9907-029

/ 4.9
1001 reviews | Need a Specific Revision?
The Woodward 9907-029 is a high-performance SPM-A synchronizer/speed and phase matching control module that supports standard AC voltage input.
Get a quick price for 9907-029
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 9907-029

  • Manufacturer:
    Woodward
  • Part Number:
    9907-029
  • Product Family:
    Woodward SPM-A Synchronizer
  • Input voltage:
    115 or 230VAC RMS, 50/60Hz
  • Voltage tolerance:
    +1.0%
  • Power consumption:
    5 W maximum
  • Synchronizer reset:
    Auto reset
  • Phase matching window:
    ±10°
  • Voltage offset:
    ±29% input voltage compensated
  • Operating temperature:
    -54 to +66°C (–65 to +150°F)
  • Weight:
    1.76 kg
  • Estimated shipping dimensions:
    31.5x21x4.7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Woodward 9907-029 is a high-performance SPM-A synchronizer/speed and phase matching control module designed for parallel operation of multiple generators or turbines. It ensures precise phase, speed, and frequency matching between units, improving system stability and safety. The module supports standard AC voltage input (115/230VAC, 50/60Hz), with a typical synchronization time of less than 5.5 seconds and a ±10° phase matching window. It features a speed bias output, enabling ±1.5Hz frequency adjustment at 50 or 60Hz generator frequencies, and supports various electronic load sharing control systems, including high-impedance, low-impedance, and EPG outputs.

The 9907-029 consumes as little as 5W, features an indicator light to show its active status, and supports remote mode switching (run, check, enable, and shut-off modes). Its compact size and approximately 2kg weight allow for installation within switchgear. Operating in a temperature range of -54°C to +66°C, it ensures long-term reliable operation in industrial environments. Its design facilitates the installation, maintenance, and safe operation of power plants, industrial automation, and multi-machine parallel control systems.
Alternative Names
9907-028 9907-173 8237-1104 5503-282 5464-414
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is 9907-029 covered by warranty?
9907-029 typically comes with a 1-year warranty. Some suppliers offer extended warranties for a longer period.
What is the module synchronization time?
Typical synchronization time is less than 5.5 seconds (from standstill, assuming an acceleration rate of 55%/second and optimal governor settings).
Input voltage and frequency range?
Supports 115 or 230VAC, 50/60Hz, voltage tolerance +1%.
What are the output options?
Compatible with high impedance output (2301 system), low impedance output (2301A, EPG, 2500 system), and EPG output.
How does the module achieve phase matching?
The module provides a ±10° phase angle matching window and compensates for ±15° phase misalignment between the generator and synchronizer.
Does it support voltage matching?
The standard provides a 1% or 5% voltage matching range; custom specifications are available for special requirements.
What are the operating modes?
Run, check, enable, and shut-off modes, which can be remotely switched via an external switch.
