ABB CI522 3BSE012790R1 is an Advant Fieldbus 100 interface module for Advant Controller 400 systems, supporting bus-master administration, RS-485 communication and redundant AF100 configurations.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for CI522 3BSE012790R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI522 3BSE012790R1

  • Manufacturer:
    ABB
  • Part Number:
    CI522 3BSE012790R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    AF100 Interface Module
  • Stock:
    1
  • Controller Platform:
    Advant Controller 400
  • Interface Standard:
    RS-485
  • Maximum Cyclic Data Packages:
    4,000
  • Input Impedance:
    12 kΩ
  • Input Current:
    60 mA
  • Power Consumption at +5 V:
    3.7 W
  • Power Consumption at +24 V:
    2 × 2.5 W
  • Weight:
    0.14 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cabling Redundancy Diagnostics Application
  • AF100 interface for Advant Controller 400 systems
  • Bus-master operation with full administration
  • Supports up to 4,000 cyclic data packages

CI522 3BSE012790R1 is an ABB AF100 interface module designed for the Advant Controller 400 platform.

It connects the controller to Advant Fieldbus 100 over RS-485 and can participate in the documented redundant AF100 architecture.

Before installation or replacement, verify the controller version, paired-module arrangement, connection unit, fieldbus cable and available +5 V and +24 V power.

Availability, condition, price, and shipping time for CI522 3BSE012790R1 are confirmed during quotation.

ABB CI522 3BSE012790R1 AF100 Interface Module Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • TC625, TC512 and TC516 are documented AF100 connection units
  • TK803V018 is documented for CI522 connection in AC450 installations
  • RS-485 line termination and bus topology must match the installed AF100 network
  • Two CI522 modules can be used in the documented redundant controller arrangement
  • Each interface connects to the media-redundant Advant Fieldbus 100 paths
  • Replacement work must preserve the existing paired-interface and bus assignment
  • Front indicators report module operation and AF100 bus activity
  • The two bus-path indicators support diagnosis of the redundant fieldbus paths
  • ABB removal and exchange procedures require diagnosis before disturbing a working bus
  • Advant Controller 400 communication on Advant Fieldbus 100
  • Media-redundant AF100 controller-interface configurations
  • AC450 installations using the documented TK803V018 interface cable
Description
CI522 3BSE012790R1 is an ABB AF100 interface module for Advant Controller 400 systems.

The module provides RS-485 Advant Fieldbus 100 communication, can act as bus master with full administration, and supports up to 4,000 cyclic data packages.

Before installation or replacement, confirm the complete order code, controller platform, redundant-bus arrangement, modem or connection unit, cable type, power loading and existing AF100 configuration.
Alternative Names
CI522 3BSE012790R1 3BSE012790R1 CI522 ABB CI522 3BSE012790R1 ABB CI522 CI522 3BSE012790R1
Technical notes
CI522 3BSE012790R1 requires confirmation of the Advant Controller 400 platform, AF100 redundancy arrangement, connection unit and cable before replacement; an incorrect interface or bus topology can interrupt fieldbus communication.
