    Apter Power supports CI854AK01 sourcing, documentation, A-version verification, and migration review.

CI854AK01 3BSE030220R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB CI854AK01 3BSE030220R1 packages the two-channel CI854A PROFIBUS DP-V1 master with a TP854 baseplate for AC 800M installations.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for CI854AK01 3BSE030220R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI854AK01 3BSE030220R1

  • Manufacturer:
    ABB
  • Part Number:
    CI854AK01 3BSE030220R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    PROFIBUS DP-V1 Communication Interface
  • Stock:
    1
  • ABB Article Number:
    3BSE030220R1
  • Package Contents:
    CI854A interface and TP854 baseplate
  • Protocol:
    PROFIBUS DP-V1
  • Operating Role:
    Master
  • Channels:
    2
  • Transmission Speed:
    9.6–12,000 kbit/s
  • Cable Redundancy:
    Yes
  • Module Redundancy:
    Yes
  • Hot Swap:
    Yes
  • High Integrity Controller Use:
    Yes
  • Maximum CEX-Bus Units:
    12
  • Connector:
    DB female, 9-pin
  • Typical 24 V Consumption:
    190 mA
  • Protection Rating:
    IP20
  • Weight:
    0.7 kg
  • Estimated shipping dimensions:
    Product dimensions: 5.9 x 18.5 x 12.75 cm (W x H x D), including base.
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Legacy Matching DP Network Upgrade Review

Features:

  • A-version package: The order combines CI854A hardware with the TP854 baseplate.
  • Redundant master: Two PROFIBUS channels support cable and module redundancy.
  • Project dependency: Correct operation depends on the installed 800xA software and hardware definitions.

CI854AK01 serves established AC 800M PROFIBUS installations that retain the A-version communication interface.

Its system role resembles CI854BK01, but the hardware generation and supported software environment require separate verification.

Replacement planning should preserve the project backup, device descriptions, addresses, segment layout, and validated redundancy behavior.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

CI854AK01 3BSE030220R1 PROFIBUS DP-V1 Communication Interface Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

ABB CI854AK01 3BSE030220R1 PROFIBUS DP-V1 Communication Interface Specs

General

  • ManufacturerABB
  • ModelCI854AK01 3BSE030220R1
  • ConditionNew Original ready stock
  • Product FamilyABB S800 I/O and AC 800M

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

A-version identity checks

  • Article number: Use 3BSE030220R1 as the package identity.
  • Hardware tree: Confirm CI854A is configured, not CI854B.
  • Baseplate: Inspect the TP854 connectors and code lock.
  • Label record: Photograph the interface and base before removal.

Fieldbus reliability checks

  • Termination: Verify both outermost nodes.
  • Shielding: Maintain the approved shield and grounding scheme.
  • Timing: Keep the documented baud rate and segment length.
  • Device set: Preserve addresses, GSD files, and parameters.

Migration-control steps

  • Supported releases: Compare old and proposed software baselines.
  • Configuration impact: Review hardware definitions and project conversion.
  • Redundancy test: Retest pair and line switchover after change.
  • Rollback: Keep a verified backup and restoration plan.
Description
The CI854AK01 3BSE030220R1 is the ABB package containing a CI854A communication interface and TP854 baseplate for PROFIBUS DP-V1 communication with AC 800M.

For CI854AK01 3BSE030220R1, ABB documents two master channels, high-speed PROFIBUS operation, cable and module redundancy, hot swap, and High Integrity controller use.

Before ordering CI854AK01 3BSE030220R1, verify the installed A-version, 800xA release, controller firmware, project library, network topology, and migration constraints.
Alternative Names
ABB CI854AK01 3BSE030220R1 CI854AK01 3BSE030220R1 CI854AK01 CI854A K01 CI854A/TP854 3BSE030220R1 3BSE 030220 R1 AC 800M CI854A PROFIBUS interface
Technical notes
ABB CI854AK01 3BSE030220R1 is a profibus dp-v1 communication interface documented for ABB S800 I/O and AC 800M. Verify the complete article, installed hardware, wiring, and system configuration before ordering.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should CI854AK01 3BSE030220R1 be matched to an established AC 800M project?
Confirm the exact A-version article, controller type, 800xA release, firmware, hardware library, CEX-Bus position, and project backup.
Can CI854BK01 replace CI854AK01 without engineering changes?
Do not assume a drop-in migration; compare supported releases, hardware definitions, configuration, redundancy behavior, and ABB migration guidance.
What network evidence should buyers provide for a CI854AK01 quotation?
Include the segment drawing, device count, baud rate, addresses, repeaters, linking devices, cable length, redundancy layout, and current diagnostics.
What should be checked if CI854AK01 reports intermittent slave loss?
Review physical termination, connector power, shielding, grounding, cable quality, address conflicts, device power, timing, and the master diagnostic buffer.
How should a redundant CI854AK01 pair be serviced?
Verify which module and line are active, follow the approved hot-swap procedure, preserve cable labels, and test recovery before closing the work order.
Which records reduce risk when migrating from CI854AK01?
Retain the controller project, hardware tree, GSD files, device parameters, bus scan, alarm history, firmware inventory, and acceptance results.
Why might PROFIBUS devices remain unavailable after CI854AK01 replacement?
Check that the correct hardware type is configured, the project is loaded, channels are enabled, addresses match, and segment termination is healthy.
What should a CI854AK01 procurement RFQ include?
State quantity, condition, destination, deadline, complete labels, software version, redundancy scope, network drawing, and documentation requirements.
