.

The MVI56-MBP ProSoft Modbus Plus Communication Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ProSoft MVI56-MBP Modbus Plus Communication Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft MVI56-MBP Modbus Plus Communication Module Specs

General

  • Manufacturer ProSoft
  • Model MVI56-MBP
  • Condition New Original ready stock
  • Product Family MVI56-GEC,MVI56-GSC,MVI56-HART
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Interface Type: The module is equipped with a standard Modbus Plus (MBP) interface specifically designed for connecting to existing MBP token ring networks.
  • Dual-Channel Design: Features two independent MBP ports, typically one as the primary port and the other for redundant network topologies.
  • Data Bearer: Supports efficient, cyclic, and fast exchange of up to 32 words of global data.
  • Throughput Performance: Allows for high-capacity block transfers between the ControlLogix processor and the network, optimizing data update cycles.
  • Retrofitting of Existing Factories: Suitable for upgrading the core controller of a factory to a ControlLogix system without replacing the underlying Modbus Plus legacy network.
  • Cross-Platform Interoperability: Used for bridging and integrating Allen-Bradley PLC architectures with traditional Schneider Electric MBP devices.
  • Distributed Data Acquisition: Deployed in distributed SCADA systems requiring high-speed global data transmission, or in large-scale industrial water treatment and power plant control networks.
  • Heterogeneous System Redundancy: Suitable for high-availability infrastructure projects that require leveraging the dual-port physical characteristics of MBPs to achieve communication link redundancy.
  • Function Alignment: Firmware is fully compatible with ControlLogix system built-in instructions, supporting seamless backplane direct memory mapping.
  • Diagnostics: Built-in advanced firmware logic provides real-time network conflict and node status diagnostics via module status LEDs and ControlLogix registers.
  • Upgrade Channel: Supports online firmware updates via the module's included serial configuration port using a dedicated flash memory upgrade tool.
  • Protocol Compliance: Firmware strictly adheres to Modicon's Modbus Plus protocol specifications, ensuring native interoperability with classic Quantum or Momentum PLCs.
Description
ProSoft MVI56-MBP provides a communication interface between ControlLogix compatible processors and devices operating on Modbus Plus networks. The module occupies a single slot in a 1756 backplane and can be installed in either a local or remote rack. Recognized as an input/output module by the ControlLogix system, MVI56-MBP accesses processor memory for data exchange between the processor and the Modbus Plus network. Ladder logic handles data transfer and configuration, while backplane communication operates asynchronously from Modbus Plus network activity.

ProSoft MVI56-MBP supports both Master and Slave operation, allowing connection with Modicon processors and other Modbus Plus compatible equipment such as drives, relays, and power monitoring hardware. Two standard DB9 female connectors provide Modbus Plus network connections. The CFG port uses an RJ45 interface with RS-232 communication only, operating at a fixed 57,600 baud, no parity, and one stop bit. The unit is supplied with an RJ45 to DB-9M cable and a six-foot RS-232 configuration cable.

ProSoft MVI56-MBP provides user-definable memory and supports transfer of up to 4,000 registers across the ControlLogix backplane. Read and write transactions can contain up to 100 words, and all five levels of Modbus Plus routing are supported. Configurable parameters include node addresses from 1 to 64, global output data from 0 to 32 words, global input data from 0 to 32 words, module transfers from 0 to 4,000 words, and Master command lists containing up to 200 commands. Slave mode accepts function codes 1, 2, 3, 4, 5, 6, 15, and 16, while Master mode transmits function codes 3 and 16.

ProSoft MVI56-MBP also supports global data exchange, broadcast commands, conditional and continuous command polling, event-driven bit and register writes, and communication status reporting to ladder logic. Backplane current requirements are 800 mA at 5 VDC and 3 mA at 24 VDC. The module operates from 0 to 60°C and can be stored from -40 to 85°C, with 5% to 95% relative humidity under non-condensing conditions. Mechanical ratings include 30 g operational shock, 50 g non-operational shock, and 5 g vibration from 10 to 150 Hz, while LEDs indicate Module Status, Backplane Transfer Status, Application Status, and Serial Activity.
Revisions

Revision Part #

Also known as

MVI56-MBP Ser A
MVI56-MBP/A, Series A, Rev A
Alternative Names
MV156-M8P MV156-MBP MV156M8P MV156MBP MVI56-PDPMV1 MVI56-MDA4 MVI56-HART MVI56-GSC
Technical notes
Engineered for demanding industrial environments, the ProSoft MVI56-MBP communication module features dual Modbus Plus ports to support redundant network topologies and high-speed block transfers across the ControlLogix backplane. It delivers robust connectivity and deterministic performance for up to 64 nodes on a single MBP routing segment.
