Features:
- A 37 kW power stage controls a three-phase motor from a 380–440 V AC supply.
- USS, Modbus RTU, and BACnet MS/TP share the drive serial communication interface.
- Integrated digital, relay, analog, and motor-temperature terminals connect the drive to the control system.
Siemens 6SL3220-1YD36-0UB0 converts the line supply into a variable-frequency motor output under V/f or sensorless-vector control.
The terminal set of 6SL3220-1YD36-0UB0 handles commands, status contacts, analog references, feedback, and motor-temperature protection.
Forced-air cooling and the IP20 enclosure of 6SL3220-1YD36-0UB0 require a cabinet layout that maintains the specified airflow and temperature limits.
The Siemens 6SL3220-1YD36-0UB0 SINAMICS G120XA 37 kW USS Variable Frequency Drive may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6SL3220-1YD36-0UB0 SINAMICS G120XA 37 kW USS Variable Frequency Drive Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Output and Control-Mode Relationship
- Power stage: The drive generates the controlled three-phase output for the connected 37 kW motor duty.
- V/f modes: Linear, square-law, parameterized, FCC, and ECO curves relate output voltage to frequency.
- Vector mode: Sensorless vector control estimates motor state without an encoder-feedback interface.
- Commissioning: Motor nameplate data, control mode, ramp times, limits, and rotation checks must be completed as one setup.
Terminal Signal Roles
- Digital inputs: Six terminals receive configured run, direction, reset, interlock, or other binary commands.
- Relay outputs: Four dry-contact outputs report assigned status or fault conditions to external circuits.
- Analog paths: Two differential inputs accept references or measurements, while two outputs transmit configured drive values.
- Temperature input: The dedicated motor-sensor terminal accepts the documented PTC, KTY, PT1000, or Thermo-Click device.
Serial Network Commissioning
- Protocol choice: Only the selected USS, Modbus RTU, or BACnet MS/TP stack interprets received telegrams.
- Station settings: Address, baud rate, parity, stop bits, and timeout must match the network master.
- Control source: Command and setpoint ownership must be assigned to fieldbus or terminals as required.
- Process map: The controller data words must correspond to the configured drive control and status mapping.
Cooling and Motor-Connection Boundaries
- Air path: The integrated fan needs unobstructed cabinet intake and exhaust around the FSD enclosure.
- Ambient range: Operation at the upper temperature boundary must follow the documented load and installation conditions.
- Motor cable: Shielded and unshielded cable routes have different maximum documented lengths.
- Grounding: Protective earth, shield termination, conductor size, and cable routing control electrical safety and interference.
