Features:
- 6EP1334-2BA20 accepts two automatic single-phase AC input windows.
- The regulated output is adjustable around the 24 V DC nominal level.
- Local and relay-based indications report the 24 V OK condition.
The 6EP1334-2BA20 establishes an isolated DC supply between a 120/230 V AC feeder and a 24 V load bus.
Its adjustment range accommodates a defined voltage setting without changing the unit's 10 A rated identity.
Input protection, output loading and the natural-convection clearances form one cabinet-integration check.
The Siemens 6EP1334-2BA20 SITOP PSU100S Stabilized Power Supply may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6EP1334-2BA20 SITOP PSU100S Stabilized Power Supply Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
How the AC source reaches the converter
- First window: The lower input path covers 85–132 V AC.
- Second window: The upper input path covers 170–264 V AC.
- Frequency boundary: Both windows are specified for a 47–63 Hz line.
- Feeder check: Source voltage must fall inside one documented window before the 24 V rail is loaded.
Reading the 24 V supply condition
- Local indication: A green LED identifies the 24 V OK state at the device.
- Remote indication: A normally open relay contact carries the same status outside the supply.
- Contact boundary: The signaling contact is rated for 60 V DC and 0.3 A.
- Signal purpose: The contact reports output condition; it does not carry load current.
Relationship between demand and current limiting
- Rated service: The nominal load point is 24 V DC at 10 A.
- Extended range: Output current can reach 12 A under the documented temperature condition.
- Short overload: The 150% capability is limited to five seconds in each minute.
- Short circuit: Constant-current control reduces voltage as current reaches the limiting region.
Mechanical and thermal placement
- Rail interface: The enclosure snaps onto a 35 mm EN 60715 DIN rail.
- Vertical airflow: Fifty millimetres of free space is required above and below.
- Side spacing: Adjacent housings may be placed without an additional side gap.
- Terminal grouping: Line, DC output and signaling conductors use separate screw-terminal positions.
