Technical specifications for 2150-AGA 1747-KE
Manufacturer:
ProSoft
Part Number:
2150-AGA 1747-KE
Product Family:
ProSoft
Product Type:
1747-KE
Model Number:
2150-AGA (Compatible with 1747-KE functions)
Configuration Port (CONFIG):
Supports RS-232/RS-422/RS-485
DF1 Port:
Supports RS-232/422/485 communication (300-19200 baud)
DH-485 Port:
Connects to a DH-485 network (requires a Link Coupler)
Operating Temperature:
0°C to +60°C
Storage Temperature:
-40°C to +85°C
Relative Humidity:
5% to 95% Non-condensing
Power Requirements (Backplane Power):
5VDC @0.150A, 24VDC @0.040A (Module Self-Powered)
Weight:
0.4 kg
Estimated shipping dimensions:
5.1x12.7x15.2cm
Tariff Code:
8537101190
Country of origin:
USA
Place of shipment:
Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The ProSoft 2150-AGA is an industrial serial interface module for Allen-Bradley SLC-500 series PLCs, providing DH-485 networking and DF1 serial communication interfaces, supporting RS-232/RS-422/RS-485 standards.
The module is rack-mounted in a single slot, with backplane power supplies of 5V DC @ 0.15A and 24V DC @ 0.04A, providing stable power support. The communication port supports data rates from 300 to 19200 baud, enabling data exchange between the PLC and remote devices, modems, or other serial interface devices. The module operates in a temperature range of 0°C to +60°C, with a storage temperature range of -40°C to +85°C, and a non-condensing relative humidity of 5%–95%, while also exhibiting interference immunity and industrial environmental adaptability. Measuring approximately 5.1cm × 12.7cm × 15.2cm and weighing approximately 0.4kg, it facilitates integration within limited rack space.
The 2150-AGA supports existing DH-485 network expansion and system upgrades, providing a reliable serial communication solution for industrial automation, process control, and remote data acquisition systems.
We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
Trust Guaranteed
Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
Expertise
Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.
FAQS
The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What communication protocols does the 2150-AGA support?
It supports DH-485 network and DF1 serial communication protocols, and can exchange data with PLCs and remote devices via RS-232/RS-422/RS-485 interfaces.
What are the module installation methods and rack requirements?
The module is for single-slot installation, directly inserted into the Allen-Bradley SLC-500 series rack. The backplane provides communication and power interfaces.
What are the operating environment and electrical parameters?
Operating temperature: 0°C to +60°C; storage temperature: -40°C to +85°C; relative humidity: 5%–95% non-condensing; backplane power supply: 5V DC @ 0.15A and 24V DC @ 0.04A; supports data rates of 300–19200 baud.
What are the application scenarios for the 2150-AGA?
It is suitable for expanding the serial communication capabilities of SLC-500 series PLC systems, integrating DH-485 networks with remote devices, modems, or other serial interface devices. It is widely used in industrial automation, process control, and remote data acquisition systems.
