IC694MDL930

/ 4.9
1001 reviews | Need a Specific Revision?
The Model IC694MDL930 is an isolated relay output module designed for PACSystems RX3i and Series 90-30 programmable logic controllers (PLCs), providing eight normally open relay circuits for controlling industrial output loads.
Get a quick price for IC694MDL930
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC694MDL930

  • Manufacturer:
    General Electric
  • Part Number:
    IC694MDL930
  • Product Family:
    GE PACSystems RX3i
  • Compatible Systems:
    PACSystems RX3i, Series 90-30
  • Rated Voltage (Nominal):
    24 VDC, 120/240 VAC
  • Operating Voltage (AC):
    5 to 250 VAC, 50/60 Hz
  • Maximum Load (Resistive):
    4 Amps per output
  • Maximum Module Current:
    20 Amps
  • Minimum Load:
    10 mA
  • Maximum Inrush Current:
    5 Amps
  • Power Consumption (5V Bus):
    6 mA (all outputs on)
  • Hot Swap Compatibility:
    Not compatible
  • Typical Applications:
    Motor starters, solenoids, indicators
  • Weight:
    0.3 kg
  • Estimated shipping dimensions:
    3.5x13.2x13.5cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications

Features:

  • Eight isolated normally open relay outputs for RX3i and Series 90-30 PLCs
  • Individual point isolation with separate common terminals per channel
  • LED status indicators for each output point
The IC694MDL930 provides essential output switching functions critical to the entire control path, serving as the primary interface between the PLC and field actuators, directly affecting the proper, normal operation of the overall automation system. One IC694MDL930 module is required per group of up to eight output points, installed in any I/O slot of a Series 90-30 or RX3i system.

For applications requiring switching of both AC and DC loads, the IC694MDL930 operates over a wide voltage range of 5 to 250 VAC or 5 to 30 VDC. In addition to standard resistive loads, the relay outputs of the IC694MDL930 can control inductive loads such as motor starters and solenoids, with appropriate suppression circuits recommended to maximize contact life.

The IC694MDL930's robust design ensures reliable operation in industrial environments. Using high-quality relay components with 4 amp resistive rating per output, the module delivers dependable switching performance over extended service life. The isolation characteristics of the IC694MDL930 provide 250 VAC continuous isolation between field wiring and the backplane, and between individual output points.

The IC694MDL930 General Electric  Output modules may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

General Electric IC694MDL930 Output modules Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IC694MDL930 PACSystems* RX3i Specs

General

  • Manufacturer General Electric
  • Model IC694MDL930
  • Condition New Original ready stock
  • Product Family IC694MDL940,IC693MDL940,IC694MDL916,IC693MDL916
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The Model IC694MDL930 is a versatile isolated relay output module engineered for PACSystems RX3i and Series 90-30 PLC platforms, providing eight normally open relay contacts for controlling a wide range of industrial output devices. Each of the eight output points on the IC694MDL930 is rated at 4 amps resistive maximum and features complete isolation from other points, with each point having its own separate common power output terminal.

The electrical specifications of the IC694MDL930 demonstrate its flexibility across both AC and DC applications. The module operates with supply voltages from 5 to 250 VAC at 50/60 Hz or 5 to 30 VDC, accommodating a broad range of field device requirements. Each output on the IC694MDL930 provides 4 amps resistive maximum load capacity, with 2 amps pilot duty rating for inductive loads, and supports 5 amp inrush current capability.

Installation and environmental considerations are important aspects of the IC694MDL930 design. This module can be installed in any I/O slot within a Series 90-30 or RX3i system, providing flexible configuration options. The IC694MDL930 is not compatible with hot swap operations, and modules must not be inserted or removed with power applied to prevent damage.

Application considerations for the IC694MDL930 include proper load management and suppression techniques. The maximum load current is temperature-dependent, with derating required at elevated ambient temperatures. Relay contact life when switching inductive loads can approach resistive load contact life if appropriate suppression circuits are employed.
Revisions

Revision Part #

Also known as

IC694MDL930A
IC694MDL930-A, Series A, Rev A
IC694MDL930B
IC694MDL930-B, Series B, Rev B
IC694MDL930C
IC694MDL930-C, Series C, Rev C
IC694MDL930D
IC694MDL930-D, Series D, Rev D
Alternative Names
IC694MDL940 IC693MDL940 IC694MDL916 IC693MDL916
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the key specifications of the IC694MDL930 relay output module?
The IC694MDL930 is an isolated relay output module with eight normally open contacts, each rated at 4 amps resistive maximum load. It operates over a wide voltage range of 5 to 250 VAC (50/60 Hz) or 5 to 30 VDC, with 2 amps pilot duty rating for inductive loads. Each output point is individually isolated from other points with separate common power terminals, and individual LEDs display the ON/OFF status of each output.
What are the isolation characteristics of the IC694MDL930?
The IC694MDL930 provides comprehensive isolation with 250 VAC continuous isolation between field wiring and the backplane/frame ground, and 1500 VAC for 1 minute. Point-to-point isolation is also rated at 250 VAC continuous and 1500 VAC for 1 minute, ensuring each of the eight output channels is electrically isolated from the others. This allows the IC694MDL930 to control loads with different voltage supplies within the same module.
What are the important installation requirements for the IC694MDL930?
The IC694MDL930 can be installed in any I/O slot of a Series 90-30 or RX3i system, but it is not compatible with hot swap operations. Power must be turned off before inserting or removing the module to prevent damage. For hazardous area installations (Class I, Division 2), the IC694MDL930 must be mounted within an enclosure accessible only by tool, and power must be switched off before replacing or wiring modules. The module requires an ultimate enclosure providing at least IP20 protection.
How can contact life be maximized when using the IC694MDL930 with inductive loads?
Relay contact life when switching inductive loads with the IC694MDL930 can approach resistive load contact life if appropriate suppression circuits are used. For DC loads, a suppression diode (such as industry standard 1N4935, 1A, 200V) connected across the load is recommended. For AC loads, an RC suppression network (resistor and capacitor) across the load is typical. These suppression circuits reduce arcing and contact wear, significantly extending the operational life of the IC694MDL930 relays when driving solenoids, motor starters, or other inductive devices.
