Siemens 6SL3210-1PE22-7AL0 is a SINAMICS PM240-2 power module for 380–480 V three-phase input with an integrated Class A filter and braking chopper.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6SL3210-1PE22-7AL0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SL3210-1PE22-7AL0

  • Manufacturer:
    Siemens
  • Part Number:
    6SL3210-1PE22-7AL0
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    SINAMICS PM240-2 Power Module
  • Stock:
    1
  • Input Supply:
    3 AC 380 to 480 V
  • Supply Frequency:
    47 to 63 Hz
  • Low-Overload Power:
    11 kW
  • High-Overload Power:
    7.5 kW
  • Low-Overload Input Current:
    32.6 A
  • High-Overload Input Current:
    27 A
  • Low-Overload Output Current:
    26 A
  • High-Overload Output Current:
    18 A
  • Maximum Output Current:
    39 A
  • Output Frequency, Vector Control:
    0 to 200 Hz
  • Output Frequency, V/f Control:
    0 to 550 Hz
  • Pulse Frequency:
    4 kHz
  • Integrated Line Filter:
    Class A
  • Braking Chopper:
    Integrated
  • Operating Temperature, Low Overload:
    -10 to +40 °C
  • Operating Temperature, High Overload:
    -10 to +50 °C
  • Protection Rating:
    IP20
  • Frame Size:
    FSC
  • Weight:
    11.685 lbs (5.3 kg)
  • Estimated shipping dimensions:
    18.5x15.7x44cm
  • Tariff Code:
    8504409999
  • Country of origin:
    Great Britain
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Power Stage Braking Control Unit Cooling Setup

Features:

  • The power stage accepts a 380–480 V three-phase input.
  • An integrated Class A line filter controls conducted emissions at the supply side.
  • An internal braking chopper switches energy into the connected braking circuit.
Siemens 6SL3210-1PE22-7AL0 supplies a controlled variable-frequency output from a three-phase industrial source.

Low-overload and high-overload duty use separate power, current, and temperature limits.

The FSC module relies on protected cabinet installation and a correctly selected SINAMICS control unit.

The Siemens 6SL3210-1PE22-7AL0 SINAMICS PM240-2 Power Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6SL3210-1PE22-7AL0 SINAMICS PM240-2 Power Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Input and Motor-Side Conversion

  • Supply side: The module accepts a 380–480 V three-phase input within the specified frequency range.
  • Conversion stage: The power electronics produce a variable-frequency output for the connected motor.
  • Duty selection: Low-overload and high-overload operation use different allowable current and power values.
  • Control method: The maximum output frequency changes between vector and V/f operation.

Regenerative Energy Path

  • Internal switch: The integrated chopper controls when braking energy is sent to the resistor circuit.
  • External load: The braking resistor must match the documented electrical limits of the power module.
  • Wiring route: Braking connections carry energy separately from the motor output conductors.
  • Thermal effect: Repeated braking adds heat that must remain within the drive and resistor duty limits.

Command and Power Functions

  • Power-module role: The PM240-2 switches the motor current but does not replace the SINAMICS control unit.
  • Control selection: The paired control unit defines command interfaces, feedback handling, and parameter access.
  • Operating mode: Vector or V/f settings change the relationship between commanded speed and output frequency.
  • Duty parameters: Current limits must follow the selected low-overload or high-overload basis.

Cabinet and Temperature Conditions

  • Enclosure: IP20 construction requires a cabinet that prevents contact and environmental exposure.
  • Air path: Installation clearance must preserve cooling flow through the FSC module.
  • Low-overload limit: The specified low-overload rating applies only within its documented ambient-temperature range.
  • High-overload limit: High-overload operation uses a separate ambient limit and current basis.
Description
Siemens 6SL3210-1PE22-7AL0 is a SINAMICS PM240-2 power module that converts a 380–480 V three-phase supply into a variable-frequency output for a connected motor. Its FSC power stage is rated separately for low-overload and high-overload duty, so the selected load profile determines the usable power and current.

At the line side, 6SL3210-1PE22-7AL0 includes a Class A filter before the conversion stage. The output frequency range then depends on whether the drive operates with vector control or V/f control, linking the electrical output directly to the selected control method.

Dynamic energy from the motor is directed by the integrated braking chopper of 6SL3210-1PE22-7AL0 toward the connected braking circuit. This internal function avoids assigning the switching task to a separate external chopper, while the resistor and wiring still have to match the documented drive requirements.

Cooling and cabinet conditions set the operating boundary for 6SL3210-1PE22-7AL0. The IP20 module must be installed in a protected enclosure, with the allowed ambient temperature applied according to low-overload or high-overload operation and with sufficient clearance for heat removal.
Alternative Names
6SL32101PE227AL0 6SL3210 1PE22 7AL0 6SL 3210 1PE22 7AL0 Siemens 6SL3210-1PE22-7AL0 6SL3210-1PE22-7AL0 PM240-2 Power Module Siemens 6SL32101PE227AL0 6SL3210-1PE22-7A10 6SL32I0-1PE22-7AL0 SINAMICS Drive
Technical notes
Low-overload and high-overload ratings on Siemens 6SL3210-1PE22-7AL0 use different power, current, and temperature limits; select one duty basis consistently.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why does 6SL3210-1PE22-7AL0 show two different kW ratings?
Siemens 6SL3210-1PE22-7AL0 has separate low-overload and high-overload ratings because each duty profile uses different continuous current and overload capacity.
What should be checked if 6SL3210-1PE22-7AL0 trips during acceleration?
Check the 6SL3210-1PE22-7AL0 duty selection, motor data, acceleration ramp, current demand, supply voltage, and mechanical load before changing protection limits.
Does 6SL3210-1PE22-7AL0 require an external braking chopper?
No. Siemens 6SL3210-1PE22-7AL0 includes the chopper, but its external braking resistor and wiring must meet the documented drive requirements.
Why can 6SL3210-1PE22-7AL0 overheat even when motor current is within its rating?
Inspect the 6SL3210-1PE22-7AL0 cabinet temperature, airflow, clearance, pulse frequency, braking duty, and selected overload class.
Can 6SL3210-1PE22-7AL0 run without a SINAMICS control unit?
No. Siemens 6SL3210-1PE22-7AL0 is the power module; a compatible control unit is required to command and parameterize the drive system.
