    Apter Power supports PLX51-PBS quotations, official documents, sourcing, and PROFIBUS-to-Ethernet application matching.

PLX51-PBS

/ 4.9
1001 reviews | Need a Specific Revision?
ProSoft PLX51-PBS is a PROFIBUS DP Slave gateway for EtherNet/IP, Modbus TCP/IP, or Modbus Serial networks.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for PLX51-PBS
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PLX51-PBS

  • Manufacturer:
    ProSoft
  • Part Number:
    PLX51-PBS
  • Product Family:
    ProSoft
  • Product Type:
    PROFIBUS DP Slave to EtherNet/IP™, Modbus® TCP/IP, or Modbus® Serial Gateway
  • Stock:
    1
  • Enclosure Rating:
    IP20, NEMA/UL Open Type
  • Operating Temperature:
    -20 to 70 °C
  • Power Input:
    10 to 36 VDC
  • Power Consumption:
    85 mA at 24 VDC; 2.04 W
  • Power Connector:
    3-way terminal
  • Conductor Size:
    24 to 18 AWG
  • Ethernet Connector:
    RJ45; CAT5 STP/UTP
  • ARP Connections:
    Maximum 40
  • TCP Connections:
    Maximum 40
  • CIP Connections:
    Maximum 10
  • Ethernet Rate:
    10/100 Mbps
  • Duplex Mode:
    Full / Half / Auto Negotiate
  • Auto-MDIX:
    Yes
  • Embedded Switch:
    Two Ethernet ports
  • Modbus TCP Role:
    Client or Server
  • Modbus Serial Role:
    Master or Slave
  • Serial Interface:
    RS-232 or RS-485
  • Serial Baud Rate:
    1200 to 115200 baud
  • Serial Format:
    8 data bits; 1 stop bit; None, Odd, or Even parity
  • PROFIBUS Protocol:
    PROFIBUS DP Slave; DPV0 or DPV1
  • PROFIBUS Baud Rate:
    9.6 kbps to 12 Mbps
  • Cyclic I/O Data:
    Input: 1536 bytes; Output: 1536 bytes
  • Weight:
    1.6 kg
  • Estimated shipping dimensions:
    5.86 x 1.33 x 4.56 in, 149 x 34 x 116 mm
  • Tariff Code:
    8471.50.00
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications PROFIBUS Ethernet Modbus

Features:

  • PROFIBUS DP Slave protocol operation
  • EtherNet/IP, Modbus TCP/IP, or Modbus Serial connectivity
  • Dual Ethernet ports with commissioning diagnostics
The ProSoft PLX51-PBS operates as a PROFIBUS DP slave gateway and links PROFIBUS networks with EtherNet/IP, Modbus TCP/IP, or Modbus Serial devices without changing the connected controller platform.

Its data exchange architecture supports up to 1536 bytes of PROFIBUS input data and 1536 bytes of output data. Ethernet services and serial communication are configured for the selected application rather than treated as interchangeable ports.

Match the intended Ethernet or serial protocol, PROFIBUS station settings, I/O sizes, network topology, and power requirements before installation. Ring-network and configuration options should be checked against the official manual.
The ProSoft PLX51-PBS PROFIBUS DP Slave to EtherNet/IP™, Modbus® TCP/IP, or Modbus® Serial Gateway is listed as Active / Available from OEM. This current ProSoft gateway supports new PROFIBUS integration enquiries. Request pricing and protocol-selection assistance from Apter Power.
ProSoft PLX51-PBS PROFIBUS DP Slave to EtherNet/IP™, Modbus® TCP/IP, or Modbus® Serial Gateway Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft PLX51-PBS PROFIBUS DP Slave to EtherNet/IP, Modbus TCP/IP, or Modbus Serial Gateway Specs

General

  • Manufacturer ProSoft Technology
  • Model PLX51-PBS
  • Condition New Original ready stock
  • Product Family PLX5x Gateways
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

PLX51-PBS PROFIBUS details

  • Function: PROFIBUS DP Slave operation
  • Protocol: DPV0 or DPV1 support
  • Capacity: Up to 1536 bytes of cyclic input and output data
  • Operation: Configuration should match the selected Ethernet or Modbus Serial architecture.

PLX51-PBS Ethernet details

  • Integration: Dual 10/100 Mbps Ethernet ports
  • Interface: EtherNet/IP and Modbus TCP/IP support
  • Configuration: DLR or embedded-switch topology options
  • Application: Configuration should match the selected Ethernet or Modbus Serial architecture.

PLX51-PBS Modbus details

  • Diagnostics: Modbus TCP/IP Client or Server operation
  • Setup: Modbus Serial Master or Slave operation
  • Verification: RS-232 or RS-485 serial media
  • Maintenance: Configuration should match the selected Ethernet or Modbus Serial architecture.
Description
The PLX51-PBS operates as a PROFIBUS DP Slave while providing connectivity to EtherNet/IP, Modbus TCP/IP, or Modbus Serial networks.

The PLX51-PBS maps PROFIBUS DP data to EtherNet/IP controller tags or Modbus registers and supports up to 1536 bytes of input and output data.

The PLX51-PBS includes dual Ethernet ports, configuration software, dynamic Add-On Instructions, and a PROFIBUS packet-capture utility for commissioning and diagnostics.
Alternative Names
PLX51 PBS PLX51PBS ProSoft PLX51-PBS PST PLX51-PBS PLX51-PBS PROFIBUS Gateway PLX51-PBS EtherNet/IP Gateway PLX51-PBS Datasheet PLX51-PBS Manual
Technical notes
PLX51-PBS is a PROFIBUS DP Slave gateway for EtherNet/IP, Modbus TCP/IP, or Modbus Serial integration. Verify protocol mode, data mapping, power, and network topology.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is ProSoft PLX51-PBS?
PLX51-PBS is a PROFIBUS DP Slave to EtherNet/IP, Modbus TCP/IP, or Modbus Serial gateway according to ProSoft's official product documentation.
Which systems are compatible with PLX51-PBS?
PLX51-PBS is intended for PROFIBUS DP networks and supported EtherNet/IP or Modbus networks. Verify the installed controller, protocol role, firmware, and wiring before commissioning.
What is the main application of PLX51-PBS?
PLX51-PBS is used for mapping PROFIBUS DP data to EtherNet/IP controller tags or Modbus registers as described in the official ProSoft documentation.
Which specifications should be checked before installing PLX51-PBS?
PLX51-PBS: verify PROFIBUS DP Slave mode, cyclic data size, Ethernet connections, serial settings, power, and temperature against the official datasheet before installation.
What is the lifecycle status of PLX51-PBS?
PLX51-PBS is classified as Active / Available from OEM from the reviewed ProSoft product and lifecycle resources.
Does PLX51-PBS require a replacement model?
PLX51-PBS has no manufacturer-stated replacement requirement in the reviewed official resources. Confirm protocol and system compatibility before any substitution.
Where can I find documentation and request a quote for PLX51-PBS?
PLX51-PBS official datasheet is listed first in the Manuals tab; send quantity, system details, destination, and documentation needs to Apter Power for quotation.
